Eaton X200M Condulet Form 5 Conduit Outlet - NEC/CEC
Part Number: X200M
Quick Summary
X200M Condulet Form 5 conduit outlet body from Eaton protects and terminates conduit in industrial electrical installations. When upgrading facilities or retrofitting, engineers often encounter compatibility gaps, certification hurdles, and mounting constraints that stall projects. This Form 5 unit is NEC/CEC compliant and UL-listed for United States and Canada, supporting safe, code-conforming installations in ordinary/non-hazardous locations. Built in malleable iron with an X-shaped form, it delivers robust enclosure integrity while remaining practical for trade-sized conduits. The combination of reliable performance, widely available catalog references, and accessible installation drawings helps streamline procurement and field work, delivering measurable cost savings over time for OEMs, panel builders, and facilities teams.
Product Information
Extended Description
X200M Eaton: Eaton Crouse-Hinds series Condulet Form 5 conduit outlet body, Malleable iron, X shape, 2"
Product Name
Eaton Crouse-Hinds series Condulet Form 5 conduit outlet body
Catalog Number
X200M
UPC
784564003058
Product Length/Depth
11.75 in
Product Height
5.4 in
Product Width
3.45 in
Product Weight
8.33 lb
Area classification
Ordinary/Non-Hazardous Locations
Standards type
NEC/CEC
Shape
X
Trade size
2"
Material
Malleable iron
Eaton Crouse-Hinds X200M 3D drawing
Crouse-Hinds series Form 5 catalog page
Condulet Form 5 Conduit Outlet Bodies UL certification
Condulet Form 5 Conduit Outlet Bodies UL certification
Eaton Specification Sheet - X200M
Feature: Form 5 conduit outlet body with a 2 in trade size provides a standardized termination point for straight or elbow conduit connections. Business Impact: accelerates installation, reduces field adjustments, and lowers rework in tight industrial spaces. Application: ideal for panel builds, machine wiring, and control enclosures in manufacturing facilities. Feature: Malleable iron construction delivers rugged enclosure integrity capable of withstanding vibration and incidental impacts common on factory floors. Business Impact: minimizes maintenance frequency and extends service life, lowering lifecycle costs. Application: suitable for Form 5 conduit bodies in control panels, machine gateways, and equipment enclosures. Feature: Precise exterior dimensions—11.75 in length, 5.4 in height, 3.45 in width—and 8.33 lb weight enable accurate space planning and mounting on enclosures. Business Impact: ensures correct fit, reduces field modification time, and supports repeatable installations in large-scale projects. Application: retrofits and new builds requiring exact enclosure geometry. Feature: NEC/CEC compliance and area classification as Ordinary/Non-Hazardous Locations. Business Impact: streamlines compliance reviews, speeds approvals, and simplifies cross-border sourcing for US and Canada. Application: industrial facilities, OEMs, and system integrators deploying Form 5 conduits. Feature: Availability of 3D CAD drawings, catalog pages, and UL certification references. Business Impact: shortens engineering design cycles, accelerates procurement, and improves change-management traceability. Application: engineering teams, procurement groups, and field technicians designing and installing conduit runs.
Get a Quick Quote for a Eaton X200M
Chat with us on WhatsApp - fast responses guaranteed
Need to speak with someone? We'll call you back within 2 hours during business hours
Interested in Eaton X200M?
Enquire Now
FAQs
The X200M Form 5 conduit outlet body is designed for ordinary/non-hazardous locations and NEC/CEC-compliant installations. It supports a 2 inch trade size and malleable iron construction, making it ideal for control panels, machine wiring, and industrial enclosures in manufacturing facilities. Use with compatible Crouse-Hinds Form 5 fittings for a sealed, reliable termination.
The X200M carries NEC/CEC standards and is specified for Ordinary/Non-Hazardous Locations, aligning with common electrical codes in the US and Canada. UL certification references for US and Canada are available in the product documentation, simplifying compliance reviews during design and procurement.
Key dimensions include 11.75 in length, 5.4 in height, and 3.45 in width, with a weight of 8.33 lb and a 2 in trade size. These specs aid space planning and mounting on enclosures, helping ensure a proper fit without interference and supporting stable, vibration-resistant installations in industrial environments.
Yes. UL certification references for the X200M Form 5 conduit outlet body are available for both the United States and Canada, indicating compliance with essential safety and performance requirements. This UL backing facilitates multi-country project approvals and reduces the need for separate certifications when sourcing from Eaton.
Using the X200M in new builds lowers lifecycle costs through durable malleable iron construction that resists wear, reducing field service. NEC/CEC compliance accelerates approvals, while readily available catalogs, CAD drawings, and UL references shorten design cycles and procurement. Although heavier at 8.33 lb, the long-term reliability yields fewer maintenance events and safer, code-compliant installations.
