Eaton UTS718MPN UTS Series Connector - IP68/69K
Part Number: UTS718MPN
Quick Summary
The Eaton Souriau UTS718MPN is a plastic waterproof IP68/69K connector for rugged fiber optic links in harsh industrial settings. Field installations often suffer from moisture ingress, vibration, and seal failures, leading to downtime and maintenance costs; this receptacle design addresses those pain points with a robust jam nut interface and seal integrity. Compliance-rich options include IEC 61984, UL 1977, and CSA C22.2 No.182.3, ensuring market-ready reliability. For procurement and engineering teams, the combination of IP68/69K protection and durable materials translates to reduced service interruptions and predictable performance across harsh environments—while maintaining ease of integration with MPO layouts and standard mounting practices.
Product Information
Extended Description
UTS718MPN Eaton: Plastic jam nut receptacle, without backshell, 1 fiber contacts, IP68/69K; UTS718MPN
Product Name
Eaton Souriau UTS series plastic waterproof IP68/69k connector
Catalog Number
UTS718MPN
Product Length/Depth
40.4 mm
Product Height
41.3 mm
Product Width
41.3 mm
Product Weight
14.8 g
Compliances
IEC 61984 (please contact us for more details) CSA-C22.2 No.182.3 (please contact us for more details) UL 1977 (please contact us for more details)
Environmental conditions
Flammability rating UL94 V0 REACH RoHS Fire and smoke rating I2F3 according to NFF 16101 and NFF 16102 Fire & Smoke
Environmental resistance
UV resistant, no degradation after 5 years of exposure in natural environment Resistant against acid bath Resistant against gasoline Resistant against mineral oil Vibrations level Per IEC 60512-4 - from 10 to 2000 Hz Resistant against oil Resistant against basic bath
Connector accessory option
Not delivered, to be ordered separately
Connector orientation
N
Connector type
Receptacle
Contact delivery
Not delivered
Contact type
Fiber Optic
Coupling type
1/3 Bayonet
Degree of protection
IP68
Insert material
Polyamide
Layout
MPO
Shell material
Plastic
Shell size
18
Mating cycles
250
Operating temperature - max
105 °C
Operating temperature - min
-40 °C
Receptacle type
Jam Nut Receptacle
Number Of Contacts
1
Nut material
Aluminium
Salt spray
500 hour
Feature: IP68/IP69K rated plastic housing with jam-nut receptacle. Business Impact: Delivers proven ingress protection and secure mounting, reducing field repair frequency and enabling quicker installs. Application: Outdoor industrial equipment and mobile machinery where exposure to water, dust, and vibration is routine. Feature: One fiber contact in a compact 40.4 mm length housing. Business Impact: Minimizes footprint in crowded harnesses while preserving signal integrity for single-channel fiber links. Application: Tight panel installations and compact control cabinets in automated systems. Feature: Polyamide insert and plastic shell with aluminium nut. Business Impact: Combines chemical resistance and durable coupling with lightweight, corrosion-resistant hardware to lower lifecycle costs. Application: Harsh chemical environments, oil-and-gas fields, and outdoor automation. Feature: Operating temperature range -40 to 105 °C and environmental resistance (UV, acid, gasoline, mineral oil). Business Impact: Enables year-round operation in extreme climates and behind equipment with wide thermal cycling, reducing spare part needs. Application: Outdoor enclosures, mobile equipment, and industrial plants with temperature swings. Feature: 1 contact, MPO layout, 1/3 bayonet coupling, and 250 mating cycles. Business Impact: Ensures repeatable mating/demating with predictable lifecycle, lowering maintenance downtime. Application: High-density fiber networks in machinery, robotics, and process automation. Feature: Compliance scope including IEC 61984, UL 1977, and CSA C22.2 No.182.3. Business Impact: Simplifies regulatory qualification and vendor due diligence for global projects. Application: Medical, automotive-adjacent, and heavy industry integrators seeking standards-aligned components.
Get a Quick Quote for a Eaton UTS718MPN
Chat with us on WhatsApp - fast responses guaranteed
Need to speak with someone? We'll call you back within 2 hours during business hours
Interested in Eaton UTS718MPN?
Enquire Now
FAQs
The UTS718MPN is designed for MPO layout configurations and uses a jam nut receptacle for secure mounting. This combination simplifies panel integration, supports dense fiber routing, and reduces misalignment risks during mating. When selecting mating hardware, ensure thread compatibility and proper seal seating to maintain IP68/69K performance in harsh environments.
This connector operates from -40 °C to 105 °C and features UV resistance, as well as chemical and oil resistance (acid, gasoline, mineral oil). The environmental rating supports outdoor and industrial deployments, including exposure to vibrations (per IEC 60512-4) and challenging interfaces, helping to prevent performance degradation over time.
Yes. The IP68/69K rated plastic housing, along with a robust jam-nut receptacle and MPO layout, makes it suitable for outdoor industrial enclosures and mobile machinery. Its aluminum nut, polyamide insert, and epoxy-free design provide durability under vibration, temperature changes, and harsh cleaning regimes typical in outdoor manufacturing and field service.
The product lists IEC 61984, UL 1977, and CSA C22.2 No.182.3—standards commonly required for safety, electrical, and telecom components. These certifications streamline supplier qualification, facilitate regional approvals, and support a quicker path to certification for equipment assemblies that incorporate the UTS718MPN.
With a mating cycle rating of 250 and a corrosion-resistant aluminium nut, you can anticipate reliable, repeatable connections over many installation/reinstallation cycles. The seal integrity, IP68/69K protection, and resistance to environmental contaminants reduce preventative maintenance needs and minimize unexpected downtime in aging fleets or high-usage automation lines.
