Rittal VX 5301.337 Gland Plate Module - Multi-piece, Solid, Zinc-plated Sheet Steel for VX IT 800x800
Part Number: 5301337
Quick Summary
Rittal VX 5301.337 gland plate module enables flexible cable entry management for VX IT enclosures. In busy automation environments, fixed entry points slow changes, while this modular design lets you reorder base plates and the sliding panel to fit evolving layouts. The design is CE-marked and aligned with ETIM 9 EC002620 and ECLASS 8.0 27189261, supporting reliable procurement and compliance. The zinc-plated sheet steel delivers durability in harsh environments, and its VX IT compatibility ensures straightforward integration. Together, these features reduce installation time and maintenance costs, delivering tangible business value for control cabinets and electrical assemblies.
Product Information
Extended Description
5301337 Rittal: VX IT gland plate module, multi-piece, solid, for width 800 mm, W x D 800 x 800 mm, sheet steel
Article number
VX 5301.337
Product description
Multi-piece gland plate set consisting of solid base plate modules and a sliding panel for cable entry. The solid gland plate module, depth 237.5 mm, may optionally be exchanged for gland plate module variants for cable entry.
Benefits
The sequence of individual modules may be freely selected
Material
Sheet steel
Surface finish
Zinc-plated
Supply includes
Gland plate set | Sealing tape | Assembly parts | 1 gland plate module, solid, depth: 75 mm | 2 gland plate modules, solid, depth: 237.5 mm | 1 sliding panel, depth: 115 mm
To fit
Enclosure type:Â VX IT | Width:Â = 800 mm | Depth:Â = 800 mm
Packs of
1 pc(s).
Weight/pack
6.32 kg
PCF per pack (cradle-to-gate)
24.1Â kg CO2 eq (Cat B)
Note on PCF category
Category B: PCF value (cradle-to-gate) based on the product weight, approximately calculated and self-declared
Customs tariff number
73269098
EAN
4028177950894
ETIM 9
EC002620
ECLASS 8.0
27189261
Product description
VX IT gland plate module, multi-piece, solid, for width 800 mm, W x D 800 x 800 mm, sheet steel
Multi-piece gland plate set consisting of solid base plate modules and a sliding panel enables tailor-made cable-entry paths for every panel. This flexibility reduces rework and downtime when layouts change, and minimizes manual threading during retrofits. It is especially valuable in VX IT installations where space is tight and cable routing must be adapted quickly to changing control architectures. The business impact is faster commissioning, simpler lifecycle management, and lower total cost of ownership for cabinet builds in manufacturing and process automation. The modular approach supports long-term scalability, enabling seamless additions or removals of entry points as systems evolve, while maintaining proper sealing and enclosure integrity for reliable operation.
Get a Quick Quote for a Rittal 5301337
Chat with us on WhatsApp - fast responses guaranteed
Need to speak with someone? We'll call you back within 2 hours during business hours
Interested in Rittal 5301337?
Enquire Now
FAQs
VX 5301.337 is designed for VX IT enclosures at 800 mm width and 800 mm depth. It ships as a complete gland plate kit including one solid base module (75 mm), two solid base modules (237.5 mm), and one sliding panel (115 mm), plus sealing tape and assembly parts. This ensures straightforward mounting and precise fit within VX IT frames.
The multi-piece design allows free sequencing and replacement of individual modules, so you can reconfigure cable entries without replacing the entire gland plate. This reduces downtime during upgrades, simplifies rework for new harness layouts, and supports scalable cabinet designs ideal for evolving automation requirements.
Yes. The gland plate module uses sheet steel with a zinc-plated finish, delivering corrosion resistance and robust mechanical performance suitable for factory floors and harsh environments. Its compatibility with VX IT enclosures ensures reliable integration into control cabinets used in manufacturing, process automation, and machine-building environments.
The product carries CE marking for European safety compliance and is aligned with ETIM 9 EC002620 and ECLASS 8.0 27189261 classifications, aiding standardized procurement and component pairing. While not all installations specify IP ratings, the zinc-plated, sheet-steel build supports typical enclosure protection when integrated with VX IT systems.
The kit provides a compact, single-pack solution with a weight of 6.32 kg and a cradle-to-gate PCF of 24.1 kg CO2 eq (Category B). This simplifies sourcing, reduces installation time, and supports greener manufacturing practices by enabling efficient cable management and streamlined retrofits in automation cabinets.
