Rittal 6701000 CX Console Pedestal - IP55
Part Number: 6701000
Manufacturer
Rittal
Part number
6701000
Alt Part Number
CX 6701.000
Quick Summary
Rittal CX 6701000 pedestal serves as a robust console solution for electrical enclosures in industrial environments. Engineers often struggle with aligning cabinets and routing cables efficiently, leading to project delays and higher costs; this pedestal provides an integrated mounting plate, gland plates, and a secure 3-point lock to simplify installation. The design carries IP 55 protection and IK10 impact resistance, meeting demanding environmental and mechanical requirements. Built for modularity, it supports quick configuration with the 720x625 mm mounting plate and a single front door. By standardizing the pedestal within enclosure infrastructure, it delivers predictable installation times and scalable housing for control panels, driving operational efficiency and lower lifecycle costs.
Product Information
Extended Description
6701000 Rittal: CX console system, pedestal, WxHxD: 800x675x400 mm, sheet steel
Article number
CX 6701.000
Design
Pedestal
Material
Enclosure: Sheet steel 1.5 mm | Door: Sheet steel, 2.0 mm, all-round foamed-in PU seal | Mounting plate: Sheet steel, 2.5 mm
Surface finish
Enclosure and door: Dipcoat primed, powder-coated on the outside, textured paint | Mounting plate: Zinc-plated
Colour
RAL 7035
Supply includes
Enclosure open at top | Door or double-door at front, with 3-point locking system | Mounting plate | Gland plates | Lock: 3 mm double-bit
Dimensions
Width:Â 800 mm | Height:Â 675 mm | Depth:Â 400 mm
Dimensions mounting plate (W x H)
720 mm x 625 mm
Number of doors
1
Door opening angle
130°
IK Code
IK10
Note
A cover plate is required to seal the pedestal
IP protection category to IEC 60 529
IP 55
Basic material
Sheet steel
Number of locks
1
Lock version
3-point lock system
Lock insert
3 mm double-bit
Lock
Lock version:Â 3-point lock system | Number of locks:Â 1 | Lock insert:Â 3 mm double-bit
Packs of
1 pc(s).
Customs tariff number
94032080
EAN
4028177983793
ETIM 9
EC000784
Product description
CX console system, pedestal, WxHxD: 800x675x400 mm, sheet steel
Pedestal-based console design delivers a stable, scalable base for control panels, enabling consistent mounting and faster project commissioning. The 800x675x400 mm footprint combined with a 720x625 mm mounting plate accommodates a wide range of automation components while preserving space on crowded plant floors, reducing cabinet clashes and permitting straightforward cable routing. Material choices—sheet steel enclosure (1.5 mm), door (2.0 mm), and mounting plate (2.5 mm)—provide lasting rigidity and mechanical protection in demanding environments. The IP55 rating protects against dust and water exposure, while IK10 resistance delivers robust impact protection, lowering risk of damage in busy industrial facilities. Supplied with gland plates and a 3-point locking system, it simplifies installation and enhances security; the 130° door opening improves access during commissioning and maintenance. Finish considerations, including dipcoat priming and powder coating, plus zinc-plated mounting plates, extend service life in corrosive or damp settings. The pedestal design also supports quick assembly with a single door and straightforward seal options, reducing field rework and enabling scalable enclosure infrastructure.
Get a Quick Quote for a Rittal 6701000
Chat with us on WhatsApp - fast responses guaranteed
Need to speak with someone? We'll call you back within 2 hours during business hours
Interested in Rittal 6701000?
Enquire Now
FAQs
CX 6701.000 uses a dedicated mounting plate sized 720 x 625 mm, designed to fit the pedestal footprint of 800 x 675 x 400 mm. The assembly provides a stable, standardized base for control panels and allows straightforward attachment of enclosure components via the mounting plate and gland plates included with the supply.
IP55 indicates protection against dust ingress and water jets, while IK10 denotes high mechanical impact resistance. Together they confirm suitability for demanding factory floors, wet or dusty environments, and high-traffic areas where enclosure integrity and component protection are critical.
Yes. The pedestal is designed for console system use with a robust sheet steel enclosure, secure 3-point locking, and an opening angle of 130 degrees for easy access. Its protective ratings, integrated gland plates, and mounting plate support reliable, compliant control panel installations on demanding sites.
The pedestal employs a 3-point lock with a 3 mm double-bit insert for secure access. It ships with gland plates to facilitate clean cable routing from the top of the enclosure, and a single front door which simplifies maintenance access while maintaining enclosure integrity.
Standardized dimensions and included gland plates reduce wiring time and site modifications, speeding up commissioning. The rugged build, IP55/IK10 protection, and durable finishes lower maintenance costs and extend service life, contributing to lower total cost of ownership and improved uptime in automation projects.
