Rittal 6005500 Adjustable Frame Connector - 8° Swivel
Part Number: 6005500
Quick Summary
Rittal 6005500 adjustable frame connector is designed to couple Comfort Panels with enclosures, enabling precise mounting between the command panel, keyboard housing, and adjacent horizontal or vertical surfaces. Engineers often struggle with misalignment and instability when joining panels and housings, which can degrade operator ergonomics and increase maintenance time. The data highlights a durable die-cast zinc body with a powder-coated finish in RAL 7024 and an adjustable 8° swivel that provides repeatable alignment across installations. This combination improves installation reliability and reduces downtime, while the rugged construction supports long service life in demanding environments. The CP Frame connector integrates seamlessly with Comfort Panels and supports efficient procurement and installation workflows for control cabinet projects.
Product Information
Extended Description
6005500 Rittal: CP Frame connector, adjustable, for Comfort-Panel
Article number
CP 6005.500
Product description
For use between the command panel and keyboard housing and horizontal or vertical surfaces.
Material
Die-cast zinc
Surface finish
Powder-coated
Colour
RAL 7024
Supply includes
Assembly parts and clamping levers for both sides.
Rotation angle/swivel area
Adjustable in 8° stepped increments.
Packs of
1 pc(s).
Weight/pack
0.72 kg
Customs tariff number
79070000
EAN
4028177490116
ETIM 9
EC002504
ECLASS 8.0
27142423
Product description
CP Frame connector, adjustable, for Comfort-Panel
Feature the CP 6005.500 adjustable frame connector offers precise mounting between Comfort Panels and housings, delivering a predictable alignment that improves operator access and reduces rework. Business impact: faster commissioning, lower maintenance costs, and greater installation reliability in control cabinets and switchgear. Application: ideal for mounting between the command panel and keyboard housing, or between operating and adjacent surfaces, accommodating horizontal or vertical orientations. Feature durable die-cast zinc construction with a powder-coated finish enhances corrosion resistance and longevity in harsh environments, translating to lower replacement costs and improved asset uptime. Application: suitable for continuous-duty industrial installations where robust mounting is required. Feature rotation angle is adjustable in 8° steps, enabling tailored orientation to suit workstation ergonomics and cable management, reducing strain and simplifying field adjustments. Feature supply includes assembly parts and clamping levers for both sides, enabling a complete kit that streamlines installation and minimizes additional purchases. Application: supports rapid integration into Comfort Panel configurations with minimal tooling. Feature compact form and 0.72 kg per pack weight support modular enclosure design, helping mechanical teams optimize space and serviceability. Application: aligns with lean installation practices and scalable automation architectures.
Get a Quick Quote for a Rittal 6005500
Chat with us on WhatsApp - fast responses guaranteed
Need to speak with someone? We'll call you back within 2 hours during business hours
Interested in Rittal 6005500?
Enquire Now
FAQs
CP 6005.500 is designed to fit Comfort Panel configurations and to mount between the command panel, keyboard housing, and adjacent surfaces. It ships with assembly parts and clamping levers for both sides, simplifying alignment checks and securing a rigid connection. For best results, verify orientation and tighten clamps in 8° increments to achieve repeatable alignment.
Key specs include material as die-cast zinc, surface finish powder-coated, colour RAL 7024, weight 0.72 kg per pack, and rotation angle adjustable in 8° steps. The product description specifies it is for use between the command panel and keyboard housing and horizontal or vertical surfaces, with supply comprising assembly parts and clamping levers for both sides.
Yes, the CP 6005.500 is specifically intended for Comfort Panel integration, designed to connect the command panel and keyboard housing to adjacent surfaces. It includes all necessary assembly parts and clamping levers, enabling straightforward installation within standard Rittal control cabinet and enclosure layouts.
The 8° stepped swivel increments allow precise, repeatable orientation of the connected panels, reducing misalignment and the need for rework. This feature is especially valuable for ergonomic alignment of operator controls, improving accessibility and reducing setup time during commissioning and routine maintenance.
The product page provides downloadable resources, including a PDF with full specifications and installation guidance. For quick access, reference the View this page as PDF option to obtain the official CP 6005.500 documentation, including compatibility notes, mounting instructions, and part details.
