Eaton TP130 Switch Box - Steel, UL-listed NEC/CEC
Part Number: TP130
Quick Summary
Eaton TP130 switch box is a steel enclosure for surface-mount electrical wiring in industrial control panels. Installers often wrestle with limited space, incompatible knockouts, and time-consuming field modifications, and TP130 mitigates these pain points with its gangable design and standard 1/2 inch knockouts. This product carries NEC/CEC compliance, UL listing for steel switch boxes, and suitability for Ordinary/Non-Hazardous Locations, ensuring safe, code-conforming installations. The compact 2x3x2 inch footprint and 10 cubic inch capacity support multiple terminations without overfilling, while ears and conduit entries simplify mounting and alignment. In practice, contractors gain faster installs, reduced rework, and better protection for wiring in industrial panels, with a proven Eaton Crouse-Hinds solution trusted in demanding environments.
Product Information
Extended Description
TP130 Eaton: Eaton Crouse-Hinds series Switch Box, (1) 1/2", Conduit (no clamps), 2", (1) 1/2", Steel, (2) 1/2", Ears, Gangable, 10.0 cubic inch capacity
Product Name
Eaton Crouse-Hinds series switch box
Catalog Number
TP130
UPC
786189101300
Product Length/Depth
2 in
Product Height
3 in
Product Width
2 in
Product Weight
0.48 lb
Area classification
Ordinary/Non-Hazardous Locations
Standards type
NEC/CEC
Depth
2"
Type
Gangable
Capacity
10 cubic in
Conduit/cable
Conduit (no clamps)
End Knockouts
(1) 1/2 in
Side knockouts
(2) 1/2 in
Bottom Knockouts
(1) 1/2 in
Material
Steel
Special features
Ears
Crouse-Hinds series Steel Switch Boxes catalog page
Steel Switch Boxes UL certification
Steel Switch Boxes UL certification
Eaton Specification Sheet - TP130
Eaton Specification Sheet - TP130
Feature: Steel construction and 10 cubic inch capacity provide durable, dense terminations without compromising enclosure size. Business Impact: Enhanced wiring protection and reliable performance in busy control panels, reducing field repairs and downtime. Application: Industrial panels and non-hazardous environments requiring robust steel outlet boxes. Feature: Conduit entries specified as Conduit (no clamps) streamline connections and minimize hardware costs. Business Impact: Lower install material costs and faster wiring runs, translating to shorter project timelines. Application: Conduit-based installations in machine centers and electrical rooms. Feature: Knockouts include (1) 1/2 in end, (2) 1/2 in side, (1) 1/2 in bottom. Business Impact: Flexible routing and future expansion without replacing the enclosure. Application: Varied conduit routing in complex control schemes. Feature: Gangable design with ears enhances mounting versatility. Business Impact: Scalable enclosures for larger control architectures, enabling modular setups and easier maintenance. Application: Modular panel assemblies and multi-box installations. Feature: Material is steel with ears and standard dimensions. Business Impact: Durable, code-ready hardware that withstands industrial conditions and provides straightforward alignment during installation. Application: Harsh environments and busy plant floors. Feature: Certifications and location compatibility—NEC/CEC compliance, UL-listed, Ordinary/Non-Hazardous Locations. Business Impact: Regulatory confidence, safer installations, and fewer compliance questions on site. Application: Industrial facilities requiring strict electrical standards. Feature: Compact dimensions—2 in W × 3 in H × 2 in D—and 0.48 lb weight. Business Impact: Easier handling, reduced shipping costs, and simplified inventory management. Application: Quick deployment in constrained spaces and budget-conscious projects.
Get a Quick Quote for a Eaton TP130
Chat with us on WhatsApp - fast responses guaranteed
Need to speak with someone? We'll call you back within 2 hours during business hours
Interested in Eaton TP130?
Enquire Now
FAQs
The TP130 features end, side, and bottom knockouts all at 1/2 in, with dimensions of 2 in width, 3 in height, and 2 in depth. It weighs 0.48 lb and provides 10 cubic inches of internal capacity, suitable for compact terminations in Industrial panels.
Yes, the TP130 is intended for Ordinary/Non-Hazardous Locations and complies with NEC/CEC standards. It is UL-listed for steel switch boxes, ensuring regulatory compliance for safe electrical installations.
Yes, the TP130 is gangable, allowing multiple boxes to be combined for larger enclosures. This reduces the need for custom fabrication, simplifies mounting in multi-box assemblies, and speeds up panel builds in automation environments.
The TP130 weighs 0.48 lb and includes ears for secure mounting. Its 2x3x2 inch footprint makes it suitable for tight spaces in control panels and electrical rooms, while providing reliable mounting alignment during installation.
Available documents include Eaton’s specification sheet for TP130, the Crouse-Hinds steel switch boxes catalog page, and UL certification reports. These resources support design validation, compliance checks, and field installation planning.
