Eaton X100M Condulet Form 5 - 1 in, Ordinary/Non-Hazardous
Part Number: X100M
Quick Summary
The Eaton X100M Condulet Form 5 outlet body provides rugged conduit connections for Form 5 installations in industrial enclosures. Engineers often grapple with wrong-sized housings, sealing challenges, and corrosion risk in harsh environments. It is designed for NEC/CEC compliance and rated for Ordinary/Non-Hazardous Locations, with Canadian certification support where applicable. For 1 in trade size installations, the malleable iron Form 5 conduit outlet body delivers durable, code-compliant connections that reduce maintenance overhead. This combination speeds installation, minimizes field errors, and supports long-term reliability in control panels and equipment rooms.
Product Information
Extended Description
X100M Eaton: Eaton Crouse-Hinds series Condulet Form 5 conduit outlet body, Malleable iron, X shape, 1"
Product Name
Eaton Crouse-Hinds series Condulet Form 5 conduit outlet body
Catalog Number
X100M
UPC
784564003027
Product Length/Depth
7.1 in
Product Height
3.56 in
Product Width
2.25 in
Product Weight
2.47 lb
Area classification
Ordinary/Non-Hazardous Locations
Standards type
NEC/CEC
Shape
X
Trade size
1"
Material
Malleable iron
Eaton Crouse-Hinds X100M 3D drawing
Crouse-Hinds series Form 5 catalog page
Condulet Form 5 Conduit Outlet Bodies Canadian certification
Condulet Form 5 Conduit Outlet Bodies Canadian certification
Eaton Specification Sheet - X100M
Feature: Form 5 conduit outlet body with a 1 in trade size and X-shaped footprint → Business Impact: Provides a robust, versatile connection point compatible with standard conduit runs, reducing the need for adapters and custom fittings → Application: Ideal for Form 5 installations in industrial control panels and equipment enclosures where reliable sealing and quick wiring access are required. Feature: Malleable iron construction → Business Impact: Delivers superior mechanical strength and resistance to impact, extending service life in challenging environments → Application: Suitable for wall-mounted panels, control cabinets, and outdoor switchgear housings facing vibration and rough handling. Feature: Precise dimensions and weight: 7.1 in length, 3.56 in height, 2.25 in width, 2.47 lb → Business Impact: Predictable fit and simplified layout planning save labor during installation and inspection → Application: Helps engineers plan enclosures and pre-fit conduits in limited spaces. Feature: Area classification Ordinary/Non-Hazardous Locations and NEC/CEC compliance → Business Impact: Regulatory alignment reduces rework, ensures safety, and streamlines approvals for new builds and retrofits → Application: Industrial facilities with non-hazardous environments; consistent with code-based project requirements. Feature: Rich collateral and resources: 3D CAD drawing package, catalog page, and specification sheets → Business Impact: Accelerates design, procurement, and approval cycles by providing ready-to-use data → Application: Engineering design workflows, purchasing catalogs, and field service readiness.
Get a Quick Quote for a Eaton X100M
Chat with us on WhatsApp - fast responses guaranteed
Need to speak with someone? We'll call you back within 2 hours during business hours
Interested in Eaton X100M?
Enquire Now
FAQs
The X100M is designed for a 1 in trade size conduit run using a Form 5 configuration and malleable iron construction. Ensure compatibility with standard Form 5 fittings and that the installation location is within ordinary/non-hazardous locations per NEC/CEC guidelines. Verify upstream and downstream enclosure clearances and sealant practices to maintain enclosure integrity.
Key specs include an X-shaped Form 5 outlet body for a 1 in trade size, length of 7.1 in, height 3.56 in, width 2.25 in, and weight 2.47 lb. UPC is 784564003027. These details aid layout planning and ensure correct mating with compatible conduits and accessories.
X100M is rated for Ordinary/Non-Hazardous Locations. It is not specified for hazardous (Classified) environments. For projects in potentially explosive or hazardous areas, select a Form 5 conduit body designed for those locations and verify compliance with local certifications.
The unit is aligned with NEC/CEC standards and area classification for Ordinary/Non-Hazardous Locations. Canadian certification information is available via UL-associated pages, and downstream documentation confirms form factor compatibility with Form 5 installations in non-hazardous environments.
Resource availability includes a 3D CAD drawing package, a Form 5 catalog page, and an Eaton specification sheet. These assets streamline design validation, BOM creation, and installation planning, reducing design cycle time and ensuring accurate part selection.
