Eaton TCF6RN Fuse - UL Listed CSA Certified RoHS

The TCF6RN combines a time-delay response with dual-element current limiting, delivering Class CF protection that tolerates short inrush while preventing nuisance trips on motor loads. This directly translates to improved process uptime and reduced maintenance interventions for critical lines. It is especially well-suited for motor starters, feeders, and control panels in demanding industrial environments. With a high interrupt rating of 100 kAIC at 300 Vdc and 300 kAIC at 600 Vac, the fuse can safely interrupt large fault currents without cascading faults. The voltage rating of 600 Vac and 300 Vdc, across a 50–60 Hz range, ensures consistent performance across AC and DC networks. Users gain predictable protection in both new builds and modernization projects. Installation is streamlined by blade-end connections on a 35 mm DIN rail chassis, allowing rapid drop-in replacement in existing frames. The compact footprint—1.88 in length, 1.75 in height, and 0.75 in width—helps save panel space and improves airflow. The device is designed for easy integration with TCFH60N and CCP2-3-60CF assemblies, supporting scalable architecture. Safety and maintenance are simplified by a finger-safe, non-indicating design, reducing shock risk during replacement. Glass-filled PES construction enhances environmental resilience in dusty or exposed panels. Its dual-element geometry improves life cycle reliability, while the standard 0.08 lb weight minimizes secondary mounting stresses in hinged enclosures. Compliance and compatibility are reinforced by UL Listed, CSA Certified, and CE RoHS marks, enabling global deployment across regulated facilities. The fuse’s spec sheet confirms suitability for 50–60 Hz systems and broad electrical protection roles in switchgear and control gear. Using this component supports regulatory audits, minimizes sourcing risk, and aligns with lean maintenance programs.
