Rittal VX 5302.031 Slide Rail - 2000 N Load - Heavy Duty
Part Number: 5302031
Quick Summary
Rittal VX 5302.031 slide rail enables heavy-duty mounting between front and rear angles for VX IT enclosures. Installers often struggle with aligning and supporting bulky equipment without risking misalignment, vibration, or service downtime. This part is CE-compliant and designed for robust, EN-standard mounting; its zinc-plated finish resists corrosion in harsh environments. With a 2U profile and a static load rating of 2000 N, it simplifies front-level mounting, reduces installation time, and improves maintenance access in demanding VX IT installations. For 482.6 mm (19") rack layouts, its 35 mm side contact surface and included assembly parts provide a reliable, scalable solution that supports fast deployment and long-term reliability.
Product Information
Extended Description
5302031 Rittal: Slide rail, 2 U, permanent installation, heavy duty, for VX IT, for mounting at the front mounting level, to support heavy installed equipment, effective contact surface each side 35 mm
Article number
VX 5302.031
Product description
Side system punchings for mounting accessories and cooling components that expel to the side.
Benefits
Simply locate into the system punchings of the 482.6 mm (19") mounting brackets after adjusting the required 482.6 mm (19") distance between levels
Applications
For mounting on the front mounting level
Material
Sheet steel
Surface finish
Zinc-plated
Supply includes
Assembly parts
Load capacity
2000 N, static
Note
Effective contact surface 35 mm per side
Installation options
for 482.6 mm (19") mounting angles, standard: Distance between levels 420/445 mm
Packs of
2 pc(s).
Customs tariff number
73269098
EAN
4028177952607
ETIM 9
EC002620
ECLASS 8.0
27189261
Product description
Slide rail, 2 U, permanent installation, heavy duty, for VX IT, for mounting at the front mounting level, to support heavy installed equipment, effective contact surface each side 35 mm
Feature → The rail is 2U high and designed for permanent installation in VX IT enclosures, providing a sturdy mounting path for heavy equipment. Benefit → This delivers improved stability and reduced risk of misalignment during operation, enhancing serviceability. Application → Ideal for front-mounting levels in 482.6 mm (19") VX IT frames where equipment weight and alignment matter. Feature → Made from sheet steel with a zinc-plated surface finish. Benefit → Delivers corrosion resistance and durability in industrial environments, extending enclosure life and lowering maintenance costs. Application → Suitable for harsh factory floors and outdoor-rated electrical installations where exposure to moisture and dust is possible. Feature → Load capacity of 2000 N static. Benefit → Allows secure support for heavy installed equipment without sag or fatigue, supporting longer equipment life and fewer support-related failures. Application → Supports high-density rack configurations in VX IT setups. Feature → Supply includes assembly parts and is packaged as 2 pc(s). Benefit → Reduces procurement steps and speeds up installation, enabling faster project completion and more reliable stocking. Application → Useful for multi-enclosure deployments and service teams that require ready-to-install components. Feature → Installation options specify 482.6 mm mounting angles with standard distance between levels 420/445 mm. Benefit → Delivers flexible, repeatable spacing to match equipment footprints and maximize space utilization. Application → Enables precise rack planning for mixed equipment heights in 19" enclosures.
Get a Quick Quote for a Rittal 5302031
Chat with us on WhatsApp - fast responses guaranteed
Need to speak with someone? We'll call you back within 2 hours during business hours
Interested in Rittal 5302031?
Enquire Now
FAQs
Begin by confirming compatibility with 482.6 mm (19") mounting angles and VX IT enclosure front levels. Align the slide rail between the front and rear mounting points, insert the assembly parts included, and tighten hardware to specification. Use the standard distance between levels 420/445 mm to set the correct spacing, ensuring the 35 mm contact surface per side seats evenly for stable load transfer.
The 2000 N static load rating indicates the rail can support a fixed load up to 2000 Newtons without deformation or failure under steady conditions. This enables secure mounting of heavy equipment in 2U VX IT configurations, reducing sag and maintaining alignment during operation and maintenance cycles.
Yes. The rail is specifically designed for mounting at the front mounting level and works with front/rear mounting angle pairs to support heavy equipment while keeping access for serviceable components straightforward and efficient.
The slide rail is designed to meet applicable CE-compliance requirements and standard industrial mounting practices for VX IT systems. For project-specific regulatory needs, confirm local enclosure and electrical installation standards and reference EN-related guidelines as part of your procurement.
The rail ships as a 2-piece pack with assembly parts, enabling rapid, repeatable installations across multiple enclosures. Its corrosion-resistant zinc-plated finish and 2000 N load capacity minimize downtime due to misalignment or component sag, improving uptime, space efficiency, and long-term ROI for high-density VX IT deployments.
