Eaton UTL6164W4S Power & Control Plug - IP68 rated
Part Number: UTL6164W4S
Quick Summary
UTL6164W4S is a rugged 8‑pole plug delivering UL/IEC power and control supply for harsh industrial environments, including automation plants, outdoor machinery, and wash-down areas. It minimizes downtime and wiring errors by providing a compact, reliable connection that withstands extreme conditions. The unit carries IEC 61984 and UL 1977 compliances, plus IP68 sealing and UL94 V0 flammability, supporting regulatory alignment and long service life. Designed for automation panels and field installations, it integrates with Souriau UTL accessories to simplify spare parts management and panel wiring, delivering trustworthy performance across demanding applications.
Product Information
Extended Description
UTL6164W4S Eaton: Female plug, 8 cavities, UTL6164W4S
Product Name
Eaton Souriau UTL series uL/IEC power and control supply
Catalog Number
UTL6164W4S
Product Length/Depth
47 mm
Product Height
40 mm
Product Width
30 mm
Product Weight
28 g
Compliances
IEC 61984 (please contact us for more details) UL 1977 (please contact us for more details)
Environmental conditions
Flammability rating UL94 V0 REACH RoHS
Number Of Poles
8-pole
Environmental resistance
UV resistant, no degradation after 5 years of exposure in natural environment Resistant against acid bath Resistant against gasoline Resistant against mineral oil Resistant against basic bath Resistant against oil
Connector accessory option
No backshell possibility
Connector type
Plug
Contact delivery
Not delivered
Contact gender
Socket (Female)
Contact type
Crimp
Coupling type
Push-Pull
Degree of protection
IP68
Insert material
Polyamide
Layout
4W4
Plug type
Straight Plug
Shell material
Plastic
Shell size
16
Mating cycles
1000
Operating temperature - max
105 °C
Operating temperature - min
-40 °C
Number Of Contacts
8
Number of cavity #16
8
Salt spray
1000 hour
Feature → Business Impact → Application: 8-pole, 4W4 layout with 8 cavities enables simultaneous power and control signals, reducing connector count and panel space while enabling robust data and actuation pathways in automation equipment. This translates to improved installation efficiency and lower assembly costs in packaging machines and robotic cells. Feature → Business Impact → Application: Push-Pull coupling provides quick, secure connections that resist accidental disconnection during high-vibration operations, cutting maintenance time and downtime in conveyor systems and outdoor machinery. Feature → Business Impact → Application: IP68 sealing, UV resistance, and UL94 V0 rating deliver reliable durability in wash-down environments, outdoor installations, and high-dust areas, reducing replacement cycles and warranty costs for industrial equipment. Feature → Business Impact → Application: Crimp contact termination supports fast, field-terminable assemblies with consistent electrical performance, improving repair turnaround times on field service calls for automation panels and machine tenders. Feature → Business Impact → Application: 1000 mating cycles and polyamide shell offer long-term reliability in demanding environments, enabling lifecycle integrity for critical control stations and remote I/O hubs. Feature → Business Impact → Application: Straight plug with 4W4 layout and 8 contacts simplifies mating with standard Souriau UTL backshells and accessories, speeding upgrades and retrofits in existing automation architectures.
Get a Quick Quote for a Eaton UTL6164W4S
Chat with us on WhatsApp - fast responses guaranteed
Need to speak with someone? We'll call you back within 2 hours during business hours
Interested in Eaton UTL6164W4S?
Enquire Now
FAQs
To install the UTL6164W4S, align the 4W4 layout with the mating connector, ensure the straight plug orientation, and use crimp terminals compatible with the 8 contacts. Push-Pull coupling allows quick engagement, while verifying IP68 sealing after assembly. Confirm compatibility with Souriau backshells and field-terminable crimp contacts to maintain environmental protection and mechanical integrity.
The UTL6164W4S operates from -40 °C to 105 °C, supporting extreme ambient conditions. It features UV resistance, IP68 sealing, and compliance with RoHS and UL94 V0 flammability, making it suitable for outdoor, wash-down, and high-dust industrial environments while maintaining electrical integrity and long-term performance.
Yes. The UTL6164W4S is designed to meet IEC 61984 and UL 1977 requirements, ensuring interoperability within UL-listed safety systems and international IEC-based assemblies. This compliance provides regulatory confidence for automated equipment, minimizes certification hurdles during integration, and supports safer, standardized connections across global facilities.
Absolutely. With IP68 sealing plus UV resistance and UL94 V0 flammability, the UTL6164W4S is well-suited for wash-down areas, outdoor installations, and environments with moisture ingress or chemical exposure. Its 8-pole configuration and crimped contacts maintain reliable electrical performance even under harsh cleaning regimes.
The connector offers up to 1000 mating cycles, a polyamide shell, and robust environmental resistance, delivering low maintenance and reduced replacement costs in automation projects. Its durable construction supports longevity in high-use applications such as packaging lines, robotic cells, and remote I/O networks, improving total cost of ownership and uptime metrics.
