Eaton TPN-6 Telecommunication Fuse - 100 kAIC / 170 Vdc
Part Number: TPN-6
Quick Summary
The Eaton TPN-6 telecommunication fuse provides reliable overcurrent protection for telecom power rails and line cards. In dense racks and remote sites, nuisance trips or undersized interrupts drive costly downtime. Key specs include a 100 kAIC interrupt rating and 170 Vdc rating, with current-limiting action and silver-plated terminals. Certification status varies by region, so consult the Eaton datasheet for CE, UL/CSA, and other approvals applicable to your installation. This fuse supports reliable telecom protection with a compact form factor, straightforward installation, and predictable lifecycle costs, making it a solid choice for mission-critical networks. Its non-indicating design minimizes maintenance overhead in the field.
Product Information
Extended Description
TPN-6 Eaton: Eaton Bussmann series TPN telecommunication fuse, 170 Vdc, 6 A, 100 kAIC, Non Indicating, Current-limiting, Silver-plated terminal
Product Name
Eaton Bussmann series TPN telecommunication fuse
Catalog Number
TPN-6
UPC
051712196918
Product Length/Depth
0.56 in
Product Height
2 in
Product Width
0.56 in
Product Weight
0.5 lb
Warranty
Not Applicable
Compliances
Not Applicable
Amperage Rating
6 A
Interrupt rating
100 kAIC
Voltage rating
170 Vdc
Packaging type
Standard
Fuse indicator
Non-indicating
Bussmann series complete full line catalog no. 1007
Bussmann series complete full line catalog no. 1007
Bussmann series Fuseology
Eaton Specification Sheet - TPN-6
Feature: Current-limiting, non-indicating fuse with silver-plated terminals provides low contact resistance and fast fault interruption. Business Impact: Reduces arc energy and downstream damage, improving reliability and reducing maintenance cycles in telecom racks. Application: Use in telecom line cards, DC distribution modules, and power rails in data centers where reliability matters. Feature: 100 kAIC interrupt rating and 170 Vdc voltage rating. Business Impact: Ensures safe operation under worst-case fault conditions, meeting stringent telecom protection requirements and reducing the risk of cascading failures. Application: Suitable for high-energy DC telecom systems and equipment cabinets. Feature: Compact, standard-packaging form factor with critical dimensions (0.56 in W, 0.56 in D, 2 in H). Business Impact: Enables dense mounting and straightforward retrofits into existing Bussmann series holders, minimizing enclosure changes. Application: Telecom cabinets and panel-mount deployments with limited space. Feature: Silver-plated terminals for corrosion resistance. Business Impact: Improves long-term contact performance in challenging environments, reducing maintenance and replacement costs. Application: Outdoor or humid telecom installations and coastal facilities. Feature: Comprehensive technical documentation and datasheets from Eaton. Business Impact: Facilitates rapid integration into designs, easier procurement, and clear compliance messaging for audits. Application: Engineering design reviews, spare-part catalogs, and MRO workflows.
Get a Quick Quote for a Eaton TPN-6
Chat with us on WhatsApp - fast responses guaranteed
Need to speak with someone? We'll call you back within 2 hours during business hours
Interested in Eaton TPN-6?
Enquire Now
FAQs
TPN-6 is designed for Bussmann series fuse holders and standard telecom panels. With its compact dimensions (0.56 in W x 0.56 in D x 2 in H) and standard packaging, it fits dense rack environments and retrofits into existing fault-protection schemes without extensive enclosure changes. Ensure the holder and connectors match the silver-plated terminals for optimal contact performance.
The TPN-6 fuse provides a 6 A amperage rating, a 170 Vdc voltage rating, and a 100 kAIC interrupt rating. It is current-limiting, non-indicating, and features silver-plated terminals to maintain low contact resistance. These ratings make it suitable for protecting telecom DC power rails and line cards against high-energy faults.
Yes. The 170 Vdc voltage rating and 100 kAIC interrupt capacity are tailored for DC telecom environments, providing rapid fault interruption while protecting downstream components. It is well-suited for telecom power rails, line cards, and DC distribution modules where reliable protection and minimal downtime are essential.
Certification status can vary by region. For exact approvals such as CE, UL/CSA, and other region-specific certifications, refer to the Eaton TPN-6 datasheet and supplier documentation. Always verify the latest certifications with your procurement team before deploying in regulated environments.
The non-indicating design reduces field maintenance checks, while its current-limiting operation minimizes arc energy and protects downstream components, leading to less downtime and fewer component replacements. In addition, its compact form factor simplifies installation in tight telecom cabinets, contributing to lower installation costs and faster recovery in fault events.
