Eaton V2PC22 Photocell - Hazardous/Classified Locations
Part Number: V2PC22
Quick Summary
Eaton V2PC22 photocell provides reliable light control for field-installed fixtures in hazardous locations. Engineers and procurement teams often struggle with unreliable dusk-to-dawn sensing and difficult wiring in rugged environments. The device carries NEC/CEC compliance and a Class I, Division 2 hazardous rating within Hazardous/Classified Locations, offering peace of mind for compliant installations. Designed for LMV, DMV, VMV, VMV high wattage, and FMV luminaires, it enables straightforward retrofits and consistent performance. By focusing on field-installable wiring and robust sensing, this solution reduces maintenance calls while delivering energy savings and safer outdoor and industrial lighting control.
Product Information
Extended Description
V2PC22 Eaton: Eaton Crouse-Hinds series V2PC photocell, 1.8A, 50/60 Hz, Photocell for field installation in lighting fixtures, Used with LMV, DMV, VMV, VMV high wattage, FMV series luminaires, 208-240 Vac
Product Name
Eaton Crouse-Hinds series V2PC photocell
Catalog Number
V2PC22
UPC
782274709369
Product Length/Depth
3.9 in
Product Height
3.1 in
Product Width
4.3 in
Product Weight
0.35 lb
Area classification
Hazardous/Classified Locations
Standards type
NEC/CEC
NEC hazardous rating
Class I, Division 2
Type
Photocell for field installation in lighting fixtures
Voltage rating
208-240 Vac
Frequency rating
50/60 Hz
Amperage Rating
1.8A
Used with
LMV, DMV, VMV, VMV high wattage, FMV series luminaires
Crouse-Hinds series Photocells catalog page
Photocells for Champ HID and Fluorescent Hazardous Area Light Fixtures Canadian certification
Photocells for Champ HID and Fluorescent Hazardous Area Light Fixtures Canadian certification
IF 1271 - V2PC Integral Photocell Kit for DMV, VMV, N2MV and FMV Fixtures
Eaton Specification Sheet - V2PC22
Feature: Field-installation photocell simplifies retrofit projects and reduces field labor. Benefit: Faster installs with fewer site visits, lowering total cost of ownership while maintaining reliable dusk-to-dawn control. Application: Works with LMV, DMV, VMV, VMV high wattage, and FMV luminaires for industrial facilities. Feature: 208-240 Vac operation at 50/60 Hz supports standard lighting circuits. Benefit: Seamless integration with existing power distribution and fewer wiring errors. Application: Retrofit projects in warehouses and plants where consistent phase voltage is essential. Feature: 1.8 A amperage rating enables control of high-wattage luminaires without overloading. Benefit: Enables energy-efficient operation and longer lamp life. Application: High-fidelity night lighting for hazardous locations. Feature: NEC/CEC compliance with Class I, Division 2 rating. Benefit: Regulatory alignment reduces compliance risk and audit findings. Application: Hazardous locations such as chemical plants and refineries. Feature: Compact dimensions and field-install-ready design (3.9 in L, 3.1 in H, 4.3 in W; 0.35 lb). Benefit: Easy installation in confined fixtures and retrofit compatibility with existing housings. Application: Field retrofits in LMV/DMV/VMV/FMVs in constrained spaces.
Get a Quick Quote for a Eaton V2PC22
Chat with us on WhatsApp - fast responses guaranteed
Need to speak with someone? We'll call you back within 2 hours during business hours
Interested in Eaton V2PC22?
Enquire Now
FAQs
The V2PC22 is a field-installation photocell designed to drop into compatible luminaires such as DMV/VMV families. Follow IF 1271 installation guidelines and Eaton's wiring diagrams to connect line, load, and sensing leads. Ensure power is off during installation and verify 208-240 Vac supply and 50/60 Hz compatibility. The compact form factor fits standard housings, simplifying retrofits in industrial settings.
The V2PC22 operates at 208-240 Vac with a frequency rating of 50/60 Hz and a current rating of 1.8 A. It is designed for field installation in lighting fixtures and is suitable for high-wattage VMV luminaires. These specs support reliable dusk-to-dawn control while minimizing nuisance trips and false starts.
Yes. The V2PC22 carries NEC/CEC compliance with a Class I, Division 2 hazardous rating and is intended for Hazardous/Classified Locations. This makes it appropriate for industrial environments such as chemical plants and other areas requiring protective electrical classifications.
This photocell is used with LMV, DMV, VMV, VMV high wattage, and FMV series luminaires. Confirm compatibility with your fixture model and review Eaton's IF1271 and datasheets to ensure proper integration and reliable sensing in your application.
By enabling field-installable dusk-to-dawn control on hazardous-location fixtures, the V2PC22 reduces retrofit time and maintenance costs, improves energy efficiency, and ensures regulatory compliance with NEC/CEC standards and Class I Division 2 ratings. This translates to lower lifecycle costs and improved lighting reliability in plants and facilities.
