Rittal VX 5301.235 Internal Interlock - IP55
Part Number: 5301235
Quick Summary
Rittal VX 5301.235 internal interlock is a screw-fastened latch for securing VX enclosure side panels. It addresses the common issue of unintended panel access during maintenance by providing inside-latching security. The design supports IP55 protection when used with VX frames and aligns with industry classifications ETIM EC000327 and ECLASS 27409217 to ensure compatibility across ERP and procurement workflows. By combining robust material construction with straightforward installation, this interlock delivers reliable security without complicating service routines, while reinforcing enclosure integrity and long-term cost efficiency in industrial environments.
Product Information
Extended Description
5301235 Rittal: VX internal interlock for side panel, screw-fastened, material: sheet steel, zinc-plated
Article number
VX 5301.235
Product description
Additional security is achieved via the option of latching the side panel from the inside. The side panels on the frame section are screw-fastened from the inside with latching brackets.
Surface finish
Sheet steel, zinc-plated
Supply includes
2 mounting brackets | Assembly parts
Assembly instruction
Access via the front and rear doors must be guaranteed
IP protection category to IEC 60 529
IP 55 (in conjunction with enclosures from the VX, VX IT series)
Packs of
2 pc(s).
Weight/pack
0.056 kg
Customs tariff number
73269098
EAN
4028177952454
ETIM 9
EC000327
ECLASS 8.0
27409217
Product description
VX internal interlock for side panel, screw-fastened, material: sheet steel, zinc-plated
Feature: Screw-fastened from inside provides enhanced security by preventing accidental panel removal during service. Business Impact: Reduces maintenance downtime and tampering risk, supporting safer and faster access for technicians. Application: Ideal for VX frame enclosures in harsh plant environments where secure side-panel latching is essential. Feature: Sheet steel, zinc-plated surface finish offers durable corrosion resistance and long life in industrial settings. Business Impact: Lower maintenance costs and extended enclosure longevity, even in aggressive atmospheres. Application: Suitable for factory floors, switchgear rooms, and outdoor-rated installations when paired with VX series. Feature: Includes two mounting brackets and assembly parts in each pack. Business Impact: Faster, error-free installation with repeatable alignment, reducing field labor and warranty claims. Application: Retrofit projects and new builds requiring quick, reliable mounting of internal latches. Feature: IP55 protection (in conjunction with VX and VX IT series enclosures). Business Impact: Ensures dust and water ingress protection for critical control panels, improving compliance with harsh-environment standards. Application: Industrial automation cabinets operating in dusty or wet environments. Feature: Compatibility with VX IT series and front/rear access requirements. Business Impact: Simplifies integration into existing racks with consistent door access control, minimizing modification needs. Application: Serviceable enclosures where secure panel access is critical to uptime and safety.
Get a Quick Quote for a Rittal 5301235
Chat with us on WhatsApp - fast responses guaranteed
Need to speak with someone? We'll call you back within 2 hours during business hours
Interested in Rittal 5301235?
Enquire Now
FAQs
Installation uses two mounting brackets and assembly parts included in the pack. The interlock is screw-fastened from inside the enclosure, and access to the front and rear doors must be guaranteed during service to ensure proper alignment and secure operation.
Key specs include article VX 5301.235, material sheet steel with zinc plating, IP55 rating with VX frames, and a weight of 0.056 kg per pack. Packaging includes 2 pieces per pack and 2 mounting brackets plus assembly parts.
Yes. The IP55 protection is achieved in conjunction with VX and VX IT series enclosures, and the latch design supports secure inside-latching for side panels on these frames.
It prevents unintended panel access during maintenance by providing an inside latch for side panels, reducing tampering risk and avoiding accidental openings that could disrupt operations.
The product aligns with IP55 protection for VX frames, and classifications such as ETIM EC000327 and ECLASS 27409217, ensuring compatibility with common data models and procurement workflows. EAN is 4028177952454.
