Eaton UTH43269A3GCH Meter Socket 320A 600V - UL Listed
Part Number: UTH43269A3GCH
Quick Summary
Eaton meter socket UTH43269A3GCH provides a reliable service connection for commercial or residential electrical feeders. Installers often struggle with durable, code-compliant terminations that resist corrosion and mis-wiring. UL Listed certification supports safety compliance, while the 320A rating and 600 V capacity cover heavy residential and light commercial needs. This design streamlines installation for both new builds and retrofits, reducing field time and support costs while ensuring reliable meter-to-service connections. Its side-wired design and bottom feed simplify field wiring, while four jaws accommodate large conductors (#4-600 kcmil) for flexible service entry. UL Listed status helps procurement teams meet project timelines and simplify compliance documentation.
Product Information
Extended Description
UTH43269A3GCH Eaton: Eaton meter socket, 1-pos commercial or resi service, 320A, Under, Solid top, #4-600 kcmil, 4-jaw, 1-ph, #4-600 kcmil, Lever bypass, Gnd conn (#14-#2 Cu), Triplex, Side-wired, 3-wire, Ringless, Three ground terminals, 600 Vac
Product Name
Eaton meter socket
Catalog Number
UTH43269A3GCH
UPC
786685493893
Product Length/Depth
5.68 in
Product Height
26 in
Product Width
15 in
Product Weight
30 lb
Warranty
Eaton Selling Policy 25-000, one (1) year from the date of installation of the Product or eighteen (18) months from the date of shipment of the Product, whichever occurs first.
Certifications
UL Listed
Special features
Side-wired
Type
Single-position commercial or residential service
Amperage Rating
320A
Feed type
Bottom
Number of jaws
Four-jaw
Phase
Single-phase
Terminals
3 ground
Line
#4-600 kcmil
Load
#4-600 kcmil
Number of wires
Three-wire
Hub type
Solid top
Security
Ringless
Voltage rating
600 V
Bypass
Lever
Number of sockets
1
Feature → Business Impact → Application: The 320A amperage rating paired with a four-jaw, single-phase configuration enables direct connection to large conductors (#4-600 kcmil), supporting high-current service entries and reducing the need for oversized downstream gear in commercial and residential projects. Bottom feed design streamlines routing inside enclosures, cutting installation time and labor costs on site. Application: ideal for commercial service entrances and large-residence installations needing robust, code-compliant service sockets. Feature → Business Impact → Application: Side-wired, ringless ground terminals with three grounding points improve safety and reduce wiring errors, enhancing fault path clarity during maintenance. Application: suitable for tight spaces where clean ground terminations are essential in both retrofit and new builds. Feature → Business Impact → Application: Lever bypass and solid top hub enable quick service disconnection without compromising service continuity, reducing downtime during maintenance. Application: critical in facilities needing rapid, safe disconnections. Feature → Business Impact → Application: 600 VAC rating, compatibility with #4-600 kcmil lines, and UL Listed certification deliver compliance and long-term reliability, decreasing risk of rework. Application: essential for code-compliant, enterprise-grade electrical distribution. Feature → Business Impact → Application: Compact dimensions (5.68 in depth, 15 in width, 26 in height) with 30 lb weight support rugged field installation and easier mounting in space-constrained enclosures. Application: suitable for retrofit projects and new builds where footprint and weight matter.
Get a Quick Quote for a Eaton UTH43269A3GCH
Chat with us on WhatsApp - fast responses guaranteed
Need to speak with someone? We'll call you back within 2 hours during business hours
Interested in Eaton UTH43269A3GCH?
Enquire Now
FAQs
The UTH43269A3GCH is designed for single-position commercial or residential service entries, supporting bottom-fed wiring and four-jaw connections for #4-600 kcmil conductors. It is ideal for main service installations in multifamily buildings, small to mid-size commercial facilities, and retrofit projects where a robust, UL Listed meter socket is required to meet code and project timelines.
This meter socket offers a 320A amperage rating, 1-phase operation, and a 600 V voltage rating. It supports bottom feed with four jaws capable of accommodating #4-600 kcmil conductors for both line and load, and uses three grounding terminals. The design is ringless and side-wired to simplify wiring and improve safety on site.
UL Listed certification provides recognized safety validation, helping your project meet electrical codes and procurement requirements. It streamlines approval processes, supports quality expectations with a proven safety baseline, and reduces the risk of nonconformance during inspections, especially for commercial and residential service installations that require documented compliance.
Key installation advantages include bottom feed for easier routing inside enclosures, side-wired terminations for cleaner wiring layouts, and a lever bypass providing rapid service isolation without disconnecting the main supply. The solid top hub and ringless grounding also contribute to a safer, more durable installation suitable for busy industrial or utility-adjacent spaces.
The product carries Eaton’s warranty policy: one year from date of installation or eighteen months from shipment, whichever occurs first. Support includes access to Eaton documentation, specification sheets, and UL compliance materials, along with available technical assistance for installation questions, troubleshooting, and field service guidance.
