Eaton U1M1R7 Meter Breakers - UL Listed, 10 kAIC
Part Number: U1M1R7
Quick Summary
Eaton U1M1R7 meter breakers provide reliable single-meter protection for three‑phase electrical systems in commercial and light industrial environments. Engineers often confront compatibility gaps and limited interrupt ratings when upgrading existing metering hardware, risking downtime and noncompliance. This unit is UL listed and EUSERC approved, rated for 10 kAIC, with aluminum bus and ANSI 61 gray finish for durable, code‑compliant use. Designed for single meter positions, it simplifies installation, reduces field wiring errors, and supports fast commissioning by panel builders. The galvanized steel chassis with ANSI 61 gray paint stands up to demanding environments, supporting surface and underground installations, and integrates with Eaton B-Line accessories for streamlined mounting and serviceability. This arrangement provides a reliable metering solution that reduces lifecycle costs and enhances project delivery.
Product Information
Extended Description
U1M1R7 Eaton: Eaton B-Line series meter breakers, Ring, 3R, ANSI 61 gray paint, 10 kAIC, Galvanized steel, 4, Single meter position, 100 A, Suface, 18, 120/240 V, Three-phase, None, Aluminum, Underground, (1) 100 A, 2P, 7
Product Name
Eaton B-Line series meter breakers
Catalog Number
U1M1R7
UPC
782051430806
Product Length/Depth
4.625 in
Product Height
24 in
Product Width
14 in
Product Weight
30 lb
Compliances
EUSERC Approved
Certifications
UL
Application
Single meter position
Amperage Rating
100 A
Voltage rating
120/240V
Phase
Three-phase
Interrupt rating
10 kAIC
Main circuit breaker
(1) 100 A, 2P
Bus material
Aluminum
Material
Galvanized steel
Finish
ANSI 61 gray paint
continuous rating meter socket jaws
continuous rating meter socket jaws
Eaton Specification Sheet - U1M1R7
Single-meter position design simplifies field wiring, reduces termination errors, and minimizes mis-termination risks during panel assembly. This configuration translates into faster commissioning and lower labor costs on commercial and light-industrial metering projects. It is well suited for commercial and light-industrial distribution panels that require a dedicated main-meter interval and straightforward expansion. UL listing and EUSERC approval represent essential standards, delivering compliance confidence and safer maintenance. The 100 A main and 10 kAIC interrupt rating further reduce fault exposure while supporting reliable service during peak demand. This combination makes it a dependable choice for utility-connected metering and code-driven installations across commercial facilities. Aluminum bus and galvanized steel enclosure with ANSI 61 gray finish deliver rugged durability in harsh environments. The construction resists corrosion and physical wear, extending service life in both surface-mounted and underground installations. Panel builders benefit from consistent dimensional footprint and compatibility with standard Eaton accessories. Compatibility with Eaton B-Line accessories enables flexible mounting, faster retrofits, and standardized field wiring. The design supports straightforward migration from legacy metering setups and reduces field configuration errors. Builders gain predictable lead times and smoother commissioning schedules on projects of any size. From a total cost of ownership perspective, the U1M1R7 delivers lower maintenance costs and longer replacement cycles. Its 120/240 V three-phase rating aligns with common commercial power distributions, improving compatibility with existing feeder layouts. Overall, electricians and panel hosts get a robust, code-compliant metering solution that scales with project demand.
Get a Quick Quote for a Eaton U1M1R7
Chat with us on WhatsApp - fast responses guaranteed
Need to speak with someone? We'll call you back within 2 hours during business hours
Interested in Eaton U1M1R7?
Enquire Now
FAQs
U1M1R7 is designed for a single meter position and Ring/Ringless configurations, compatible with Eaton B-Line accessories for streamlined mounting. It supports standard metering layouts and can be integrated into existing panel boards with minimal modification, reducing retrofit time and wiring errors while preserving system protection levels.
Key specs include a 100 A amperage rating, 120/240 V voltage rating, three‑phase configuration, and a 10 kAIC interrupt rating. The main circuit breaker is (1) 100 A, 2P, with aluminum bus and galvanized steel enclosure, UL listed and EUSERC approved for code-compliant metering installations.
Yes. The unit is designed for surface and underground installations, with a galvanized steel chassis and ANSI 61 gray finish that withstands harsh environments. Its robust construction supports durable performance in outdoor or recessed meter environments while maintaining reliable electrical protection.
U1M1R7 offers a compact form factor, compatible with standard Eaton B-Line accessories, which simplifies mounting and reduces field wiring complexity. Its single-meter position design lowers termination errors and accelerates commissioning, helping panel builders meet tight project timelines and improve overall install quality.
The product is UL listed and EUSERC approved, ensuring compliance with safety and metering standards for utility-connected installations. It also carries a 10 kAIC interrupt rating and ANSI 61 gray finish, aligning with common industry requirements for durable, code-compliant metering equipment.
