Eaton UTL1103G1P03 Power & Control Receptacle - IP68
Part Number: UTL1103G1P03
Quick Summary
Eaton UTL1103G1P03 power and control supply enables reliable inline connections for demanding industrial automation applications. Designers struggle with limited space, harsh environments, and the need for maintenance-friendly, IP-rated interfaces. Compliance with UL 1977 and IEC 61984, plus RoHS and REACH, supports global deployment and asset protection. As a 3G1 inline receptacle with 4 contacts, it reduces wiring complexity while delivering durable operation. This solution pairs a compact footprint with rugged materials, helping OEMs shorten assembly time and simplify serviceability. For best results, consider its overmolded accessory compatibility and push-pull coupling to accelerate field installation and minimize downtime.
Product Information
Extended Description
UTL1103G1P03 Eaton: Male in-line receptacle, grey, 3G1 layout; UTL1103G1P03
Product Name
Eaton Souriau UTL series uL/IEC power and control supply
Catalog Number
UTL1103G1P03
Product Length/Depth
28.6 mm
Product Height
28.6 mm
Product Width
28.6 mm
Product Weight
14.3 g
Compliances
UL 1977 (please contact us for more details) IEC 61984 (please contact us for more details)
Current rating
16 A UL 16 A IEC
Fitted with:
First mate last break capability Layout with ground cavity
Environmental conditions
RoHS Flammability rating UL94 V0 REACH
Environmental resistance
Resistant against mineral oil Resistant against gasoline UV resistant, no degradation after 5 years of exposure in natural environment Resistant against acid bath Resistant against basic bath Resistant against oil
Test current
16 A UL16 A IEC
Test voltage
600 V UL 500 V IEC
Connector accessory option
Only to be overmolded
Connector type
Receptacle
Contact delivery
Not delivered
Contact gender
Pin (Male)
Contact type
Crimp
Coupling type
Push-Pull
Degree of protection
IP68
Insert material
Polyamide
Layout
3G1
Shell material
Plastic
Shell size
10
Mating cycles
1000
Operating temperature - max
105 °C
Operating temperature - min
-40 °C
Receptacle type
In-Line Receptacle
Number Of Contacts
4
Number of cavity #16
4
Salt spray
1000 hour
Feature: 16 A current rating at 600 V (UL) / 500 V (IEC) with a 4-contact configuration. Business Impact: Enables reliable power delivery for motors and controllers while maintaining safety margins in demanding environments. Application: Robotics, conveyors, and automated panels where high current and compact form factor matter. Feature: IP68 enclosure with -40 °C to 105 °C operating range and salt spray resistance. Business Impact: Delivers long-term performance in dirty, wet, and high-traffic industrial settings, reducing maintenance and replacement costs. Application: Outdoor or wash-down environments where ingress protection is critical. Feature: First mate last break capability and ground cavity layout. Business Impact: Improves safety during disconnects and simplifies wiring with clear ground reference, reducing commissioning time. Application: Heavy machinery and machine tools requiring safe, visible disconnection. Feature: Push-Pull coupling and 3G1 layout with 4 cavities. Business Impact: Quick, tool-free mating and reliable alignment, lowering installation labor and downtime. Application: Modular assemblies in control cabinets and field-installable harnesses. Feature: Polyamide insert and plastic shell with UV, oil, and chemical resistance. Business Impact: Enhances durability and EMI stability while extending service life in harsh environments. Application: Automotive manufacturing cells and process automation lines. Feature: 1000 mating cycles and 28.6 mm footprint with compact dimensions. Business Impact: Predictable lifecycle performance and space-efficient design, enabling smaller enclosures and lower total system weight. Application: Robotic grippers, sensor arrays, and panel interfaces. Feature: RoHS and REACH compliance. Business Impact: Ensures global market access and regulatory alignment, reducing risk for cross-border programs. Application: International deployments in Europe, North America, and Asia. Feature: Connector accessory option only to be overmolded. Business Impact: Supports robust, vibration-resistant assemblies with minimized field rework. Application: OEM harness integration and encapsulated installations.
Get a Quick Quote for a Eaton UTL1103G1P03
Chat with us on WhatsApp - fast responses guaranteed
Need to speak with someone? We'll call you back within 2 hours during business hours
Interested in Eaton UTL1103G1P03?
Enquire Now
FAQs
The UTL1103G1P03 uses a push-pull coupling for quick mating and a 3G1 layout with four contacts. Ensure mating with compatible Souriau UTL-series receptacles and use the crimp contact method specified. Verify ground cavity alignment before engagement, and confirm IP68 seals are intact after assembly to maintain ingress protection during operation.
Ideal for automation panels, robotics, and field devices where reliable inline power and control supply is critical. Its compact 28.6 mm footprint, 4-contact arrangement, and 16 A current rating support motors, controllers, and distributed I/O in harsh environments, helping to minimize wiring complexity and installation time.
The connector complies with UL 1977 and IEC 61984, with RoHS and REACH adherence. It also features IP68 ingress protection and operates from -40 °C to 105 °C, making it suitable for global deployments in challenging industrial settings.
Yes. The connector specification notes an option that is intended to be overmolded, enabling robust, vibration-resistant assemblies. This simplifies harness integration and improves durability in machinery subject to movement and shocks.
Expect up to 1000 mating cycles, with materials chosen for UV resistance and oil/chemical exposure. The polyamide insert and plastic shell support long service life in industrial environments, while RoHS/REACH compliance helps minimize regulatory risk across regions.
