Eaton UTS7GJC128P Connector - IP68/69K 8-contact Receptacle
Part Number: UTS7GJC128P
Quick Summary
Eaton UTS7GJC128P connector is a waterproof electrical connector for harsh-environment machinery and control panels. That means reliable performance in moisture-prone outdoor installations where moisture ingress, vibration, and contamination threaten uptime. Certified to UL 1977, CSA-C22.2 No.182.3, and IEC 61984, it aligns with global safety and interoperability standards. Its IP68 rating and IP69K compatibility protect against dust and heavy water exposure, while the jam-nut receptacle design supports secure, field-serviceable mating. Using the Souriau UTS series in automation projects reduces maintenance costs and extends mean time between outages, especially on rugged industrial equipment. This combination of performance, compatibility, and ease of installation delivers tangible business value to OEMs and end users.
Product Information
Extended Description
UTS7GJC128P Eaton: Plastic jam nut receptacle, with cable gland and grommet backshell, for 8 male contacts, IP68/69K; UTS7GJC128P
Product Name
Eaton Souriau UTS series plastic waterproof IP68/69k connector
Catalog Number
UTS7GJC128P
Product Length/Depth
76.7 mm
Product Height
31.8 mm
Product Width
31.8 mm
Product Weight
31.2 g
Compliances
CSA-C22.2 No.182.3 (please contact us for more details) UL 1977 (please contact us for more details) IEC 61984 (please contact us for more details)
Current rating
10 A UL 10 A IEC
Fitted with:
First mate last break capability(optional) Last mate first break capability(optional)
Environmental conditions
RoHS Flammability rating UL94 V0 Fire & Smoke Fire and smoke rating I2F3 according to NFF 16101 and NFF 16102 REACH
Environmental resistance
Resistant against mineral oil Resistant against oil UV resistant, no degradation after 5 years of exposure in natural environment Resistant against acid bath Resistant against gasoline Vibrations level Per IEC 60512-4 - from 10 to 2000 Hz Resistant against basic bath
Test current
10 A IEC 10 A UL 7 A CSA
Test voltage
500 V CSA 80 V IEC 500 V UL
Backshell angle
Straight
Backshell type
Sealing Gland
Connector accessory option
Delivered with connector
Connector orientation
N
Connector type
Receptacle
Contact delivery
Not delivered
Contact gender
Pin (Male)
Contact type
Crimp
Coupling type
1/3 Bayonet
Degree of protection
IP68
Insert material
Polyamide
Shell material
Plastic
Shell size
12
Cable diameter - max
12 mm
Cable diameter - min
3 mm
Mating cycles
250
Operating temperature - max
105 °C
Operating temperature - min
-40 °C
Receptacle type
Jam Nut Receptacle
Number Of Contacts
8
Number of cavity #16
8
Nut material
Aluminium
Salt spray
500 hour
Feature → Business Impact → Application: IP68/IP69K waterproof sealing with 8-pin jam-nut receptacle ensures reliable operation in wet, dusty, and vibration-prone environments, reducing unscheduled downtime in outdoor machinery and process lines; Application: heavy equipment, outdoor automation panels, wind or rain-exposed installations. Feature → Business Impact → Application: 1/3 Bayonet coupling enables quick mating and secure retention, speeding field wiring and minimizing installation torque requirements; Application: assembly lines, robotics cells, and mobile equipment. Feature → Business Impact → Application: Crimp 8-contact configuration with a 10 A rating delivers robust electrical performance with low contact resistance, supporting dependable sensing and control signals; Application: motor starters, sensors, and I/O modules. Feature → Business Impact → Application: Cable diameter range from 3 to 12 mm and straight backshell with sealing gland simplify harness design and reduce mis-mating risk; Application: panel builds and harnessed equipment. Feature → Business Impact → Application: Polyamide insert and plastic shell provide UV resistance, RoHS compliance, and flame retardancy (UL94 V0), lowering risk in sun-exposed or heated environments; Application: outdoor cabinets and process enclosures. Feature → Business Impact → Application: 250 mating cycles and 105 °C operating max temperature extend service life and enable higher uptime in demanding automation and control systems; Application: robotic arms, conveyors, and packaging machinery.
Get a Quick Quote for a Eaton UTS7GJC128P
Chat with us on WhatsApp - fast responses guaranteed
Need to speak with someone? We'll call you back within 2 hours during business hours
Interested in Eaton UTS7GJC128P?
Enquire Now
FAQs
Installation requires using the jam-nut receptacle with the included sealing gland and grommet backshell. Ensure cable diameter is within 3–12 mm, tighten the jam nut to specification, and verify backshell engagement for full IP68 protection. These steps minimize ingress paths and maximize long-term moisture resistance in harsh environments.
The connector is rated 10 A for UL and IEC contexts and carries 8 crimp contacts arranged for a robust 8-pin configuration. The combination of contact design, crimp termination quality, and tight backshell sealing ensures reliable current delivery and signal integrity in automation and sensing networks.
Yes. The UTS7GJC128P uses a standard Souriau UTS series interface, including a Sealing Gland backshell and jam-nut receptacle. This compatibility simplifies accessory selection, reduces replacement lead times, and supports consistent sealing performance across mixed equipment in an installation.
The product complies with UL 1977, CSA-C22.2 No.182.3, and IEC 61984, addressing safety, interconnectivity, and international acceptance in electrical connectors. This helps ensure compliance in North American and international control systems and supports system-level certifications for industrial equipment.
ROI comes from reduced maintenance, fewer field failures, and longer mean time between outages due to IP68/69K sealing and rugged materials. The 250 mating cycles and wide operating temperature range enable longer service life in outdoor enclosures and automated lines, lowering replacement costs and downtime in mission-critical processes.
