Rittal 6702600 TopConsole Pedestal - IP55, NEMA 12
Part Number: 6702600
Manufacturer
Rittal
Part number
6702600
Alt Part Number
TP 6702.600
Quick Summary
Rittal 6702600 TopConsole pedestal is a rugged enclosure solution for control cabinets in industrial automation. Engineers often wrestle with routing cables cleanly while maintaining a professional, uniform front across multiple enclosures. The unit delivers IP55 protection and NEMA 12 compliance, ensuring reliable performance in challenging environments, while its powder-coated exterior and zinc-plated mounting plate resist corrosion. With the VX mounting aid option and a ready-to-install gland plate system, this pedestal supports scalable, serviceable installations that reduce both setup time and total cost. Designed for the TP TopConsole system, it offers a stable, uniform footprint across widths and depths.
Product Information
Extended Description
6702600 Rittal: TP TopConsole system, pedestal, WHD: 1200x675x400 mm, Sheet steel
Article number
TP 6702.600
Material
Enclosure: Sheet steel 1.5 mm | Door and console cover: Sheet steel, 2.0 mm, all-round foamed-in PU seal | Mounting plate: Sheet steel
Surface finish
Enclosure, cover and door: Dipcoat-primed, powder-coated on the outside, textured paint | Mounting plate: Zinc-plated
Colour
RAL 7035
Supply includes
Enclosure open at top | Door or double door with locking rod (with depth 400 mm at the front, with depth 500 mm at the front and rear) | Mounting plate | Gland plates
Dimensions mounting plate (W x H)
1,099 mm x 625 mm
Number of doors
2
Dimensions
Width: 1,200 mm | Height: 675 mm | Depth: 400 mm
IP protection category to IEC 60 529
IP 55
Protection category NEMA
NEMA 12
Note
Positioning slide VX 5051.172 can be used as a mounting aid for base/plinth system VX in its new design
Packs of
1 pc(s).
Weight/pack
60.5 kg
Customs tariff number
94032080
EAN
4028177959866
ETIM 9
EC000784
ETIM 8
EC000784
ECLASS 8.0
27180504
Product description
TP TopConsole system, pedestal, WHD: 1200x675x400 mm, Sheet steel
Robust construction translates to longer service life in harsh environments, delivering a measurable reduction in maintenance cycles. Feature → Business Impact → Application: The sheet steel enclosure with 1.5 mm walls and 2.0 mm doors provides durable protection while maintaining access for diagnostics in heavy industry automation applications, reducing downtime and safeguarding sensitive electronics. The IP55 rating and NEMA 12 compatibility give you compliant protection against dust and water ingress, enabling installations in manufacturing lines and harsh workshop floors without enclosure-related failures. The included gland plates and two-part gland plates streamline cable routing, speeding up panel assemblies and reducing wiring errors during commissioning. The VX mounting aid compatibility supports base/plinth systems, enabling quick, modular expansions for evolving control architectures. Finish and color—RAL 7035 with powder coating and zinc-plated mounting plate—deliver corrosion resistance and a consistent, professional look across all enclosures, boosting uptime and maintenance planning accuracy. Overall, the TopConsole pedestal supports cost-efficient installation workflows, predictable service intervals, and scalable enclosure infrastructure for machine builders and integrators.
Get a Quick Quote for a Rittal 6702600
Chat with us on WhatsApp - fast responses guaranteed
Need to speak with someone? We'll call you back within 2 hours during business hours
Interested in Rittal 6702600?
Enquire Now
FAQs
Plan the 1200x675x400 mm footprint and ensure clearance for the two doors tracked by their swing. Use the mounting plate (1099x625 mm) as the primary anchor, and allocate space for gland plates and cable routing. Consider the top-open design and VX mounting aid compatibility for base/plinth integration to minimize rework in constrained environments.
Yes. The TP TopConsole pedestal supports the VX mounting aid (VX 5051.172) for mounting as part of a base/plinth system in its new design, enabling modular expansions and faster layout updates on manufacturing lines and machine assemblies.
The enclosure delivers IP55 protection under IEC 60529 and conforms to NEMA 12, providing dust and moisture protection suitable for production floors, machine rooms, and outdoor-adjacent environments. This reduces enclosure-related maintenance and helps meet facility safety and reliability standards.
The unit includes two-part gland plates and gland plates for straightforward cable routing, simplifying wiring during commissioning and facilitating tidy, fault-resistant installations in control cabinets and automation panels.
Durable sheet steel construction with powder-coated exterior and zinc-plated mounting plate minimizes corrosion and repaint cycles, while the integrated gland plates speed up installation. The result is shorter commissioning times, consistent panel aesthetics, and lower lifecycle maintenance costs in high-usage automation environments.
