Rittal 5302003 Air baffle plate - dynamic, RAL9005
Part Number: 5302003
Quick Summary
Air baffle plate 5302003 from Rittal dynamically separates hot and cold zones inside enclosures used in aisle-contained climate systems. This helps prevent mixing of conditioned and ambient air, reducing cooling load and improving overall energy efficiency. The design uses UL 94-HB rated plastics and aligns with ETIM 9 EC000331 and ECLASS 8.0 27189272 for reliable cataloging and cross‑system compatibility. Additionally, it features a RAL 9005 spray finish and is compatible with VX IT 19" mounting angles, enabling straightforward installation in existing rack layouts. For OEMs and integrators, this translates to lower operating costs, easier maintenance, and scalable performance across climate‑controlled enclosures in industrial settings.
Product Information
Extended Description
5302003 Rittal: Air baffle plate, for VX IT 19" mounting angles, dynamic, to separate the hot/cold zones within an enclosure with aisle containment or when using an LCP system. WxD: 800x1800 mm, RAL 9005
Article number
DK 5302.003
Product description
For selectively boosting the energy efficiency of a climate control system.
Benefits
Vertical brush strip for collision-free shielding with installed rail systems on the outer mounting level.
Applications
To separate the hot/cold zones within an enclosure with aisle containment or when using an LCP system.
Material
Sheet steel | Blanking panel: Plastic, ULÂ 94-HB, halogen-free | Brush strip: Plastic, UL 94-HB
Surface finish
Spray-finished
Colour
RALÂ 9005
Supply includes
2 vertical trim panels | 2 horizontal trim panels | 4 brush strips | 4 cellular PU foam pieces | Assembly parts | 6 blanking panels, 482.6 mm (19"), 1 U
Assembly instruction
The vertical trim panels with brush strip may be fitted on both the front and rear 482.6 mm (19") mounting angles for partitioning.
To fit
Width:Â = 800 mm | Height:Â = 1,800 mm
Packs of
1 pc(s).
Customs tariff number
73269098
EAN
4028177955189
ETIM 9
EC000331
ECLASS 8.0
27189272
Product description
Air baffle plate, for VX IT 19" mounting angles, dynamic, to separate the hot/cold zones within an enclosure with aisle containment or when using an LCP system. WxD: 800x1800 mm, RAL 9005
Feature: Dynamic air separation plate for hot/cold zones. Business Impact: Minimizes crossflow between conditioned and ambient air, reducing the cooling demand and energy consumption in climate control systems. Application: Ideal for aisle containment setups and LCP systems in IT, automation, and power distribution enclosures. Feature: Durable sheet steel base with plastic blanks and brush strips. Business Impact: Provides robust separation while maintaining cost efficiency; the UL 94-HB rated plastics reduce fire risk and simplify regulatory compliance. Application: Suitable for indoor industrial environments where safety and longevity matter. Feature: 800x1800 mm WxD and 19" VX IT mounting compatibility. Business Impact: Delivers a ready-to-install solution that fits standard rack rails, shortening project timelines and lowering installation labor. Application: Fits VX IT mounting angles on 19" enclosures. Feature: Comprehensive supply kit including vertical/horizontal trim panels, brush strips, PU foam pieces, and blanking panels. Business Impact: Reduces procurement steps and ensures proper sealing for effective zoning. Application: Streamlines on-site assembly and reduces risk of gaps in the barrier. Feature: Finish and color consistency with RAL 9005 and a spray-finished surface. Business Impact: Improves maintenance visibility and long-term aesthetics while resisting warehouse wear. Application: Enhances integration with other black enclosures and standardized color schemes across facilities.
Get a Quick Quote for a Rittal 5302003
Chat with us on WhatsApp - fast responses guaranteed
Need to speak with someone? We'll call you back within 2 hours during business hours
Interested in Rittal 5302003?
Enquire Now
FAQs
Installation leverages the VX IT 19" mounting angles and includes two vertical and two horizontal trim panels, brush strips, and foam pieces. The vertical trim panels with brush strip can be fitted on both front and rear mounting angles to partition the enclosure while preserving easy access for maintenance. Assembly parts are supplied for a complete, bolt‑together install.
The plate dynamically separates hot and cold zones, reducing air mixing and lowering the cooling burden. This yields energy savings, improved temperature uniformity, and better reliability for sensitive equipment. The solution supports climate control efficiency in IT and industrial environments by enabling targeted zoning without oversized cooling units.
Best applied in enclosures employing aisle containment or LCP systems, particularly with VX IT 19" mounting rails. Its 800x1800 mm footprint is designed for large rack installations where hot/cold zone separation is critical. It complements climate control strategies and is compatible with standard 19" rack layouts for straightforward integration.
The plate uses UL 94-HB rated plastics and aligns with industry classifications ETIM 9 EC000331 and ECLASS 8.0 27189272 for procurement and data exchange. These standards help ensure safe material choices, consistent cataloging, and reliable cross‑system compatibility across IT and industrial enclosures.
By reducing cooling load and stabilizing enclosure temperatures, the plate can lower energy costs and extend equipment life, yielding a favorable ROI over time. Maintenance is minimal: the spray-finished surface resists wear, and the modular kit—trim panels, brush strips, and foam pieces—facilitates straightforward inspection and replacement during routine service.
