Eaton U2M2RP Meter Breakers - UL Listed 10 kAIC
Part Number: U2M2RP
Quick Summary
Eaton U2M2RP meter breakers provide secure single-meter protection for commercial and light industrial panels. Facing space constraints and the need for quick, code-compliant metering installs, this unit simplifies mounting and wiring while reducing field configuration. UL-listed and EUSERC approved, with an ANSI 61 gray finish, it also offers robust protection for 120/240 V single-phase systems. This combination supports faster deployments and lower total cost of ownership by minimizing labor, while remaining fully compatible with existing B-Line meter mounting equipment for reliable meter-ready protection in critical facilities.
Product Information
Extended Description
U2M2RP Eaton: Eaton B-Line series meter breakers, Ring, 3R, ANSI 61 gray paint 10 kAIC, Galvanized steel, 3, Single meter position, 200 A, Suface, 8, 120/240 V, Single-phase, None, Aluminum, Underground, (1) 200 A, 2P, 4
Product Name
Eaton B-Line series meter breakers
Catalog Number
U2M2RP
UPC
782051570359
Product Length/Depth
6 in
Product Height
25 in
Product Width
14 in
Product Weight
35 lb
Compliances
EUSERC Approved
Certifications
UL
Application
Single meter position
Amperage Rating
200 A
Voltage rating
120/240V
Phase
Single-phase
Interrupt rating
10 kAIC
Main circuit breaker
(1) 200 A, 2P
Bus material
Aluminum
Material
Galvanized steel
Finish
ANSI 61 gray paint
continuous rating meter socket jaws
continuous rating meter socket jaws
Eaton Specification Sheet - U2M2RP
Single-meter position design reduces enclosure footprint and simplifies metering installation, delivering faster project turnarounds and lower labor costs for service entrances in commercial and light industrial applications. 200 A, 120/240 V, single-phase rating matches common feeder requirements, enabling seamless integration with standard panels and reducing the need for bespoke solutions while maintaining series protection. 10 kAIC interrupt rating provides enhanced fault protection, improving safety margins for short-circuit events and helping meet utility and code requirements in busy facilities. Aluminum bus and galvanized steel enclosure offer durability with lighter weight, improving handling during install and ongoing resistance to corrosion in mixed environments. The ANSI 61 gray finish and UL listing, combined with EUSERC approval, support compliance and utility acceptance, while the 6 in depth, 14 in width, and 25 in height footprint fits common meter mounting enclosures and minimizes site rework. Compatibility with surface mounting and single meter configurations streamlines retrofits and new builds alike, delivering reliable metering protection with predictable maintenance needs.
Get a Quick Quote for a Eaton U2M2RP
Chat with us on WhatsApp - fast responses guaranteed
Need to speak with someone? We'll call you back within 2 hours during business hours
Interested in Eaton U2M2RP?
Enquire Now
FAQs
The U2M2RP is ideal for single-meter position installations in commercial and light-industrial panels. Its 200 A rating and 120/240 V single-phase capability match common service entrances, simplifying retrofit projects and new builds while reducing wiring complexity and labor costs.
This meter breaker provides a 200 A amperage rating, 120/240 V operation, single-phase configuration, and a 10 kAIC interrupt rating. These specifications deliver robust short-circuit protection for meter-based applications and comply with typical utility and safety guidelines.
Yes. The U2M2RP is designed for single-meter, meter-mounting configurations in Eaton B-Line systems. Its dimensions and mounting approach align with standard ring/3R mounting schemes, enabling straightforward integration with existing meter sockets and mounting hardware.
The unit is UL-listed and EUSERC approved, with an ANSI 61 gray finish. These certifications support utility acceptance and compliance with industry safety standards for meter mounting equipment.
Expect reduced installation labor due to its single-meter position design and straightforward mounting. Durability from galvanized steel and aluminum bus minimizes corrosion and lifecycle maintenance, while UL/EUSERC compliance helps protect against rework and regulatory delays in project delivery.
