Eaton TB200HB-09BSQC3 Panel Mount Terminal Block - 9-Pole
Part Number: TB200HB-09BSQC3
Quick Summary
TB200HB-09BSQC3 panel mount terminal block connectors provide reliable signal and power distribution in compact control panels. Engineers often struggle to meet high voltage and current requirements in tight enclosures without sacrificing reliability. This Eaton device is CE marked and RoHS compliant, aligning with essential regulatory standards for European installations and sustainable manufacturing practices. The 9-pole high barrier design supports clean, organized terminations in automation cabinets, while the rugged construction helps reduce maintenance cycles. By combining robust electrical ratings with a compact footprint, this terminal block delivers measurable business value for panel builders and system integrators, enabling quicker commissioning and more predictable uptime in demanding environments.
Product Information
Extended Description
TB200HB-09BSQC3 Eaton: Eaton Bussmann TB200 series panel mount terminal block connector, Breakdown voltage 4800 V, 600 V, 30 A, High barrier, 9-pole, Black, Tin-plated brass terminal, Nickel-plated brass SEMS philslot screw
Product Name
Eaton Bussmann TB200 series panel mount terminal block connector
Catalog Number
TB200HB-09BSQC3
UPC
051712582117
Product Length/Depth
4.69 in
Product Height
0.75 in
Product Width
1.37 in
Product Weight
0.6 lb
Warranty
Not Applicable
Compliances
CE Marked RoHS Compliant
Certifications
Contact Manufacturer
Amperage Rating
30A
Voltage rating
600 V
Number Of Poles
Nine-pole
Type
High barrier
Feature → Business Impact → Application: The TB200HB-09BSQC3 uses a nine-pole high barrier design that provides clear separation between conductors, reducing creepage and improving safety in dense control panels. This translates to lower risk of cross-talk and short circuits in machine wiring, boosting overall equipment reliability for automated lines. Application: ideal for industrial automation enclosures where space is at a premium and wiring density is high. Feature → Business Impact → Application: The unit carries a 30 A amperage rating at 600 V, delivering strong fault tolerance and margin for motor control and power distribution tasks. This supports faster, safer commissioning and reduces the need for oversized interconnects in mid-range automation projects. Feature → Business Impact → Application: Tin-plated brass terminals with nickel-plated SEMS philslot screws offer corrosion resistance and vibration durability, extending life in harsh environments. Application: suitable for outdoor or factory floor installations where moisture and vibration are concerns. Feature → Business Impact → Application: Breakdowns up to 4800 V provide high insulation safety margins for high-energy applications, enabling reliable operation in mixed signal and power interfaces. Application: useful in panels feeding high-energy loads where strict isolation is required. Feature → Business Impact → Application: The compact footprint (4.69 in L, 1.37 in W, 0.75 in H) and panel-mount form factor simplify installation in standard electrical cabinets, accelerating wiring harness assembly and reducing enclosure modification costs. Application: fits common DIN rail or panel cutouts in machine builders and OEM panel shops. Feature → Business Impact → Application: Compliance with CE and RoHS minimizes regulatory risk and supports sustainability goals; Certification details can be requested for additional markets. Application: ensures project teams meet European market requirements and supplier compliance obligations. Overall, the TB200HB-09BSQC3 provides reliable, scalable terminations with predictable performance, helping engineers deliver faster time-to-market and lower maintenance overhead.
