Eaton UTS6JC8E3ASW Connector - IP68/69K
Part Number: UTS6JC8E3ASW
Quick Summary
The Eaton UTS6JC8E3ASW is a plastic waterproof IP68/69K connector designed for harsh industrial environments. Engineers often struggle with ingress, corrosion, and maintenance costs in washdown facilities and outdoor equipment. This interface meets IP68 (and IP69K) sealing standards, UL 1977 and CSA safety approvals, and RoHS exemptions, providing rugged reliability. With a 3-contact solder cup configuration and gold-plated contacts, it delivers low contact resistance in compact form, supporting efficient installations and long service life. Designed for the Souriau UTS series ecosystem, it helps streamline assemblies and improve uptime in industrial automation and equipment wiring projects.
Product Information
Extended Description
UTS6JC8E3ASW Eaton: Plastic plug, with cable gland backshell, with 3 female solder contacts, IP68/69K in unmated conditions, keying W; UTS6JC8E3ASW
Product Name
Eaton Souriau UTS series plastic waterproof IP68/69k connector
Catalog Number
UTS6JC8E3ASW
Product Length/Depth
54 mm
Product Height
22.4 mm
Product Width
22.4 mm
Product Weight
14.6 g
Compliances
ROHS exemption 6.c CSA-C22.2 No.182.3 (please contact us for more details) UL 1977 (please contact us for more details) IEC 61984 (please contact us for more details)
Current rating
7 A IEC 7 A UL
Environmental conditions
Flammability rating UL94 HB RoHS REACH
Environmental resistance
Resistant against acid bath Resistant against mineral oil Resistant against gasoline Vibrations level Per IEC 60512-4 - from 10 to 2000 Hz Resistant against basic bath Resistant against oil UV resistant, no degradation after 5 years of exposure in natural environment
Test current
7 A CSA 7 A IEC 7 A UL
Test voltage
250 V UL 250 V CSA 50 V IEC
Backshell angle
Straight
Backshell type
Sealing Gland
Connector accessory option
Delivered with connector
Connector orientation
W
Connector type
Plug
Contact delivery
Loaded
Contact gender
Socket (Female)
Contact plating
Gold
Contact type
Solder Cup
Coupling type
1/3 Bayonet
Degree of protection
IP68
Insert material
Neoprene
Layout
E3A
Plug type
Straight Plug
Shell material
Plastic
Shell size
8
Cable diameter - max
6.5 mm
Cable diameter - min
1.5 mm
Mating cycles
250
Operating temperature - max
105 °C
Operating temperature - min
-40 °C
Number Of Contacts
3
Number of cavity #20
3
Salt spray
500 hour
Feature: IP68/IP69K sealing and sealing gland backshell deliver unmated protection in washdown and outdoor environments. Business impact: minimizes ingress-related failures and reduces field maintenance, cutting downtime costs. Application: food processing lines, outdoor machinery, and washdown environments where reliability is critical. Feature: 7 A current rating with 3 contact positions and gold-plated solder cups. Business impact: supports reliable power and signal transfer without oversizing components, lowering total cost of ownership. Application: sensors, actuators, and control modules in automation systems. Feature: 1/3 bayonet coupling and straight plug with a sealing gland backshell. Business impact: quick, secure mating and easier field replacements, improving installation efficiency and minimizing commissioning time. Application: on-site wiring in confined or hard-to-reach panels. Feature: Operating temperature range -40 to 105 °C and UV resistance. Business impact: broad ambient tolerance reduces the need for additional enclosure heating or cooling and extends service life in harsh climates. Application: mining, construction, and outdoor equipment. Feature: Neoprene insert, plastic shell, and 8-size shell with 3 cavities. Business impact: compact footprint and robust housing support reliable, vibration-tolerant connections. Application: automation sockets and compact junctions in controlled environments. Feature: Compliance with RoHS, CSA, UL, and IEC 61984 standards. Business impact: simplifies regulatory approvals, supports global deployments, and reduces risk of non-compliance penalties. Application: regulated industrial installations and international projects.
Get a Quick Quote for a Eaton UTS6JC8E3ASW
Chat with us on WhatsApp - fast responses guaranteed
Need to speak with someone? We'll call you back within 2 hours during business hours
Interested in Eaton UTS6JC8E3ASW?
Enquire Now
FAQs
The UTS6JC8E3ASW is a straight plug in the UTS series featuring a sealing gland backshell and 1/3 bayonet coupling. It ships with a connector and sealing backshell, accommodates 3 female solder contacts (3 cavities), and is designed to mate with Souriau UTS receptacles of the same shell size to ensure IP68 performance and reliable field service.
Key electrical specs include a current rating of 7 A (IEC and UL), test current of 7 A, and test voltage of 250 V (UL/CSA) or 50 V (IEC). The contact arrangement provides 3 cavities with gold-plated solder cups for low resistance and corrosion resistance, suitable for moderate power and signal applications in automation.
It supports operating temperatures from -40 °C to 105 °C and carries IP68 sealing (with IP69K capability in unmated conditions). The housing and neoprene insert offer UV resistance and oil/chemical compatibility, making it suitable for washdown facilities, outdoor machinery, mining, and other demanding industrial settings.
The connector complies with RoHS exemptions, UL 1977, CSA-C22.2 No.182.3, and IEC 61984, reflecting adherence to electrical safety, performance, and environmental standards. These certifications support global deployment, ease regulatory approvals, and reduce risk for regulated industries such as automation, food processing, and heavy equipment.
Plan for a straight plug with a sealing gland backshell and 1/3 bayonet coupling. Cable diameter range is 1.5 to 6.5 mm, and the assembly length is 54 mm with a width of 22.4 mm. Ensure correct mating with compatible UTS components, verify the 3-cavity arrangement, and account for 250 mating cycles in maintenance planning.
