Eaton TPN-10 Telecommunication Fuse - 100 kAIC
Part Number: TPN-10
Quick Summary
TPN-10 telecommunication fuse protects sensitive telecom power circuits by interrupting faults quickly. This addresses common downtime and nuisance trips caused by mismatched protection devices in data centers and network racks. While the data sheet notes Not Applicable for Warranty and Compliances, the model delivers a robust 170 Vdc rating with 10 A capacity and a high 100 kAIC interrupt rating, reinforcing reliability in demanding environments. The non-indicating design minimizes panel clutter, and silver-plated terminals ensure durable, low-resistance connections. As you scale protection across mid-range telecom budgets, this fuse aligns with Eaton Bussmann series standards, simplifying procurement and field replacements while reducing total cost of ownership.
Product Information
Extended Description
TPN-10 Eaton: Eaton Bussmann series TPN telecommunication fuse, 170 Vdc, 10 A, 100 kAIC, Non Indicating, Current-limiting, Silver-plated terminal
Product Name
Eaton Bussmann series TPN telecommunication fuse
Catalog Number
TPN-10
UPC
051712196666
Product Length/Depth
0.56 in
Product Height
2 in
Product Width
0.56 in
Product Weight
0.5 lb
Warranty
Not Applicable
Compliances
Not Applicable
Amperage Rating
10 A
Interrupt rating
100 kAIC
Voltage rating
170 Vdc
Packaging type
Standard
Fuse indicator
Non-indicating
TPN-10~TELPOWER FUSE
TPN-10~TELPOWER FUSE
Bussmann series Fuseology
Eaton Specification Sheet - TPN-10
Feature: 170 Vdc voltage rating, 10 A amperage rating, and 100 kAIC interrupt rating. Business Impact: Delivers rapid fault clearing and high fault-current tolerance to protect DC telecom power circuits, minimizing equipment damage and downtime. Application: Ideal for data centers, network cabinets, and telecom power distribution units where fast, reliable protection is essential. Feature: Non-indicating fuse with standard packaging. Business Impact: Reduces panel indicators and simplifies installation in compact enclosures, lowering maintenance overhead and potential misreads during routine checks. Application: Enclosures with dense component density and minimalist signaling requirements in telecom rooms. Feature: Current-limiting and silver-plated terminals. Business Impact: Controls arc energy and ensures low-resistance, corrosion-resistant terminations for long-term reliability in industrial environments. Application: Harsh environment racks and DC power paths in data centers and industrial networks. Feature: Compact dimensions (0.56 in x 0.56 in footprint, 2 in height) and 0.5 lb weight. Business Impact: Easy retrofits and cross-bay replacements, reducing downtime during maintenance windows. Application: retrofit projects and new installations where space is at a premium. Feature: Compatibility with Bussmann series catalogs and standard packaging. Business Impact: Streamlines procurement, inventory management, and cross-referencing with existing protection schemes. Application: Enterprise networks and facilities with standardized Eaton Bussmann components. Industry insight: For engineers evaluating protection schemes, the TPN-10 provides predictable performance under DC fault conditions and scales well with other Bussmann series devices, delivering a balanced mix of protection, cost efficiency, and ease of use.
Get a Quick Quote for a Eaton TPN-10
Chat with us on WhatsApp - fast responses guaranteed
Need to speak with someone? We'll call you back within 2 hours during business hours
Interested in Eaton TPN-10?
Enquire Now
FAQs
To install the TPN-10, locate a suitable fuse holder designed for Bussmann series devices, align the fuse with the bus contacts, and secure the silver-plated terminals to the termination points. The non-indicating design simplifies panel layout, while the 170 Vdc rating and 10 A current rating ensure compatibility with standard telecom DC power rails. Verify enclosure clearance and follow site wiring practices for DC circuits.
The TPN-10 is specified as current-limiting, which means it quickly reduces let-through current when a fault occurs. This minimizes fault energy, reduces overheating risk for downstream conductors, and helps protect power supplies and wiring in telecom DC paths. This characteristic is especially valuable in data centers and network cabinets where rapid fault clearance preserves uptime and equipment life.
Yes. The TPN-10 is designed for telecom power circuits common in data centers, offering a 170 Vdc rating, 10 A capacity, and a 100 kAIC interrupt rating. Its current-limiting action and robust terminals support reliable protection of DC power distribution units, racks, and other critical infra, while its compact form simplifies integration in dense cabinets.
The provided data marks warranty and compliance fields as Not Applicable for this model. For region-specific certifications such as CE, IP, or SIL, consult Eaton’s official datasheets or contact the manufacturer to confirm current approvals for your installation and jurisdiction.
Expect reduced downtime due to rapid fault clearing and lower maintenance overhead thanks to the non-indicating design which minimizes on-panel signaling. The high interrupt rating (100 kAIC) and durable silver-plated terminals contribute to longer service life and lower replacement costs in telecom and data-center environments, delivering a favorable total cost of ownership over the protection circuit’s lifetime.
