Eaton TRIGSGF15W GFCI Receptacle - Isolated Ground
Part Number: TRIGSGF15W
Quick Summary
The Eaton GFCI receptacle TRIGSGF15W provides reliable ground fault protection for commercial outlets in industrial spaces. In busy facilities, nuisance trips and wiring incompatibilities can disrupt operations, increasing downtime and maintenance costs. This model is cULus Listed with NOM and supports isolated-ground GFCI requirements, delivering safe, code-compliant protection. Designed for flush mounting in decorator applications, it accepts #14-10 AWG wiring with back and side termination and features durable PBT/polycarbonate construction. For engineers and procurement teams, TRIGSGF15W combines reliable safety performance with installation flexibility and predictable lifecycle costs.
Product Information
Extended Description
TRIGSGF15W Eaton: Eaton GFCI receptacle,Tamper-resistant,Isolated ground,Self-test,#14-10 AWG,15A,Commercial,Extra heavy-duty industrial specification grade,Flush,125 V,Back and side wire,White,Brass,PBT/Polycarbonate,5-15R,2-pole,3-wire,grounding,Decorator
Product Name
Eaton GFCI receptacle
Catalog Number
TRIGSGF15W
UPC
032664767289
Product Length/Depth
1.31 in
Product Height
4.05 in
Product Width
1.36 in
Product Weight
0.4 lb
Certifications
cULus Listed NOM
Device type
Decorator duplex receptacle Receptacle
Type
Self-test
Amperage Rating
15A
Voltage rating
125V
Circuit interrupter type
GFCI
Contact material
Brass
Features
Isolated ground Tamper resistant
Application
Commercial
Device grade
Extra heavy-duty industrial specification grade
Wiring method
Back and side wire
Material
PBT
Allowable wire size
#14 - 10 AWG
NEMA configuration
5-15R
Environmental conditions
Tamper resistant
Number of wires
Three-wire
Mounting method
Flush
Number Of Poles
Two-pole
Style type
Decorator
Color
White
Combination type
Isolated ground GFCI
Design type
Isolated ground GFCI
Face/body material
PBT/polycarbonate
Receptacle type
Two-pole, three-wire, grounding
Installing and testing a GFCI receptacle instruction sheet
What is a Ground Fault Circuit Interrupting (GFCI) receptacle?
Eaton Specification Sheet - TRIGSGF15W
Eaton Specification Sheet - TRIGSGF15W
Feature: Self-test GFCI with tamper-resistant and isolated-ground; Business Impact: automatic self-testing reduces the risk of undetected ground faults and minimizes manual maintenance; Application: commercial outlets in busy facilities requiring dependable safety. Feature: Back and side wiring compatible with #14-10 AWG; Business Impact: faster terminations and easier retrofits; Application: new builds or renovations in industrial spaces. Feature: Isolated-ground GFCI with brass contact material; Business Impact: improved EMI/neutral isolation, better device performance for sensitive equipment; Application: data centers, control rooms, and laboratories. Feature: Extra heavy-duty industrial specification grade; Business Impact: extended service life under harsh conditions, lowering replacement costs; Application: high-traffic commercial environments. Feature: Decorator, flush-mount design with white finish; Business Impact: professional aesthetics and code-compliant installation that aligns with modern interiors; Application: offices, labs, and maintenance areas. Feature: 125 V, 15 A, two-pole, three-wire, 5-15R configuration; Business Impact: standard compatibility with common electrical infrastructure, reducing wiring complexity; Application: general-purpose commercial circuits. Feature: Material stability (PBT/polycarbonate); Business Impact: resistance to temperature, moisture, and chemical exposure, reducing failure rates; Application: industrial enclosures and wall boxes. All features collectively support faster commissioning, improved safety alignment with NEC requirements, and lower total cost of ownership over the product lifecycle.
Get a Quick Quote for a Eaton TRIGSGF15W
Chat with us on WhatsApp - fast responses guaranteed
Need to speak with someone? We'll call you back within 2 hours during business hours
Interested in Eaton TRIGSGF15W?
Enquire Now
FAQs
TRIGSGF15W supports back and side wiring for #14 - 10 AWG conductors, enabling flexible installation in flush-mount decorator outlets. This compatibility simplifies retrofits and new builds alike, reducing termination steps and eliminating the need for additional adapter kits.
Isolated-ground GFCI receptacles like TRIGSGF15W minimize ground-loop noise and EMI, improving performance for sensitive devices such as control systems and data equipment. In practice, this reduces interference, maintains signal integrity, and supports cleaner operation in data-rich or EMI-sensitive spaces.
Yes. The unit is cULus Listed with NOM, and is designed to meet commercial safety requirements for isolated-ground GFCI protection. Its 15A, 125V rating and two-pole three-wire configuration align with common NEC and local code expectations for decorator receptacles.
Plan for flush, decorator installation with back and side wiring to #14-10 AWG conductors. The TRIGSGF15W’s dimensions (approximately 4.05 in H x 1.36 in W x 1.31 in D) fit standard wall boxes, and its white PBT/polycarbonate body supports durable, space-efficient mounting in commercial interiors.
The combination of tamper resistance, self-test GFCI, isolated ground performance, and heavy-duty industrial specification grade reduces nuisance trips and maintenance costs while enhancing safety compliance. The result is lower replacement frequency and predictable performance in high-traffic commercial environments.
