Eaton TB200HB-26 Panel Mount Terminal Block - 4800V
Part Number: TB200HB-26
Quick Summary
The Eaton TB200HB-26 panel mount terminal block enables reliable 26-circuit connections in control panels. Engineers wrestle with crowded enclosures and insulation gaps that compromise signal integrity and complicate maintenance. This block carries CE marking and RoHS compliance, along with a robust 600 V / 30 A rating and a high-barrier, double-row design for safe, long-life operation. The 12.12 in length, 1.37 in width, and 0.75 in height support compact layouts, while the 26-pole configuration accelerates harnessing and reduces footprint. For manufacturers, the combination of dense wiring capability and standard #6-32 screws translates to faster assembly and lower installation risk, boosting overall equipment reliability and uptime.
Product Information
Extended Description
TB200HB-26 Eaton: Eaton Bussmann TB200 series panel mount terminal block connector, Breakdown voltage 4800V, 600V, 30A, Double row, high barrier, 26-pole, #6-32 TPI Screw, Black, Tin-plated brass terminal, Zinc-plated Steel philslot screw
Product Name
Eaton Bussmann TB200 series panel mount terminal block connector
Catalog Number
TB200HB-26
UPC
051712194563
Product Length/Depth
12.12 in
Product Height
0.75 in
Product Width
1.37 in
Product Weight
1 lb
Warranty
Not Applicable
Compliances
CE Marked RoHS Compliant
Certifications
Contact Manufacturer
Amperage Rating
30A
Voltage rating
600 V
Number Of Poles
26-pole
Type
Double row, high barrier
Bussmann series complete full line catalog no. 1007
Bussmann series complete full line catalog no. 1007
Bussmann series Fuseology
26-pole double-row high-barrier design enables dense wiring without compromising isolation, delivering safer and more maintainable panel layouts for industrial automation. This configuration reduces cross-talk and simplifies cable routing, which translates to faster wiring, fewer errors, and improved uptime in control cabinets. 30 A at 600 V provides robust power handling for motor drives and distributed I/O, while the high-barrier construction enhances safety in high-energy environments. The #6-32 TPI screws with tin-plated brass terminals and zinc-plated steel philslot screws offer reliable, corrosion-resistant connections that resist vibration in demanding environments. The compact 12.12 in length with 1.37 in width and 0.75 in height enables scalable installations across TB200 series panels, reducing overall enclosure footprint and installation time. CE marking and RoHS compliance streamline regulatory workflows and supplier qualification for industrial projects.
Get a Quick Quote for a Eaton TB200HB-26
Chat with us on WhatsApp - fast responses guaranteed
Need to speak with someone? We'll call you back within 2 hours during business hours
Interested in Eaton TB200HB-26?
Enquire Now
FAQs
To install, mount the TB200HB-26 in the panel and secure it with the standard #6-32 TPI screws. Ensure the panel surface is clean and the connectors are aligned with the 26-pole double-row layout. Verify clearance for insulation and tighten screws to the recommended torque to maintain a vibration-resistant connection.
The TB200HB-26 is rated for 30 A at 600 V, with a breakdown voltage specification up to 4800 V for high-energy isolation. These ratings support safe operation in motor drives, power distribution, and dense I/O applications within industrial automation cabinets.
Yes. The TB200HB-26 carries CE marking and RoHS compliance, which helps satisfy European regulatory requirements and ensures the product is free from restricted hazardous substances, simplifying procurement and approval processes for industrial projects.
The 26-pole double-row high-barrier design provides substantial wiring density while preserving electrical isolation between circuits. This enables compact panel layouts, faster harnessing, and reduced enclosure footprint, which translates to lower installation time and improved serviceability in automation cabinets.
TB200HB-26 uses panel mounting with a length of 12.12 inches, width of 1.37 inches, and height of 0.75 inches, weighing about 1 lb. It employs standard #6-32 TPI screws and is designed for TB200 series compatibility, simplifying upgrade paths and spare-part planning for existing installations.
