Eaton TC80 Fuse - British Standard gL/gG, 80A
Part Number: TC80
Quick Summary
The Eaton TC80 fuse is a low-voltage British Standard device that protects distribution circuits in industrial control panels. Engineers often struggle to select fuses that meet BS88 standards while maintaining compact footprints and predictable coordination with upstream protection. Key references include BS88 British Standard compatibility, UKCA declarations, and the gL/gG characteristics that define its fast-acting and general-purpose protection modes. With an 80 A rating and the 26x137 mm form factor, the TC80 delivers reliable protection without occupying valuable panel space. This combination reduces downtime, simplifies spare inventories, and supports standardised protection across modular power distributions.
Product Information
Extended Description
TC80 Eaton: Eaton Bussmann series low voltage british standard fuse, 80A, AC 660 V, DC 350 V, V88/B1, 26 x 137 mm, gL/gG
Product Name
Eaton Bussmann series low voltage british standard fuse
Catalog Number
TC80
UPC
051712485111
EAN
5027590513333
Product Length/Depth
137 mm
Product Height
26 mm
Product Width
26 mm
Product Weight
123.1 g
Warranty
No warranty
Certifications
Not Applicable
CA134002EN
UKCA Redspot fuse-links
UKCA Redspot fuse-links
Eaton Bussmann - Red Spot fuse links
10078 Red spot centre bolted fuses:TB, TBC, TC, TF, TKF, TKM, TMF, TM, TMT, TTM, TLM, TT, TLU,TXU fuses
Feature: 80 A current rating with AC up to 660 V and DC up to 350 V. Business Impact: provides robust overload and short-circuit protection for critical loads, reducing unplanned downtime. Application: ideal for motor drives, feeders, and control panels in manufacturing environments. Feature: gL/gG fuse type. Business Impact: enables versatile protection against both overload and short-circuit events, improving safety and coordination with upstream devices. Application: standard BS88 protection schemes in industrial power distribution. Feature: 26 x 137 mm form factor. Business Impact: fits common BS88 fuse holders and panel spaces, simplifying retrofits and new builds. Application: compact enclosures and modular switchgear in process automation. Feature: BS88 British Standard with UKCA declarations. Business Impact: supports regulatory compliance in the UK and related markets, streamlining procurement and auditing. Application: panel assemblies and distribution boards across UK manufacturing sites. Feature: Lightweight, 123.1 g weight. Business Impact: ease of handling during installation and reduces shipping costs. Application: field installations and maintenance cycles where weight and ergonomics matter.
Get a Quick Quote for a Eaton TC80
Chat with us on WhatsApp - fast responses guaranteed
Need to speak with someone? We'll call you back within 2 hours during business hours
Interested in Eaton TC80?
Enquire Now
FAQs
The TC80 uses the standard 26 x 137 mm BS88 footprint, designed to fit common Bussmann/BS88 fuse holders and panel cutouts. This ensures straightforward retrofits and consistent compatibility across Eaton Bussmann low-voltage fuse installations in control cabinets and distribution boards.
TC80 is rated for 80 A, with AC operation up to 660 V and DC operation up to 350 V. This makes it suitable for protection of depot and production line feeders, motor drives, and panel circuits that require BS88-compliant protection with clear short-circuit and overload response.
Yes. The TC80 supports DC operation up to 350 V, enabling protection for DC-powered drives and control circuits. Ensure coordination with upstream protection and consider system voltage levels and fault current when selecting the fuse rating.
The TC80 is aligned with BS88 British Standard requirements, and Eaton provides UKCA declarations for regulatory compliance in the UK. These certifications support procurement audits and safety approvals for panel assemblies and distribution networks.
Using the TC80 standardizes protection across BS88 panels, reducing spare variety and simplifying stocking. The predictable response to overload and short-circuit events helps minimize downtime and maintenance costs, delivering quicker fault isolation and system recovery in production environments.
