Eaton TCF10 Fuse - Class CF Time-Delay, UL Listed
Part Number: TCF10
Quick Summary
Eaton TCF10 fuse provides reliable time-delay overcurrent protection for control circuits in industrial equipment. Nuisance trips during motor starts or transient faults can slow production and complicate maintenance. It carries UL Listed, CSA Certified, and CE Marked RoHS compliance to support regulatory and safety requirements across North America and Europe. With 600 Vac / 300 Vdc ratings and 35 mm DIN rail mounting, it integrates seamlessly into standard panels, delivering dependable protection and lower total cost of ownership.
Product Information
Extended Description
TCF10 Eaton: Eaton Bussmann Series Class CF fuse, TCF, time-delay, dual-element current limiting cube fuse, 10 A, indicating fuse, interrupting rating of 100 kA at 300 Vdc and 300 kA at 600 Vac
Product Name
Eaton Bussmann series TCF fuse
Catalog Number
TCF10
UPC
051712614986
EAN
5027590184397
Product Length/Depth
1.88 in
Product Height
1.75 in
Product Width
0.75 in
Product Weight
0.08 lb
Warranty
Not Applicable
Compliances
CE Marked RoHS Compliant
Certifications
UL Listed CSA Certified
Amperage Rating
10 A
Frequency rating - max
60 Hz
Frequency rating - min
50 Hz
Interrupt rating
300 kAIC at 600 Vac 100 kAIC at 300 Vdc
Response time
10 sec at 500%
Voltage rating
600 Vac, 300 Vdc
Color
Black
Fuse type
Class CF Time delay
Material
Glass filled PES
Number of elements
Dual
Packaging type
Standard
Class
Class CF
Connection
Blade end
Fuse indicator
With Indicator
Mounting method
Chassis 35 mm DIN rail
Special features
Finger safe
Used with
TCFH30N, CCP2-3-30CF
Feature → Business Impact → Application: The TCF10 is a Class CF time-delay, dual-element cube fuse with current-limiting characteristics that reduce nuisance trips during short transients, improving equipment uptime and operator efficiency in machine controls and power supplies. Application: Ideal for control panels and DIN-rail mounted subsystems in 50/60 Hz environments, where steady protection against inrush and short circuits is essential. Feature → Business Impact → Application: The fuse is indicating and blade-end mounted, enabling quick visual status checks and simple replacement, cutting downtime during maintenance and reducing training time for technicians. Application: Suitable for panel builders integrating with TCFH30N and CCP2-3-30CF components in OEM machinery. Feature → Business Impact → Application: 600 Vac / 300 Vdc ratings paired with 10 A sizing ensure compatibility with mixed AC/DC systems, supporting design convergence and regulatory compliance while minimizing inventory complexity. Application: Use in motor drives, conveyors, and programmable logic controller (PLC) powered subsystems to balance protection and availability. Feature → Business Impact → Application: Finger-safe construction and 35 mm DIN rail mounting reduce installation risk and streamline enclosure wiring, delivering faster deployments and safer maintenance in industrial environments.
