Rittal VX 5301.341 Gland Plate Module - Zinc-Plated
Part Number: 5301341
Quick Summary
Rittal VX 5301.341 gland plate module is a modular, solid gland plate system for VX IT enclosures. It addresses the common challenge of fixed gland plate configurations by allowing freely sequenced modules to match evolving cable routes. While explicit SIL, CE, and IP certifications aren’t listed in the data, the design relies on ETIM 9 EC002620 and ECLASS 8.0 27189261 for standardised classification and compatibility. This combination supports faster installs, easier maintenance, and scalable cable-entry solutions, delivering reliable panel performance in industrial environments. Ideal for VX IT enclosures and modular gland-plate systems, it enables flexible, future-proof electrical routing.
Product Information
Extended Description
5301341 Rittal: VX IT gland plate module, multi-piece, solid, for width 600 mm, W x D 600 x 1200 mm, sheet steel
Article number
VX 5301.341
Product description
Multi-piece gland plate set consisting of solid base plate modules and a sliding panel for cable entry. The solid gland plate module, depth 237.5 mm, may optionally be exchanged for gland plate module variants for cable entry.
Benefits
The sequence of individual modules may be freely selected
Material
Sheet steel
Surface finish
Zinc-plated
Supply includes
Gland plate set | Sealing tape | Assembly parts | 4 gland plate modules, solid, depth: 237.5 mm | 1 sliding panel, depth: 115 mm
To fit
Enclosure type: VX IT | Width: = 600 mm | Depth: = 1,200 mm
Packs of
1 pc(s).
Weight/pack
6.92 kg
PCF per pack (cradle-to-gate)
26.4 kg CO2 eq (Cat B)
Note on PCF category
Category B: PCF value (cradle-to-gate) based on the product weight, approximately calculated and self-declared
Customs tariff number
73269098
EAN
4028177950931
ETIM 9
EC002620
ECLASS 8.0
27189261
Product description
VX IT gland plate module, multi-piece, solid, for width 600 mm, W x D 600 x 1200 mm, sheet steel
Feature: Multi-piece gland plate set consisting of solid base modules and a sliding panel. Business Impact: Enables tailored cable entry paths, reducing the need for costly custom enclosures and minimizing modification downtime. Application: Suited for VX IT enclosure configurations with a 600 mm width and 1200 mm depth. Feature: Solid gland plate modules with a depth of 237.5 mm and an option to exchange for alternate variants. Business Impact: Supports precise routing for diverse cable bundles and simplifies upgrades without replacing the enclosure. Application: Fits standard VX IT frames while letting you reconfigure entries as project needs change. Feature: Sliding panel with a depth of 115 mm. Business Impact: Allows additional space for larger cable bundles or special entry requirements, lowering routing constraints. Application: Enhances adaptability in midlife redesigns or expansion projects. Feature: Material and finish—sheet steel, zinc-plated. Business Impact: Provides robust mechanical strength with corrosion resistance, extending service life in harsh environments. Application: Suitable for factory floors, outdoor cabinets, and other demanding installations. Feature: Supplied components and weight—4 solid modules (237.5 mm) and 1 sliding panel (115 mm) with sealing tape and assembly parts; weight per pack 6.92 kg; PCF 26.4 kg CO2 eq (Cat B). Business Impact: Reduces onsite sourcing, speeds assembly, and supports sustainability metrics while maintaining expected performance. Application: Streamlines procurement and installation for VX IT projects.
Get a Quick Quote for a Rittal 5301341
Chat with us on WhatsApp - fast responses guaranteed
Need to speak with someone? We'll call you back within 2 hours during business hours
Interested in Rittal 5301341?
Enquire Now
FAQs
The VX 5301.341 is designed specifically for VX IT enclosures, with a 600 mm width and 1200 mm depth. It includes four solid modules (237.5 mm depth) and one sliding panel (115 mm depth), plus sealing tape and assembly parts, ensuring straightforward integration and reliable sealing within VX IT frames.
Install by selecting the desired module sequence to match cable routing needs. Use the included sealing tape and assembly parts for proper sealing. The kit comprises four solid modules and one sliding panel, compatible with a 600x1200 mm VX IT enclosure, which helps minimize retrofit time and component search during setup.
The gland plate is constructed from sheet steel with a zinc-plated finish, providing corrosion resistance and durability. Weight per pack is 6.92 kg, aiding straightforward handling and on-site logistics during installation.
Yes. The design supports a freely selectable sequence of modules, enabling you to swap, add, or remove entries as project requirements evolve without replacing the entire assembly. This modular approach supports mid-project adjustments and future-proofing of cable routing.
The product is classified under ETIM 9 EC002620 and ECLASS 8.0 27189261 for standardised data exchange and compatibility. It also carries the EAN 4028177950931 and a customs tariff number of 73269098, aiding procurement and regulatory compliance in global supply chains.
