Eaton TP5SQ50100-BLUE Outlet Box - NEC/CEC, Welded, Blue Painted
Part Number: TP5SQ50100-BLUE
Quick Summary
TP5SQ50100-BLUE outlet box from Eaton provides a durable enclosure for low-voltage wiring in industrial controls. In dense control panels, wiring congestion and limited space can slow installs and raise risk of miswiring. This box meets NEC/CEC compliance and is suitable for ordinary/non-hazardous locations, helping you stay code-compliant across facilities. Its welded galvanized steel body and blue-painted finish deliver long-term corrosion resistance while enabling quick visual identification in multi-circuit panels. With a generous 67 cubic inch capacity and thoughtfully arranged knockouts, it scales with evolving control requirements, reducing replacements and rework. When projects demand reliable enclosure performance without over-spending, TP5SQ50100-BLUE offers value through durable construction, flexible conduit options, and straightforward installation for low-voltage systems and industrial automation applications.
Product Information
Extended Description
TP5SQ50100-BLUE Eaton: Eaton Crouse-Hinds series outlet box, (3)- 1/2", (2) 3/4", 5", Blue painted, Conduit (no clamps), Welded, 2-7/8", Galvanized steel, (4) 1/2", (8) 1", 67.0 cubic inch capacity
Product Name
Eaton Crouse-Hinds series outlet box
Catalog Number
TP5SQ50100-BLUE
UPC
662276805873
Product Length/Depth
16 in
Product Height
6 in
Product Width
12 in
Product Weight
1.4 lb
Area classification
Ordinary/Non-Hazardous Locations
Standards type
NEC/CEC
Box size
5"
Capacity
67 cubic in
Depth
2-7/8"
Conduit/cable
Conduit (no clamps)
Construction
Welded
Side knockouts
(4) 1/2 in, (8) 1 in
Bottom Knockouts
(3) 1/2 in, (2) 3/4 in
Color
Blue painted
Material
Galvanized steel
Crouse-Hinds series Low Voltage flyer
5-Inch Steel Square Low Voltage Outlet Boxes and Covers Catalog Page
Steel Outlet Boxes - 5 in square, low voltage
Steel Outlet Boxes - 5 in square, low voltage
Feature: Welded galvanized steel construction provides robust mechanical strength and corrosion resistance. Business Impact: Reduces maintenance and replacement costs in harsh industrial environments, improving total cost of ownership. Application: Ideal for control panels and field enclosures in manufacturing facilities. Feature: 67 cubic inch capacity inside a 5-inch square box enables room for splices and modest circuit routing. Business Impact: Frees up cabinet space and minimizes the need for multiple boxes. Application: Low-voltage wiring, simple control circuits, and small automation deployments. Feature: Conduit (no clamps) design accelerates installation by minimizing required hardware and steps. Business Impact: Cuts labor time and material costs while preserving code compliance. Application: Fast-fit enclosures for panel builders and on-site assemblies. Feature: Knockout arrangement—(4) 1/2 in and (8) 1 in on the sides; (3) 1/2 in and (2) 3/4 in on the bottom. Business Impact: Flexible routing for conduits and cables, enabling cleaner installations. Application: Diverse wiring schemas in electrical cabinets. Feature: Color and finish—blue painted exterior on galvanized steel. Business Impact: Easy circuit identification and durable finish that resists weathering in non-hazardous indoor locations. Application: Multi-circuit installations and panel environments requiring quick visual cues. Feature: Dimensions and weight—16 in length, 12 in width, 6 in height; 1.4 lb weight. Business Impact: Predictable footprint and manageable weight for field mounting and handling. Application: Space-constrained installations and retrofits in industrial settings.
Get a Quick Quote for a Eaton TP5SQ50100-BLUE
Chat with us on WhatsApp - fast responses guaranteed
Need to speak with someone? We'll call you back within 2 hours during business hours
Interested in Eaton TP5SQ50100-BLUE?
Enquire Now
FAQs
Yes. The box features side knockouts of 1/2 in and 1 in (4 and 8 respectively) plus bottom knockouts of 1/2 in and 3/4 in (3 and 2), and it is designed for conduit without clamps. This combination supports common low-voltage wiring runs while maintaining regulatory compliance and clean, organized installs.
Key specs include a 5 inch box size, 67 cubic inch capacity, depth of 2-7/8 inches, overall dimensions of 16 in L x 12 in W x 6 in H, welded galvanized steel construction, blue painted finish, and side (4x 1/2 in; 8x 1 in) plus bottom (3x 1/2 in; 2x 3/4 in) knockouts. Weight is approximately 1.4 lb.
The TP5SQ50100-BLUE is specified for Ordinary/Non-Hazardous Locations and NEC/CEC compliance. It is not rated for hazardous or outdoor environments. For outdoor or hazardous-location applications, consider enclosures with appropriate IP ratings and hazard classifications and verify project requirements with a qualified electrical engineer.
Conduit without clamps reduces the number of installation parts and steps, speeding up assembly and simplifying field routing. With the TP5SQ50100-BLUE, you can route conduits directly into the pre-defined knockouts, maintain code compliance, and achieve a cleaner, faster installation—particularly valuable in crowded panels or retrofit projects.
The welded galvanised steel construction and long-term corrosion resistance translate to lower maintenance needs and longer service life, reducing replacement cycles. The generous 67 cu in capacity and flexible knockout arrangement minimize the need for additional enclosures, cutting inventory complexity and total cost of ownership for ongoing automation and control projects.
