Eaton TB200HB-10 Panel Mount Terminal Block - 600 V
Part Number: TB200HB-10
Quick Summary
Panel Mount Terminal Block TB200HB-10 from Eaton delivers compact, reliable panel wiring for control panels and automation systems. Engineers often face dense, misaligned wiring, risk of arcing, and limited space when routing high‑voltage circuitry; this block’s high barrier design and 10‑pole arrangement help keep conductors separated and organized. The TB200HB-10 carries 30 A at 600 V with a breakdown voltage of up to 4800 V, supporting demanding industrial applications, while the tin-plated brass terminals and zinc‑plated steel screws contribute to long-term performance in harsh environments. It’s CE Marked and RoHS Compliant, ensuring regulatory alignment across global installations. In practice, its double‑row layout and 6‑32 TPI screws speed installation, reduce wiring errors, and lower maintenance costs for panel builders and system integrators.
Product Information
Extended Description
TB200HB-10 Eaton: Eaton Bussmann TB200 series panel mount terminal block connector, Breakdown voltage 4800 V, 600 V, 30 A, High barrier, 10-pole, 6-32 TPI Screw, Black, Tin-plated brass terminal, Zinc-plated steel philslot screw
Product Name
Eaton Bussmann TB200 series panel mount terminal block connector
Catalog Number
TB200HB-10
UPC
051712812481
Product Length/Depth
5.13 in
Product Height
0.75 in
Product Width
1.37 in
Product Weight
0.7 lb
Warranty
Not Applicable
Compliances
CE Marked RoHS Compliant
Certifications
Contact Manufacturer
Amperage Rating
30A
Voltage rating
600 V
Number Of Poles
Ten-pole
Type
Double row, high barrier
Bussmann series complete full line catalog no. 1007
Bussmann series complete full line catalog no. 1007
Bussmann series Fuseology
Feature → Business Impact → Application: Ten-pole, double-row high barrier design provides effective isolation between circuits, reducing cross-talk and the risk of fault propagation in dense control panels; this translates to improved reliability and safer maintenance in automation systems, particularly where multiple actuators and sensors share a compact footprint. Application: Ideal for industrial automation wiring in machine control panels where space is at a premium and safety margins must be maintained. Feature → Business Impact → Application: 30 A at 600 V electrical ratings, with a breakdown voltage up to 4800 V, delivering robust performance for motors, drives, and logic circuits; this enables designers to scale control architectures with confidence while meeting regulatory specs. Application: Suitable for motor control centers and power distribution nodes in manufacturing lines. Feature → Business Impact → Application: Tin-plated brass terminals and zinc-plated steel philslot screws offer superior corrosion resistance and mechanical durability; this lowers replacement frequency and maintenance costs in harsh environments and dusty plant floors. Application: Long-life wiring blocks in assembly lines and packaging equipment. Feature → Business Impact → Application: 5.13 in length, 1.37 in width, and 0.75 in height provide a compact footprint that simplifies cabinet layouts and panel mounting; installation is faster and reduces overall enclosure size. Application: Retrofit projects and new builds for compact control panels. Feature → Business Impact → Application: CE Marking and RoHS compliance ensure regulatory alignment and material traceability; this supports global deployment and simplifies supplier qualification. Application: International machinery builds and OEM equipment where standards conformance is mandatory. Feature → Business Impact → Application: 6-32 TPI screws support standard, widely available fastening hardware, enabling quick field servicing and scalable maintenance programs. Application: Field upgrades and serviceable control panels in process industries.
