Rittal 5301438 Sheet Steel Door - IP55 VX IT Series
Part Number: 5301438
Quick Summary
Rittal 5301438 Sheet Steel Door replaces existing doors in VX IT enclosures, delivering secure access in controlled electrical rooms. The compact rotation radius of the door minimizes bay spacing, reducing overall footprint and simplifying maintenance routes. IP55 protection ensures resilience in dusty or damp environments, while the viewing panel and 4-point locking rod enable safe, quick inspections. This door is powder-coated in RAL 7035 with VX comfort handle and black hinges for durable service life. With standardized dimensions (800 mm width, 2,200 mm height) and supported assembly, it pairs with VX IT enclosures to streamline installation, improve serviceability, and align with modern automation infrastructure.
Product Information
Extended Description
5301438 Rittal: Sheet steel glazed door, vertically divided for VX IT, to replace existing doors. With underlaid viewing panel and 4-point locking rod. For enclosure width 800 mm, for enclosure height 2,200 mm
Article number
DK 5301.438
Product description
To replace existing doors. With underlaid viewing panel and 4-point locking rod. The divided design allows room-optimised siting of the enclosures coupled with the best possible access, thanks to a reduced distance between the individual bayed enclosure suites.
Material
Frame: Sheet steel | Viewing window: Single-pane safety glass, 3 mm
Surface finish
Powder-coated
Colour
Frame: RAL 7035 | Comfort handle VX, hinges: RAL 9005
Supply includes
Door, vertically divided, with comfort handle VX for semi-cylinders with security lock 3524 E, right | 4 x 180° hinges, fitted on each half of the door | Assembly parts
Assembly instruction
For a door opening angle of 180° when baying, a 180° baying hinge is required
Note
Door opening angle for stand-alone siting: max. 240°
IP protection category to IEC 60 529
IP 55
To fit
Enclosure type: VX IT | Width: = 800 mm | Height: = 2,200 mm
Packs of
1 pc(s).
Weight/pack
36.2 kg
PCF per pack (cradle-to-gate)
137.9 kg CO2 eq (Cat B)
Note on PCF category
Category B: PCF value (cradle-to-gate) based on the product weight, approximately calculated and self-declared
EAN
4028177955042
ETIM 9
EC000747
ECLASS 8.0
27182204
Product description
Sheet steel glazed door, vertically divided for VX IT, to replace existing doors. With underlaid viewing panel and 4-point locking rod. For enclosure width 800 mm, for enclosure height 2,200 mm
Reduced baying footprint due to minimal door rotation radius. Business impact: This enables denser enclosure rows and more efficient floor plans, reducing the overall capital tied up in hardware and space. Application: The 800 mm width VX IT family makes it ideal for data centers, manufacturing lines, and control rooms where every inch counts. Vertically divided glazed door with underlaid viewing panel and 4-point locking rod. Business impact: Improves maintenance efficiency and security by allowing quick visual checks and secure access without full door removal. Application: Suitable for VX IT enclosures where operators need fast status checks inside the cabinet while keeping valuables protected. Sheet steel construction with powder-coated finish and 3 mm viewing glass. Business impact: Delivers durable performance in harsh environments while maintaining visibility, reducing replacement cycles. Application: Industrial facilities and process lines requiring robust, clear access. IP55 protection rating. Business impact: Protects against dust ingress and water spray in manufacturing and outdoor installations, helping maintain uptime. Application: Enclosures in damp or dusty zones needing compliant protection. Includes 4 x 180° hinges per door half plus assembly parts; baying hinge option required for 180° opening. Business impact: Simplifies retrofit and installation with standardized hardware, minimizing downtime. Application: Upgrade projects across existing VX IT bays. Designed for VX IT width 800 mm and height 2,200 mm with a powder-coated frame in RAL 7035 and VX comfort handle. Business impact: Ensures consistent dimensions and aesthetics across facilities, improving operator experience and compliance with color-coding. Application: New builds and refurbishments of compact VX IT door assemblies.
Get a Quick Quote for a Rittal 5301438
Chat with us on WhatsApp - fast responses guaranteed
Need to speak with someone? We'll call you back within 2 hours during business hours
Interested in Rittal 5301438?
Enquire Now
FAQs
The installation uses 4 x 180° hinges per door half and includes assembly parts. For bayed configurations, a 180° baying hinge is required to achieve full 180° opening. Follow the enclosure’s mounting points and align the door with the 800 mm width and 2,200 mm height specification to ensure proper sealing and operation.
Yes. The door is designed to fit VX IT enclosures with a width of 800 mm and height of 2,200 mm. It features an IP55-rated sealing system, a viewing panel, and a 4-point locking rod for secure, controlled access during maintenance and operations.
The vertically divided glazed door includes an underlaid viewing panel for quick visual checks and a 4-point locking rod for enhanced security. The combination of these features enables fast inspections without full door removal, reducing downtime and improving overall maintenance efficiency in busy control environments.
The door provides IP55 protection per IEC 60529, safeguarding against dust ingress and water spray in challenging environments. Its construction uses powder-coated sheet steel with a 3 mm safety glass window, supporting reliable performance in harsh industrial settings.
Space savings from the compact door rotation radius allow closer baying, reducing floor footprint and wiring complexity. The durable finish and secure access reduce maintenance downtime and replacement costs, while straightforward installation minimizes initial labor and disruption during retrofit projects.
