Eaton TB200HB-20SP Panel Mount Terminal Block - CE Marked
Part Number: TB200HB-20SP
Quick Summary
Eaton TB200HB-20SP panel mount terminal block connects high-density wiring for control panels. In dense installations, space, insulation, and reliable terminations can be a bottleneck; this block delivers a high barrier and compact 9.5 inch length to maximize field wiring efficiency. It is CE marked and RoHS compliant, with a 600 V voltage rating and 30 A amperage, supporting safe, regulatory-ready operation in industrial environments. The tin-plated brass terminals and #6-32 TPI screws ensure durable, low-resistance connections under vibration. By combining rugged construction with straightforward installation, it provides predictable performance for engineers, technicians, and procurement teams managing panel assemblies and wiring harnesses.
Product Information
Extended Description
TB200HB-20SP Eaton: Eaton Bussmann TB200 series panel mount terminal block connector, Breakdown voltage 4800V, 600V, 30A, Double row, high barrier, 20-pole, #6-32 TPI Screw, Black, Tin-plated brass terminal
Product Name
Eaton Bussmann TB200 series panel mount terminal block connector
Catalog Number
TB200HB-20SP
UPC
051712847216
Product Length/Depth
9.5 in
Product Height
0.75 in
Product Width
1.37 in
Product Weight
0.8 lb
Warranty
Not Applicable
Compliances
CE Marked RoHS Compliant
Certifications
Contact Manufacturer
Amperage Rating
30A
Voltage rating
600 V
Number Of Poles
20-pole
Type
Double row, high barrier
Feature: 20-pole, double-row, high-barrier design. Business Impact: enables dense wiring while maintaining strong insulation between circuits, reducing creepage risk in compact panels. Application: control cabinets and instrumentation enclosures where space is at a premium. Feature: 30A current rating and 600 V voltage rating with 4800 V breakdown voltage. Business Impact: supports higher-energy circuits with ample safety margins, improving reliability and fault tolerance. Application: motor starters, drives, and power distributions in industrial automation. Feature: screw terminals using #6-32 TPI screws. Business Impact: secure, vibration-resistant terminations that minimize maintenance and re-termination costs. Application: harsh manufacturing environments and equipment subject to vibration. Feature: tin-plated brass terminals. Business Impact: provides corrosion resistance and long-term conductivity for outdoor or damp locations. Application: outdoor control panels and moisture-prone installations. Feature: panel-mounted form factor with 9.5 in length, 1.37 in width, and 0.75 in height. Business Impact: reduces enclosure footprint while enabling easy routing and mounting in tight spaces. Application: dense wiring harnesses in modern control panels. Feature: CE Marked and RoHS Compliant. Business Impact: regulatory acceptance in Europe and compliance with lead-free materials, reducing compliance risk. Application: multinational manufacturing lines and integrated systems. Feature: rugged construction with black finish and 20 poles. Business Impact: visible, robust wiring solution that withstands industrial environments while supporting organized wiring. Application: instrumentation cabinets and process control panels.
Get a Quick Quote for a Eaton TB200HB-20SP
Chat with us on WhatsApp - fast responses guaranteed
Need to speak with someone? We'll call you back within 2 hours during business hours
Interested in Eaton TB200HB-20SP?
Enquire Now
FAQs
To install TB200HB-20SP, align the 20-pole block to the panel cutout, secure with appropriate mounting hardware, and connect conductors to each #6-32 TPI screw terminal. Tighten screws to the recommended torque, ensuring clean, tin-plated brass terminations for reliable contact. This design supports quick termination and minimizes field re-termination during maintenance.
The TB200HB-20SP is rated for 30 A at 600 V, with a breakdown voltage of 4800 V. It features 20 poles in a double-row, high-barrier configuration, making it suitable for high-density, reliable panel wiring in industrial control environments.
Yes. The TB200HB-20SP carries CE marking and RoHS compliance, aligning with European regulatory requirements and ensuring lead-free materials are used in its construction. This supports regulatory acceptance and safer, environmentally responsible deployment.
Best suited for dense control panels, instrumentation cabinets, and power distribution enclosures where space is limited but dependable, high-voltage wiring is required. Its high-barrier design improves creepage distances, while the 20-pole configuration supports complex wiring harnesses in automation and process control systems.
The TB200HB-20SP measures 9.5 in in length, 1.37 in in width, and 0.75 in in height, with an approximate weight of 0.8 lb. It is designed for panel mounting, enabling straightforward installation and compact enclosure design while maintaining clear separation between circuits.
