Eaton TB200HB-12L1L2QC4 Panel Mount Terminal Block - 600V
Part Number: TB200HB-12L1L2QC4
Quick Summary
Eaton TB200HB-12L1L2QC4 terminal block is a panel-mount connector designed for high-density control panels. Engineers often face wiring congestion, insulation breakdown, and difficult field terminations in tight enclosures. This 12-pole high-barrier design is RoHS compliant and CE marked, with a breakdown voltage up to 4800 V and a standard operating voltage of 600 V, plus a 30 A current capability to handle common industrial loads. Its compact footprint and robust materials deliver reliable performance while simplifying supplier qualification for wiring assemblies. By standardizing on this TB200HB-12L1L2QC4, projects can reduce rework, accelerate installation, and improve long-term maintenance across diverse machinery.
Product Information
Extended Description
TB200HB-12L1L2QC4 Eaton: Eaton Bussmann TB200 series panel mount terminal block connector, Breakdown voltage 4800V, 600V, 30A, High barrier, Twelve-pole, Black, Tin-plated brass terminal, zinc-plated steel philslot screw - TB200HB-12L1L2QC4
Product Name
Eaton Bussmann TB200 series panel mount terminal block connector
Catalog Number
TB200HB-12L1L2QC4
UPC
051712393515
Product Length/Depth
6 in
Product Height
0.75 in
Product Width
1.37 in
Product Weight
0.7 lb
Warranty
Not Applicable
Compliances
RoHS Compliant CE Marked
Certifications
Contact Manufacturer
Amperage Rating
30A
Voltage rating
600 V
Number Of Poles
Twelve-pole
Type
High barrier
Bussmann series complete full line catalog no. 1007
Bussmann series complete full line catalog no. 1007
Bussmann series Fuseology
Feature → Business Impact → Application: High-density 12-pole, high-barrier design reduces wiring footprint and improves isolation, increasing safety and reducing panel complexity while enabling denser control architectures in industrial equipment. Feature → Business Impact → Application: Tin-plated brass terminals with zinc-plated steel philslot screws provide corrosion resistance and secure torque, lowering maintenance needs and extending service life in demanding environments such as packaging lines and process controls. Feature → Business Impact → Application: Electrical ratings of 30 A at 600 V support heavy loads and power distribution within compact enclosures, reducing the need for multiple smaller blocks and improving reliability in motor control and feeder wiring. Feature → Business Impact → Application: Panel-mount form factor with a 6 in depth and compact dimensions enables faster wiring and simpler field termination, cutting installation time and labor costs in new builds and retrofits. Feature → Business Impact → Application: RoHS compliant and CE marked, easing regulatory compliance for global deployments and supplier qualification across overseas projects, while maintaining consistent performance. Feature → Business Impact → Application: Dense, high-barrier insulation and 12-pole arrangement improve wiring organization and traceability, which supports predictive maintenance and ROI through reduced downtime.
