Eaton TPS-2 Telecommunication Fuse - 100 kAIC, CE RoHS
Part Number: TPS-2
Quick Summary
Eaton TPS-2 telecommunication fuse protects telecom circuits with fast current limiting, making it ideal for protecting power feeds, line cards, and data-paths in dense telecom enclosures. Engineers often contend with unexpected outages, nuisance trips, and slow replacement cycles that drive downtime and support costs. This device carries CE marking and RoHS compliance for European regulatory alignment, and its 100 kAIC interrupt rating with a 170 Vdc rating helps fast, dependable fault isolation in high-energy networks. As a member of the Eaton Bussmann series, TPS-2 offers compact installation, robust protection, and lower maintenance costs for mission-critical networks.
Product Information
Extended Description
TPS-2 Eaton: Eaton Bussmann series TPS telecommunication fuse, 170 Vdc, 2 A, 100 kAIC, Non Indicating, Current-limiting, Glass melamine tube, Silver-plated brass ferrules
Product Name
Eaton Bussmann series TPS telecommunication fuse
Catalog Number
TPS-2
UPC
051712197007
Product Length/Depth
0.56 in
Product Height
0.87 in
Product Width
0.56 in
Product Weight
0.2 lb
Warranty
Not Applicable
Compliances
CE Marked RoHS Compliant
Amperage Rating
2 A
Interrupt rating
100 kAIC
Voltage rating
170 Vdc
Packaging type
Standard
Fuse indicator
Non-indicating
Feature: 170 Vdc rating and 2 A current rating provide precise protection for DC telecom rails, reducing downstream damage. Business Impact: Improves uptime and limits energy exposure during faults, lowering repair time and operating costs. Application: DC-powered telecom power feeds, data-center rack power rails. Feature: 100 kAIC interrupt rating enables fast isolation of high-energy faults, protecting sensitive equipment from arcing and collateral damage. Business Impact: Enhanced protection for line cards and routers, reducing repair cycles and warranty claims. Application: Core telecom switching subsystems and central offices. Feature: Glass-melamine tube construction with silver-plated brass ferrules delivers durability and reliable mechanical connection. Business Impact: Longer service life in harsh environments and easier field maintenance. Application: Outdoor cabinets and indoor telecom enclosures subject to vibration and thermal cycling. Feature: Non-indicating fuse with current-limiting action minimizes insertion indicators while maximizing protective performance. Business Impact: Simplified panel design and reduced maintenance checks; faster fault diagnosis via system-level indicators. Application: Rack-mounted protection modules and distributed power architectures. Feature: CE Marked and RoHS compliant ensures regulatory alignment and environmental responsibility. Business Impact: Streamlined procurement and audit readiness, supporting compliance-driven deployments. Application: European and RoHS-compliant telecom deployments across data centers and service providers. Feature: Standard packaging and compatible fuse holders support quick replacement and installation. Business Impact: Accelerates technician throughput and reduces on-site downtime. Application: Field service, modular telecom enclosures, and retrofit projects.
Get a Quick Quote for a Eaton TPS-2
Chat with us on WhatsApp - fast responses guaranteed
Need to speak with someone? We'll call you back within 2 hours during business hours
Interested in Eaton TPS-2?
Enquire Now
FAQs
TPS-2 is designed for standard fuse holders with dimensions of 0.56 in length, 0.87 in height, and 0.56 in width. To install, orient the fuse into the holder until fully seated, ensuring a solid connection with the silver-plated brass ferrules. The unit is non-indicating, so verify circuit protection through host system indicators or monitoring software.
TPS-2 provides a 2 A amperage rating, a 170 Vdc voltage rating, and a 100 kAIC interrupt rating. It is a current-limiting, non-indicating fuse rated for DC telecom applications, designed to isolate faults quickly and protect downstream components.
Yes. With a 170 Vdc rating and 100 kAIC interrupt capacity, TPS-2 is well-suited for DC telecom rails in data centers and central offices. Its current-limiting action helps minimize arc energy and collateral damage, while its compact form simplifies integration in compact power distribution assemblies.
TPS-2 is CE marked and RoHS compliant, aligning with European regulatory requirements and environmental standards. This supports regulatory audits, supplier approvals, and procurement processes for multinational telecom deployments.
The current-limiting action reduces fault energy and downstream damage, lowering repair time and maintenance costs. Its robust construction and standard packaging also simplify stocking, replacements, and field service, contributing to lower total cost of ownership for telecom protection systems.
