Eaton TP220 Switch Box - 12.5 cu in Capacity
Part Number: TP220
Quick Summary
The Eaton TP220 switch box is a rugged enclosure designed for reliable housing of control switches in industrial panels. This compact, gangable solution addresses the common challenge of cramped spaces and retrofit constraints by enabling easy expansion as your control system grows. It carries NEC/CEC compliance for ordinary locations and UL certification for steel switch boxes, with area classification suitable for non-hazardous environments. Coupled with a 3 in product depth, 2-1/2 in height, and a 12.5 cubic inch capacity, the TP220 delivers durable protection without sacrificing accessibility. Engineers will appreciate compatibility with 1/2 inch conduit entries and the F bracket setup, translating to faster installs and lower total cost of ownership.
Product Information
Extended Description
TP220 Eaton: Eaton Crouse-Hinds series Switch Box, (1) 1/2", F, set 1/2", Conduit (no clamps), 2-1/2", Steel, Gangable, 12.5 cubic inch capacity
Product Name
Eaton Crouse-Hinds series switch box
Catalog Number
TP220
UPC
786189102208
Product Length/Depth
3 in
Product Height
2.5 in
Product Width
2 in
Product Weight
0.64 lb
Area classification
Ordinary/Non-Hazardous Locations
Standards type
NEC/CEC
Depth
2-1/2"
Type
Gangable
Capacity
12.5 cubic in
Conduit/cable
Conduit (no clamps)
Bracket style
F, Set 1/2"
Bottom Knockouts
(1) 1/2 in
Material
Steel
Crouse-Hinds series Steel Switch Boxes catalog page
Steel Switch Boxes UL certification
Steel Switch Boxes UL certification
Steel Outlet Boxes for Electrical Systems
Steel Outlet Boxes for Electrical Systems
Feature: Steel construction provides rugged durability for harsh industrial environments. Business Impact: Reduces maintenance costs and extends service life of enclosure assets. Application: Control panels in manufacturing lines where dust, impact, and vibration are concerns. Feature: 12.5 cubic inch capacity with 3 in depth and 2 in width supports practical wiring space for standard switch configurations. Business Impact: Improves wiring efficiency and minimizes rework during panel updates. Application: Electrical protection and circuit control enclosures in machine rooms. Feature: Conduit (no clamps) and bottom knockout (one 1/2 in) with a 1/2 inch conduit entry option. Business Impact: Streamlines installation, saving time and labor in new builds and retrofits. Application: Quick-connect conduit runs in confined spaces. Feature: Gangable design with F bracket (Set 1/2 inch) enables future expansion. Business Impact: Scales with system growth without replacing boxes. Application: Modular panel builds in automation lines. Feature: NEC/CEC compliance and Ordinary/Non-Hazardous area classification plus UL certification. Business Impact: Reduces compliance risk and inspection cycles. Application: Industrial control panels requiring code-backed protection.
