Eaton UTS6JC8E3ASX Connector IP68/69K
Part Number: UTS6JC8E3ASX
Quick Summary
The Eaton UTS6JC8E3ASX Connector provides a rugged IP68/69K waterproof connection for industrial equipment. Moisture ingress and unreliable seals routinely limit uptime in outdoor, damp, or high-vibration environments. Compliant with IEC 61984 and UL 1977, with ROHS exemption 6.c and IP68 protection, it offers dependable connectivity. The compact 54 mm length and 3-contact configuration reduce wiring complexity while gold-plated contacts resist corrosion. Designed for automation engineers and procurement teams, it supports reliable, maintenance-light operation across rugged industrial connectors and sealed plug ecosystems.
Product Information
Extended Description
UTS6JC8E3ASX Eaton: Plastic plug, with cable gland backshell, with 3 female solder contacts, IP68/69K in unmated conditions, keying X; UTS6JC8E3ASX
Product Name
Eaton Souriau UTS series plastic waterproof IP68/69k connector
Catalog Number
UTS6JC8E3ASX
Product Length/Depth
54 mm
Product Height
22.4 mm
Product Width
22.4 mm
Product Weight
14.6 g
Compliances
IEC 61984 (please contact us for more details) CSA-C22.2 No.182.3 (please contact us for more details) ROHS exemption 6.c UL 1977 (please contact us for more details)
Current rating
7 A IEC 7 A UL
Environmental conditions
Flammability rating UL94 HB REACH RoHS
Environmental resistance
Resistant against acid bath Resistant against mineral oil UV resistant, no degradation after 5 years of exposure in natural environment Resistant against oil Resistant against gasoline Resistant against basic bath Vibrations level Per IEC 60512-4 - from 10 to 2000 Hz
Test current
7 A CSA 7 A UL 7 A IEC
Test voltage
250 V CSA 250 V UL 50 V IEC
Backshell angle
Straight
Backshell type
Sealing Gland
Connector accessory option
Delivered with connector
Connector orientation
X
Connector type
Plug
Contact delivery
Loaded
Contact gender
Socket (Female)
Contact plating
Gold
Contact type
Solder Cup
Coupling type
1/3 Bayonet
Degree of protection
IP68
Insert material
Neoprene
Layout
E3A
Plug type
Straight Plug
Shell material
Plastic
Shell size
8
Cable diameter - max
6.5 mm
Cable diameter - min
1.5 mm
Mating cycles
250
Operating temperature - max
105 °C
Operating temperature - min
-40 °C
Number Of Contacts
3
Number of cavity #20
3
Salt spray
500 hour
Feature: IP68/69K sealing with a sealing gland backshell, 3 female solder contacts, straight plug design. Business impact: protects against moisture and dust, minimizes unexpected downtime, enables outdoor and wash-down installations. Application: outdoor machinery, conveyors, and mobile equipment. Feature: 7 A current rating at up to 250 V with gold-plated solder cups. Business impact: supports robust power delivery with low contact resistance, reducing heat buildup and failures. Application: motor drives, sensors, and control panels in demanding environments. Feature: 54 mm product length with 22.4 mm width and 22.4 mm height, weight 14.6 g. Business impact: compact form factor enables tight panel integration and lightweight assemblies, lowering shipping and installation costs. Application: compact automation enclosures and modular systems. Feature: 1/3 bayonet coupling and backshell straight orientation. Business impact: quick mating and reliable sealing with minimal torque, speeding maintenance. Application: field service and modular automation lines. Feature: Insert material Neoprene and Shell material Plastic with gold plating on contacts. Business impact: improved chemical resistance and longevity in harsh plants. Application: wet, oily, or UV-exposed environments. Feature: Mating cycles 250 and operating temperature range -40 °C to 105 °C. Business impact: predictable lifecycle, reduced replacement cycles, and resilience to temperature swings. Application: automotive plants, food and beverage lines, and outdoor equipment.
