Eaton TP7028 Weatherproof Outlet Box - NEMA 3R
Part Number: TP7028
Quick Summary
TP7028 weatherproof outlet box protects electrical terminations in outdoor or harsh industrial environments. It shields wiring from moisture and corrosion, reducing maintenance downtime in exposed conduit installations. This enclosure carries critical certifications, including NEMA 3R, NEC/CEC compliance, and UL Canadian certification, supporting safe operation in Ordinary/Non-Hazardous locations. By combining bronze finish with die-cast aluminum construction and a compact single-gang footprint, it delivers durable, easy-to-install protection for outdoor electrical projects while helping procurement teams simplify stocking and compliance.
Product Information
Extended Description
TP7028 Eaton: Eaton Crouse-Hinds series weatherproof outlet box, 17.0 cu in capacity, Bronze, 2" deep, Die cast aluminum, Single-gang, (4) 1/2" outlet holes, Rectangular
Product Name
Eaton Crouse-Hinds series weatherproof outlet box
Catalog Number
TP7028
UPC
662276949317
Product Length/Depth
4.54 in
Product Height
2.14 in
Product Width
2.78 in
Product Weight
0.56 lb
Area classification
Ordinary/Non-Hazardous Locations
Standards type
NEC/CEC
NEMA Rating
3R
Number of gangs
Single-gang
Depth
2"
Type
Rectangular
Outlet holes
(4) 1/2"
Capacity
17.0 cu in
Color
Bronze
Material
Die cast aluminum
Crouse-Hinds series Weatherproof portfolio catalog pages
Weatherproof Outlet Boxes and Covers Canadian certification
Weatherproof Outlet Boxes and Covers Canadian certification
TP7028 PDF drawing
TP7028 PDF drawing
Eaton Specification Sheet - TP7028
Capacity and size are optimized for single-gang installations: 17.0 cu in internal space with (4) 1/2" outlet holes, 4.54 in length, 2.14 in height, and 2.78 in width. This configuration provides sufficient space for terminations and conductors, enabling cleaner wiring and faster field terminations, which translates to reduced install time and fewer field rework issues in outdoor control panels or lighting enclosures. The die-cast aluminum construction finished in bronze delivers superior corrosion resistance and weather durability, lowering maintenance costs and extending service life in harsh environments. Its NEMA 3R rating and NEC/CEC compliance give confidence in outdoor performance, while Ordinary/Non-Hazardous location suitability reduces compliance overhead for typical industrial sites. The 2 in depth and single-gang footprint simplify mounting and retrofit projects, improving install efficiency. Availability of CAD drawings and spec sheets accelerates project design and procurement workflows, reducing design-to-install cycle times. At a compact 0.56 lb, the TP7028 remains field-friendly without sacrificing protective performance.
Get a Quick Quote for a Eaton TP7028
Chat with us on WhatsApp - fast responses guaranteed
Need to speak with someone? We'll call you back within 2 hours during business hours
Interested in Eaton TP7028?
Enquire Now
FAQs
TP7028 provides (4) 1/2" outlet holes and 17.0 cubic inches of internal space in a single-gang, rectangular enclosure. External dimensions are 4.54 in long, 2.14 in tall, and 2.78 in wide, with a 2" depth, supporting organized terminations for outdoor installations.
The TP7028 carries a NEMA 3R rating, is NEC/CEC compliant, is suitable for Ordinary/Non-Hazardous locations, and has UL Canadian certification documented for cross-border use, helping ensure safe, code-compliant outdoor installations.
Yes. The bronze die-cast aluminum TP7028 is designed for outdoor use, offering weather resistance and protection against moisture. With a NEMA 3R rating and non-hazardous location applicability, it is well-suited for outdoor controls, lighting enclosures, and rugged industrial applications.
TP7028 measures 4.54 inches in length, 2.14 inches in height, and 2.78 inches in width, with a depth of 2 inches. The enclosure weighs 0.56 pounds, making it manageable for field installations and mounting in restricted or tight spaces.
Eaton provides technical resources including the Crouse-Hinds weatherproof portfolio catalog pages, TP7028 PDF drawings and SLDDRW CAD files, and the Eaton specification sheet to support design, routing, and procurement activities.
