Eaton TB200HB-23 panel mount terminal block - High barrier
Part Number: TB200HB-23
Quick Summary
TB200HB-23 panel mount terminal block connector from Eaton enables robust, field-installable terminations for 23 poles in control panels. Engineers often struggle with reliable isolation and compact wiring in crowded cabinets; this design addresses tight spaces and high-current demands. With CE marking and RoHS compliance, the product aligns with regulatory requirements, while its 4800 V breakdown capability and 600 V working voltage support diverse industrial uses. Designed for automation cabinets, panels, and power distribution frames, TB200HB-23 simplifies wiring schematics and maintenance planning. By supporting standard 23-pole terminations and reliable metal-to-terminal connections, it helps ensure long service life in harsh environments.
Product Information
Extended Description
TB200HB-23 Eaton: Eaton Bussmann TB200 series panel mount terminal block connector, Breakdown voltage 4800V, 600V, 30A, High barrier, 23-pole, Black, Tin-plated brass terminal, zinc-plated steel philslot screw
Product Name
Eaton Bussmann TB200 series panel mount terminal block connector
Catalog Number
TB200HB-23
UPC
051712194556
Product Length/Depth
10.81 in
Product Height
0.75 in
Product Width
1.37 in
Product Weight
0.9 lb
Warranty
Not Applicable
Compliances
CE Marked RoHS Compliant
Certifications
Contact Manufacturer
Amperage Rating
30A
Voltage rating
600 V
Number Of Poles
23-pole
Type
High barrier
Bussmann series complete full line catalog no. 1007
Bussmann series complete full line catalog no. 1007
Bussmann series Fuseology
Feature — 23-pole high barrier design; Business Impact — enables dense, reliably isolated terminations in compact panels; Application — control panels and automation cabinets where space is at a premium. Feature — 30 A at 600 V rating; Business Impact — supports typical automation loads without overloading the conductors; Application — PLC power distributions and motor control wiring. Feature — breakdown voltage up to 4800 V; Business Impact — enhanced fault and transient protection for sensitive control circuits; Application — high-energy system interfaces and safety interlocks. Feature — tin-plated brass terminals and zinc-plated steel philslot screws; Business Impact — durable, corrosion-resistant terminations reducing maintenance and replacement costs; Application — harsh factory environments with frequent vibrations. Feature — compact dimensions: 10.81 in length, 0.75 in height, 1.37 in width; Business Impact — space-efficient wiring harness integration improving panel density; Application — small-to-medium control enclosures. Feature — CE Marked and RoHS compliant; Business Impact — regulatory readiness and supply-chain assurance; Application — regulated facilities and certified equipment installations.
