Eaton TB200HB-20 Panel Mount Terminal Block - 600V/30A, CE
Part Number: TB200HB-20
Quick Summary
The Eaton TB200HB-20 panel mount terminal block connector enables reliable conductor termination in industrial control panels. Many engineers struggle with high-density layouts and ensuring safe, consistent connections across double-row configurations. This part is CE marked and RoHS compliant, providing regulatory confidence while withstanding harsh industrial environments with a 4800V breakdown rating. The 20-pole, double-row design uses #6-32 TPI screws and tin-plated brass terminals to deliver secure wiring in tight spaces. Built for efficiency, it reduces panel footprint and accelerates maintenance cycles. With rugged construction and standardized interfaces, TB200HB-20 supports scalable automation projects and global supply requirements.
Product Information
Extended Description
TB200HB-20 Eaton: Eaton Bussmann TB200 series panel mount terminal block connector, Breakdown voltage 4800V, 600V, 30A, Double row, high barrier, 20-pole, #6-32 TPI Screw, Black, Tin-plated brass terminal, Zinc-plated Steel philslot screw
Product Name
Eaton Bussmann TB200 series panel mount terminal block connector
Catalog Number
TB200HB-20
UPC
051712194518
Product Length/Depth
9.5 in
Product Height
0.75 in
Product Width
1.37 in
Product Weight
0.8 lb
Warranty
Not Applicable
Compliances
CE Marked RoHS Compliant
Certifications
Contact Manufacturer
Amperage Rating
30A
Voltage rating
600 V
Number Of Poles
20-pole
Type
Double row, high barrier
Bussmann series complete full line catalog no. 1007
Bussmann series complete full line catalog no. 1007
Bussmann series Fuseology
Feature: 20-pole, double-row high-barrier design increases wiring density and improves insulation between adjacent circuits. Business Impact: enables compact control panels with safer separation of circuits, reducing risk of cross-talk and shorts. Application: machine control cabinets and power-distribution enclosures where space is at a premium. Feature: 30A, 600V electrical ratings provide robust support for industrial loads. Business Impact: supports common automation and distribution circuits without overdesign, cutting cost and simplifying procurement. Application: power rails, motor control circuits, and I/O terminations in panel assemblies. Feature: Tin-plated brass terminals with zinc-plated steel philslot screws offer corrosion resistance and torque stability. Business Impact: longer service life in challenging environments and reduced maintenance intervals. Application: harsh manufacturing floors, outdoor-rated enclosures, and sealed control panels. Feature: 4800V breakdown voltage specification enhances insulation performance for surge conditions. Business Impact: provides higher insulation margin in multi-conductor applications, improving reliability. Application: high-voltage control panels and equipment where transient protection matters. Feature: #6-32 TPI screw terminals and 9.5 in length with 1.37 in width enable straightforward field wiring and installation. Business Impact: faster terminations, standardized tooling, and predictable layouts. Application: dense control cabinets and modular automation racks. Feature: CE Marked and RoHS compliant ensure regulatory alignment and sustainability. Business Impact: reduces compliance risk during audits and supports green manufacturing initiatives. Application: European and global automation deployments, with traceable supplier documentation. Feature: 20-pole, double-row architecture helps optimize footprint without sacrificing accessibility. Business Impact: lowers enclosure footprint, simplifies cable management, and speeds future expansion. Application: distributed I/O and multi-channel control networks across industrial systems.
Get a Quick Quote for a Eaton TB200HB-20
Chat with us on WhatsApp - fast responses guaranteed
Need to speak with someone? We'll call you back within 2 hours during business hours
Interested in Eaton TB200HB-20?
Enquire Now
FAQs
TB200HB-20 is designed for panel mounting with a 9.5 inch length and 1.37 inch width, using standard #6-32 TPI screws to terminate conductors. Ensure clean, rated enclosure space and proper panel cutouts; torque screws to the manufacturer’s recommended values to maintain insulation integrity and long-term reliability in industrial environments.
The terminal block is rated for 30A at 600V, with a breakdown voltage specification of 4800V to support insulation performance under transient conditions. It features 20 poles in a double-row high-barrier arrangement, suitable for dense I/O terminations in control panels and distribution units.
TB200HB-20 carries CE marking and RoHS compliance, aligning with European regulatory requirements and environmental standards. For additional certifications, contact Eaton directly to confirm suitability for your specific regulatory regime and application.
This 20-pole, double-row panel mount terminal block is ideal for machine control panels, automation cabinets, and power-distribution enclosures where high-density wiring and reliable terminations are required. Its mechanical robustness and 600V/30A ratings support motor control, I/O terminations, and high-density control networks.
Use the #6-32 TPI screws for secure terminations on tin-plated brass terminals, and apply torque per Eaton's guidelines to avoid over-tightening. Keep conductors properly stripped and within recommended gauge ranges, maintain clean contact surfaces, and protect against moisture and dust ingress with appropriate enclosure sealing for extended service life.
