Eaton UTS6JC8E3AS Connector - IP68/69K Waterproof
Part Number: UTS6JC8E3AS
Quick Summary
Eaton Souriau UTS series plastic waterproof IP68/69k connector provides rugged, sealed electrical connections for harsh industrial environments. Maintenance downtime and mis-seated connections are costly in wet, oily, or dusty plants. These connectors meet UL 1977 and IEC 61984 requirements, with CSA-C22.2 No.182.3 compliance and RoHS exemptions. Designed for quick field installation and long service life, they help reduce downtime and total cost of ownership in industrial automation and heavy equipment.
Product Information
Extended Description
UTS6JC8E3AS Eaton: Plastic plug, with cable gland backshell, with 3 female solder contacts, IP68/69K in unmated conditions; UTS6JC8E3AS
Product Name
Eaton Souriau UTS series plastic waterproof IP68/69k connector
Catalog Number
UTS6JC8E3AS
Product Length/Depth
54 mm
Product Height
22.4 mm
Product Width
22.4 mm
Product Weight
14.6 g
Compliances
ROHS exemption 6.c UL 1977 (please contact us for more details) CSA-C22.2 No.182.3 (please contact us for more details) IEC 61984 (please contact us for more details)
Current rating
7 A UL 7 A IEC
Environmental conditions
RoHS Flammability rating UL94 HB REACH
Environmental resistance
Resistant against mineral oil Resistant against basic bath Vibrations level Per IEC 60512-4 - from 10 to 2000 Hz Resistant against acid bath UV resistant, no degradation after 5 years of exposure in natural environment Resistant against gasoline Resistant against oil
Test current
7 A IEC 7 A CSA 7 A UL
Test voltage
250 V CSA 250 V UL 50 V IEC
Backshell angle
Straight
Backshell type
Sealing Gland
Connector accessory option
Delivered with connector
Connector orientation
N
Connector type
Plug
Contact delivery
Loaded
Contact gender
Socket (Female)
Contact plating
Gold
Contact type
Solder Cup
Coupling type
1/3 Bayonet
Degree of protection
IP68
Insert material
Neoprene
Layout
E3A
Plug type
Straight Plug
Shell material
Plastic
Shell size
8
Cable diameter - max
6.5 mm
Cable diameter - min
1.5 mm
Mating cycles
250
Operating temperature - max
105 °C
Operating temperature - min
-40 °C
Number Of Contacts
3
Number of cavity #20
3
Salt spray
500 hour
IP68/69K sealing with 1/3 bayonet coupling and a sealing gland backshell provides immersion and washdown resistance, which reduces ingress and maintenance in harsh environments. This translates to improved uptime for machinery in packaging lines, hydraulics, and outdoor equipment, while supporting compliance with industry sealing standards. The 3 contact Solder Cup contacts with gold plating offer reliable, corrosion-resistant connections that promote stable signal and power transfer, reducing contact fatigue and field failures in sensor and actuator wiring. The 7 A current rating and 250 V test voltage support common automation parts without overdesign, enabling cost-effective harnessing for control panels, motors, and actuators. Mating cycles of 250 support frequent field servicing and quick replacement, lowering lifecycle costs and downtime during maintenance windows. Operating temperature from -40 °C to 105 °C, UV resistance, and mineral oil resistance ensure long-term reliability in outdoor, mobile, and industrial environments, minimizing unexpected outages. The souriau UTS series compatibility with neoprene inserts and straight plug orientation delivers straightforward installation on existing cable glands, while the overall compact shell size and 54 mm length streamline panel design and routing in constrained spaces.
Get a Quick Quote for a Eaton UTS6JC8E3AS
Chat with us on WhatsApp - fast responses guaranteed
Need to speak with someone? We'll call you back within 2 hours during business hours
Interested in Eaton UTS6JC8E3AS?
Enquire Now
FAQs
The UTS6JC8E3AS uses a straight plug with a 1/3 bayonet coupling and a sealing gland backshell. It accepts cable diameters from 1.5 mm to 6.5 mm and ships with a connector ready for field mounting. This combination enables quick, tool-ready installations while maintaining IP68 protection in challenging environments.
It is rated for 7 A current (UL and IEC equivalents) and supports a 250 V maximum voltage. The contact arrangement is 3 sockets (solder cup) with gold plating, designed for stable signal transfer and corrosion resistance in automation wiring and sensor circuits.
Yes. The UTS6JC8E3AS carries IP68 protection (and 69K in unmated conditions), with UV resistance and mineral oil resistance. Its operating temperature range of -40 °C to 105 °C makes it suitable for outdoor machinery, washdown areas, and heavy-duty industrial settings where exposure to moisture and chemicals is common.
The connector aligns with UL 1977, IEC 61984, and CSA-C22.2 No.182.3. RoHS exemptions are noted, which facilitates global procurement and compliance in many industries. These certifications help ensure safety, interoperability, and regulatory readiness across markets.
With a sealing gland backshell, robust IP68/69K protection, and a 250 mating-cycle lifespan, the UTS6JC8E3AS supports frequent maintenance without compromising sealing performance. Its gold-plated contacts resist corrosion, reducing contact failures, while compact form factor and straightforward installation shorten repair times and improve overall equipment availability.
