Eaton WD3090F-LLN Portable Outlet Box - Extra Depth
Part Number: WD3090F-LLN
Quick Summary
Eaton WD3090F-LLN is a non-metallic portable outlet box designed for rugged, single-receptacle connections in harsh industrial environments. Field installations often suffer from moisture ingress, incorrect box sizing, and limited interior space for wiring, which slows progress and raises risk. Certifications are provided by the manufacturer; verify regional requirements to ensure your project specs are met. Constructed with Alcryn and Valox and rated for -32 to 176°F, this enclosure supports reliability when paired with compatible Eaton outlets, covers, and accessories. By choosing a clearly visible yellow box with extra depth feed-through, you gain installation efficiency and long-term operational uptime.
Product Information
Extended Description
WD3090F-LLN Eaton: Eaton non-metallic portable outlet box, Extra depth feed through, Yellow, Single receptacle, Alcryn and Valox, 1.56 in diameter opening, -32° to 176°F
Product Name
Eaton non-metallic portable outlet box
Catalog Number
WD3090F-LLN
UPC
032664699917
Product Length/Depth
2.5 in
Product Height
4.25 in
Product Width
6.5 in
Product Weight
0.833 lb
Certifications
Contact Manufacturer
Type
Non-metallic portable outlet box
Box depth
Extra depth feed through
Color
Yellow
Cover plate type
Single receptacle
Material
Alcryn and Valox
Opening diameter
1.56 in
Operating temperature
-32 to 176°F
Non-metallic construction with Alcryn and Valox provides excellent insulation and chemical resistance, reducing risk of corrosion and electrical leakage while keeping weight manageable for field installs. This translates to faster, safer installations and lower labor costs on demanding lines and outdoor sites. The extra depth feed-through design enables additional wiring inside the box without compromising enclosure integrity, simplifying routing and reducing conduit runs in control panels. The yellow color improves visibility in crowded plant floors or outdoor environments, speeding maintenance and minimizing misplacement during rework or inspections. A 1.56 in opening accommodates standard single receptacles, ensuring compatibility with common components and reducing procurement complexity. The operating temperature range of -32 to 176°F supports performance across extreme industrial climates, from cold facilities to hot, sun-exposed locations. With a compact 2.5 in depth, 4.25 in height, and 6.5 in width, plus a light 0.833 lb weight, this box delivers easy handling and straightforward mounting in tight spaces while maintaining robust protection against impacts and dust. Overall, it pairs well with Eaton covers and accessories to streamline installation workflows and improve uptime in automation and electrical infrastructure projects.
Get a Quick Quote for a Eaton WD3090F-LLN
Chat with us on WhatsApp - fast responses guaranteed
Need to speak with someone? We'll call you back within 2 hours during business hours
Interested in Eaton WD3090F-LLN?
Enquire Now
FAQs
Plan for a field-friendly fit by confirming aperture compatibility with standard receptacles and ensuring mounting space accommodates the box dimensions (2.5 in depth, 4.25 in height, 6.5 in width). Use appropriate fasteners and ensure the extra-depth feed-through is leveraged for orderly wire routing. Verify that site codes and lockout/tagout procedures are followed during installation.
Yes, WD3090F-LLN is designed for a single receptacle with a 1.56 in opening, supporting common receptacle configurations. The enclosure’s non-metallic construction and dimensions are suited for typical portable outlet box applications, and it can be mounted alongside compatible covers and accessories within Eaton’s ecosystem for a cohesive installation.
The extra depth feed-through provides additional interior space behind the receptacle, making it easier to route conductors and connect cables without crowding the outlet. This reduces bending, minimizes cable strain, and streamlines field terminations, contributing to faster commissioning and more reliable connections in automation and control panels.
The enclosure operates from -32 to 176°F, enabling reliable performance across extreme indoor and outdoor environments. It uses Alcryn and Valox materials, which offer strong insulation, chemical resistance, and impact protection, helping to maintain electrical integrity and extend service life in harsh industrial settings.
The WD3090F-LLN reduces maintenance overhead by delivering durable insulation, visible yellow coloration for quick location, and easier wiring due to extra-depth feed-through. Its moderate weight (0.833 lb) and compact footprint simplify field handling, reducing labor time during installations and inspections, while supporting consistent uptime in automation and electrical infrastructure projects.
