Rittal 5302011 Air Baffle Plate for VX IT 19in Mounting Angles - RAL 9005
Part Number: 5302011
Quick Summary
The Rittal 5302011 Air Baffle Plate separates hot and cold zones inside enclosures used with aisle containment. Without proper partitioning, hotspots can undermine cooling efficiency and raise energy costs. Although no explicit SIL, CE, or IP ratings are listed here, the unit uses robust sheet steel construction with a durable spray finish in RAL 9005 to support reliable industrial deployment. In practice, this partitioning enables predictable climate control, reduces cooling losses, and supports energy-efficient operation across VX IT 19in enclosures. For facilities teams, the included kit simplifies installation and helps maintain compliance with ongoing maintenance cycles. This combination of partitioning performance and practical installability delivers measurable cost savings and more stable equipment temperatures.
Product Information
Extended Description
5302011 Rittal: Air baffle plate, for VX IT 19" mounting angles, standard, to separate the hot/cold zones within an enclosure with aisle containment or when using an LCP system. WxH: 800x1200 mm, RAL 9005
Article number
DK 5302.011
Benefits
To selectively boost the energy efficiency of your climate control system
Applications
To separate the hot/cold zones within an enclosure with aisle containment or when using an LCP system.
Material
Sheet steel | Blanking panel: Plastic, ULÂ 94-HB, halogen-free | Brush strip: Plastic, UL 94-HB
Surface finish
Spray-finished
Colour
RALÂ 9005
Supply includes
2 vertical trim panels | 2 horizontal trim panels | 4 brush strips | 4 cellular PU foam pieces | Assembly parts | 4 blanking panels, 482.6 mm (19"), 1 U
Assembly instruction
The vertical trim panels with brush strip may be fitted on both the front and rear 482.6 mm (19") mounting angles for partitioning.
To fit
Width:Â = 800 mm | Height:Â = 1,200 mm
Packs of
1 pc(s).
Weight/pack
5.32 kg
PCF per pack (cradle-to-gate)
20.3Â kg CO2 eq (Cat B)
Note on PCF category
Category B: PCF value (cradle-to-gate) based on the product weight, approximately calculated and self-declared
Customs tariff number
73269098
EAN
4028177955264
ETIM 9
EC000331
ECLASS 8.0
27189272
Product description
Air baffle plate, for VX IT 19" mounting angles, standard, to separate the hot/cold zones within an enclosure with aisle containment or when using an LCP system. WxH: 800x1200 mm, RAL 9005
Air baffle partitioning creates a dedicated barrier that separates hot and cold zones inside an enclosure. This reduces heat transfer and lowers the cooling load, delivering energy savings in data centers, control rooms, and industrial cabinets. The solution is designed for use with aisle containment or LCP systems and fits VX IT 19in mounting angles for straightforward retrofits or new builds. The kit includes two vertical trim panels, two horizontal trim panels, four brush strips, four cellular PU foam pieces, assembly parts, and four blanking panels (19 in, 1 U), enabling plug-and-play installation that minimizes field labor and accelerates commissioning. The materials mix sheet steel with UL 94-HB plastic parts, halogen-free finishes, and a spray-coated surface in RAL 9005, delivering safety, durability, and a consistent industrial appearance. With a WxH of 800x1200 mm and standard 19in mounting compatibility, the plate integrates cleanly into VX IT cabinets while offering flexible partitioning options for front and rear mounting angles. Environmental impact and lifecycle considerations are reflected in the cradle-to-gate PCF value of 20.3 kg CO2 eq (Cat B), helping teams balance performance with sustainability and regulatory expectations. Overall, the product enhances climate control reliability, reduces risk of temperature-induced downtime, and supports long-term operating cost reductions for mission-critical enclosures.
Get a Quick Quote for a Rittal 5302011
Chat with us on WhatsApp - fast responses guaranteed
Need to speak with someone? We'll call you back within 2 hours during business hours
Interested in Rittal 5302011?
Enquire Now
FAQs
Yes. The air baffle plate is designed for VX IT 19in mounting angles and specifically supports partitioning within enclosures that use aisle containment or LCP systems. With WxH 800x1200 mm and included vertical and horizontal trim panels, it aligns with standard 19in cabinet footprints and installs alongside the supplied assembly parts, brush strips, and foam pieces to create a tight, effective barrier.
Expect enhanced climate control due to reduced heat transfer between hot and cold zones, resulting in lower cooling loads and improved energy efficiency. The documentation notes a cradle-to-gate PCF of 20.3 kg CO2 eq (Category B), reflecting a thoughtful balance of performance and sustainability for industrial deployments.
The kit includes 2 vertical trim panels, 2 horizontal trim panels, 4 brush strips, 4 cellular PU foam pieces, assembly parts, and 4 blanking panels (482.6 mm or 19 in) in a 1 U configuration, along with the necessary mounting alignment hardware to enable a complete partitioning solution.
The data provided does not list explicit CE, IP, or SIL certifications for this part. However, the plate uses standard industrial materials and finishes (sheet steel, UL 94-HB plastic, halogen-free) and is finished in RAL 9005, which supports robust factory-floor use. It is recommended to verify compliance with your local authority or Rittal documentation for your specific application.
Follow the assembly guidance that notes vertical trim panels with brush strips can be fitted on front and rear 19in mounting angles to partition the cabinet effectively. Align theWxH (800x1200 mm) with the enclosure and ensure the supplied foam pieces seal gaps to minimize air leakage. The color and finish also help maintain a consistent look and corrosion resistance in harsh environments.
