Eaton TPN-20 Telecommunication Fuse - 100 kAIC
Part Number: TPN-20
Quick Summary
The Eaton TPN-20 telecommunication fuse protects DC telecom rails by delivering reliable overcurrent protection. Engineers often struggle with protecting sensitive telecom gear without triggering nuisance trips or adding bulky indicators. This entry lists a 170 Vdc rating, 20 A current, and a 100 kAIC interrupt capability with non-indicating construction. Note that warranty and compliance fields are listed as Not Applicable in this data, so please verify this device against the official Eaton datasheet for CE/UL or IEC certifications as applicable. By focusing on a compact footprint and high interrupt capability, the TPN-20 delivers value in quick-install telecom enclosures and data-center rack protection, reducing downtime and simplifying panel design for mid-to-large scale deployments.
Product Information
Extended Description
TPN-20 Eaton: Eaton Bussmann series TPN telecommunication fuse, 170 Vdc, 20 A, 100 kAIC, Non Indicating, Current-limiting, Silver-plated terminal
Product Name
Eaton Bussmann series TPN telecommunication fuse
Catalog Number
TPN-20
UPC
051712196741
EAN
5027590114066
Product Length/Depth
0.56 in
Product Height
2 in
Product Width
0.56 in
Product Weight
0.5 lb
Warranty
Not Applicable
Compliances
Not Applicable
Amperage Rating
20 A
Interrupt rating
100 kAIC
Voltage rating
170 Vdc
Packaging type
Standard
Fuse indicator
Non-indicating
TPN-20~TELPOWER FUSE
TPN-20~TELPOWER FUSE
Bussmann series Fuseology
Eaton Specification Sheet - TPN-20
Feature: 170 Vdc, 20 A, 100 kAIC rating with current-limiting action → Business Impact → Application: Provides fast fault interruption and limited arc energy, protecting telecom power rails and sensitive electronics in DC systems, leading to reduced downtime and lower replacement costs in data centers and network cabinets. Feature: Non-indicating, with silver-plated terminals → Business Impact → Application: Reduces indicator wiring needs and improves connection reliability in harsh environments, ideal for dense telecom racks and outdoor cabinets where space is at a premium. Feature: Compact footprint (0.56 in W, 0.56 in D, 2 in H) → Business Impact → Application: Enables higher pack density in control panels and telecom enclosures, accelerating installation in standardized fuse bases and minimizing panel redesigns. Feature: 20 A amperage with 170 Vdc rating → Business Impact → Application: Aligns to typical telecom DC rails, ensuring appropriate protection without nuisance trips during normal transients, suitable for rack-mount protection modules and Bussmann series integration. Feature: 100 kAIC interrupt rating → Business Impact → Application: Withstands high fault currents common in telecom and data-center PDN configurations, improving system reliability and meeting stringent protection requirements. Feature: Standard packaging and Bussmann series compatibility → Business Impact → Application: Simplifies stocking and procurement, simplifies field replacement, and supports scalable protection strategies across multiple sites.
Get a Quick Quote for a Eaton TPN-20
Chat with us on WhatsApp - fast responses guaranteed
Need to speak with someone? We'll call you back within 2 hours during business hours
Interested in Eaton TPN-20?
Enquire Now
FAQs
The TPN-20 is designed for standard telecom fuse bases used with Eaton Bussmann series. Verify the base footprint (compact 0.56 in width, 2 in height) and wire the 170 Vdc rail with appropriately rated conductors. Ensure proper isolation of DC rails during servicing and use external status indicators if monitoring is required since the fuse is non-indicating.
TPN-20 provides 170 Vdc voltage rating, 20 A amperage, and a 100 kAIC interrupt rating. The 100 kAIC rating means it can interrupt a fault current up to 100 kiloamps at its rated voltage, offering robust protection for high-energy telecom DC networks and reducing the risk of cascading failures.
Yes. Its 170 Vdc rating and 20 A capacity suit telecom DC rails in data centers, network equipment cabinets, and outdoor telecom enclosures. The current-limiting design minimizes fault energy, while the compact form factor supports dense panel layouts common in modern data-center and field deployments.
The provided data for this entry lists warranty and compliance as Not Applicable, and no certifications are specified here. For definitive CE/UL or IEC certifications, consult the official Eaton Bussmann datasheet or contact Eaton technical support to confirm current certification status for your region and application.
The TPN-20 offers robust protection with a high interrupt rating and current-limiting behavior, reducing fault energy and downtime. Silver-plated terminals improve long-term reliability in challenging environments, lowering maintenance costs and extending component life in telecom DC rails, which translates to a lower total cost of ownership across multi-site deployments.
