Rittal gland plate module - Zinc-plated
Part Number: 5301347
Quick Summary
Rittal VX 5301.347 gland plate module provides flexible cable entry for VX IT enclosures. Engineers often struggle to configure cable entry without compromising enclosure integrity or sealing. The module aligns with industry classifications ETIM 9 EC002620 and ECLASS 8.0 27189261, supporting procurement, maintenance, and cross‑system compatibility. With its modular sequence and a footprint of 800 by 1200 millimeters, the design supports scalable layouts and faster installation for automation cabinets, while the included sealing tape and assembly parts streamline onboarding. In short, this gland plate adds value by improving cable management, reducing downtime, and supporting lifecycle costs in industrial environments.
Product Information
Extended Description
5301347 Rittal: VX IT gland plate module, multi-piece, solid, for width 800 mm, W x D 800 x 1200 mm, sheet steel
Article number
VX 5301.347
Product description
Multi-piece gland plate set consisting of solid base plate modules and a sliding panel for cable entry. The solid gland plate module, depth 237.5 mm, may optionally be exchanged for gland plate module variants for cable entry.
Benefits
The sequence of individual modules may be freely selected
Material
Sheet steel
Surface finish
Zinc-plated
Supply includes
Gland plate set | Sealing tape | Assembly parts | 4 gland plate modules, solid, depth: 237.5 mm | 1 sliding panel, depth: 115 mm
To fit
Enclosure type:Â VX IT | Width:Â = 800 mm | Depth:Â = 1,200 mm
Packs of
1 pc(s).
Weight/pack
9.64 kg
PCF per pack (cradle-to-gate)
36.7Â kg CO2 eq (Cat B)
Note on PCF category
Category B: PCF value (cradle-to-gate) based on the product weight, approximately calculated and self-declared
Customs tariff number
73269098
EAN
4028177950993
ETIM 9
EC002620
ECLASS 8.0
27189261
Product description
VX IT gland plate module, multi-piece, solid, for width 800 mm, W x D 800 x 1200 mm, sheet steel
Modular module sequence enables freely selecting the order of base plates and the sliding panel, enabling tailored cable entry paths that fit unique cabinet layouts, reducing rework and accelerating commissioning in manufacturing lines. The multi-piece gland plate set—four solid glands plus one sliding panel—offers flexible entry points for varying cable densities, improving layout efficiency and negating the need for post‑purchase modifications on the shop floor. Sheet steel with a zinc‑plated finish provides durable corrosion resistance in harsh environments, extending service life and lowering maintenance costs while maintaining a clean appearance. Designed to fit VX IT enclosures at 800 mm width and 1200 mm depth, this gland plate ensures straightforward compatibility with existing cabinet systems and accessories, minimizing integration risk. Included sealing tape and assembly parts speed up installation, reducing labor time and material waste, and supporting lean deployment. The lightweight 9.64 kg per pack, combined with cradle‑to‑gate PCF of 36.7 kg CO2 eq (Category B), offers a tangible sustainability and cost‑of‑ownership advantage for large‑scale deployments while remaining robust for industrial automation environments.
Get a Quick Quote for a Rittal 5301347
Chat with us on WhatsApp - fast responses guaranteed
Need to speak with someone? We'll call you back within 2 hours during business hours
Interested in Rittal 5301347?
Enquire Now
FAQs
Begin by validating the enclosure width and depth (800 mm x 1200 mm). Assemble the four solid gland modules and the 115 mm sliding panel using the supplied assembly parts and sealing tape. Mount the solid base plates first, then insert the sliding panel where cable entry is required. Use the included seals to maintain enclosure integrity and ensure all fasteners are tightened to spec. This modular approach lets you tailor entry points while preserving enclosure sealing and accessibility.
Key specifications include width 800 mm, overall depth 1200 mm, base modules depth 237.5 mm, sliding panel depth 115 mm, and sheet steel construction with a zinc‑plated finish. The set comprises four solid gland plate modules and one sliding panel, with a pack weight of 9.64 kg and a PCF of 36.7 kg CO2 eq (Category B). The EAN is 4028177950993, and the part is listed as VX 5301.347 with ETIM 9 EC002620 and ECLASS 8.0 27189261.
Yes. It is designed to fit VX IT enclosures with a width of 800 mm and a depth of 1200 mm, and its modular sequence lets you arrange the base plates and sliding panel to match specific cable densities and cabinet layouts. This compatibility reduces integration risk and simplifies procurement when pairing with other VX IT accessories and gland plate modules.
The product uses zinc‑plated sheet steel and provides cradle‑to‑gate PCF data of 36.7 kg CO2 eq per pack (Category B), supporting sustainability reporting. It carries industry classifications ETIM 9 and ECLASS 8.0, which aid in standard procurement and cross‑system integration, while the sealed design helps meet typical enclosure integrity requirements in automated environments.
Downloads include a View page as PDF and DE, EN, FR instruction documents. Access the official Rittal resource links to obtain the latest installation instructions, dimension details, and sealing guidelines, ensuring accurate and up‑to‑date technical data for setup and maintenance.
