Rittal VX 5302.032 Slide Rail - Heavy Duty 2U, 2000 N
Part Number: 5302032
Quick Summary
Rittal VX 5302.032 Slide Rail is a heavy‑duty mounting rail for front‑to‑rear 19" mounting in VX IT enclosures. Engineers often struggle with keeping heavy equipment properly aligned and securely supported in tight VX IT layouts; this slide rail delivers stable support and precise positioning. Notable classifications in the data include ETIM 9 EC002620 and ECLASS 8.0 27189261, while explicit CE, IP, or SIL certifications are not listed. With zinc‑plated sheet steel construction and a static load rating of 2000 N, it combines durability with installation flexibility for front mounting levels, while remaining compatible with standard 482.6 mm mounting angles.
Product Information
Extended Description
5302032 Rittal: Slide rail, 2 U, permanent installation, heavy duty, for VX IT, for mounting at the front mounting level, to support heavy installed equipment, effective contact surface each side 35 mm
Article number
VX 5302.032
Product description
Side system punchings for mounting accessories and cooling components that expel to the side.
Benefits
Simply locate into the system punchings of the 482.6 mm (19") mounting brackets after adjusting the required 482.6 mm (19") distance between levels
Applications
For mounting on the front mounting level
Material
Sheet steel
Surface finish
Zinc-plated
Supply includes
Assembly parts
Load capacity
2000 N, static
Note
Effective contact surface 35 mm per side
Installation options
for 482.6 mm (19") mounting angles, standard: Distance between levels 520/545 mm
Packs of
2 pc(s).
Customs tariff number
73269098
EAN
4028177952614
ETIM 9
EC002620
ECLASS 8.0
27189261
Product description
Slide rail, 2 U, permanent installation, heavy duty, for VX IT, for mounting at the front mounting level, to support heavy installed equipment, effective contact surface each side 35 mm
Feature: 2 U height and heavy‑duty design for permanent installation in VX IT enclosures. Business Impact: Enables safe support of heavy installed equipment with stable positioning, reducing sag and misalignment. Application: Ideal for front mounting level installations using 482.6 mm (19") mounting angles. Feature: Sheet steel construction with zinc plating. Business Impact: Delivers corrosion resistance and durable life in demanding industrial environments, lowering replacement costs. Application: Suitable for long‑term service in harsh production floors and control rooms. Feature: 2000 N static load capacity. Business Impact: Supports heavy devices and accessories with minimal deflection, enhancing reliability and uptime. Application: Install power supplies, controllers, and amplifiers on the front level without risk of overloading the rail. Feature: Flexible installation spacing and mounting options (520/545 mm between levels). Business Impact: Reduces rework and accelerates commissioning by adapting to existing VX IT mounting brackets. Application: Works with standard 482.6 mm mounting angles for quick deployment. Feature: Assembly parts included and 2‑piece pack. Business Impact: Simplifies procurement and reduces on‑site sourcing time, speeding up installation. Application: Ready‑to‑install kit for rapid rack assembly. Feature: Effective contact surface 35 mm per side. Business Impact: Improves stability under load and minimizes movement on the front mounting level. Application: Ideal for securing heavy equipment with confidence.
Get a Quick Quote for a Rittal 5302032
Chat with us on WhatsApp - fast responses guaranteed
Need to speak with someone? We'll call you back within 2 hours during business hours
Interested in Rittal 5302032?
Enquire Now
FAQs
VX 5302.032 is designed to mount between a front and rear pair of 482.6 mm (19") mounting angles in VX IT enclosures. It supports a 2U height and ships with assembly parts, enabling secure placement on the front mounting level. Compatibility with standard 482.6 mm brackets ensures straightforward integration into existing layouts.
The 2000 N static load rating defines the maximum weight the rail can support without excessive deflection. When selecting equipment, account for the cumulative weight of devices and accessories, ensure proper distribution across both rails, and pair with the 35 mm side contact surfaces to maintain stability during operation.
Yes. The rail is engineered for front mounting level use within VX IT systems, offering 2U height, a 2000 N static load rating, and a 35 mm per‑side contact surface. It ships with assembly parts and is compatible with 482.6 mm (19") mounting angles, making front‑level installations efficient and stable.
The provided product data lists ETIM 9 EC002620 and ECLASS 8.0 27189261 classifications, but does not specify CE, IP, or SIL certifications. For regulatory compliance, consult the manufacturer datasheet or request certification documentation to confirm any applicable CE marking or industry‑specific requirements.
Using the VX 5302.032 rail improves installation efficiency by simplifying alignment with front mounting level brackets and reducing rework through precise 520/545 mm level spacing. The 2U, heavy‑duty design enhances uptime by lowering movement and wear on mounted equipment, while assembly parts and a 2‑piece pack streamline procurement and on‑site setup.
