Rittal TP 6704.600 TopConsole Pedestal - IP55
Part Number: 6704600
Manufacturer
Rittal
Part number
6704600
Alt Part Number
TP 6704.600
Quick Summary
The Rittal TP 6704.600 TopConsole pedestal is a rugged enclosure solution for control panels in industrial environments. Engineers often struggle with messy cable routing and inconsistent mounting when space is limited, leading to longer installation times and higher wiring costs. This solution delivers IP55 protection and NEMA 12 enclosure reliability, built from sheet steel for durability in harsh conditions. By integrating a depth-variable mounting plate on a 25 mm pitch and including gland plates, it streamlines installation, improves serviceability, and supports scalable panel configurations for evolving automation needs.
Product Information
Extended Description
6704600 Rittal: TP TopConsole system, pedestal, WHD: 600x675x500 mm, Sheet steel
Article number
TP 6704.600
Material
Enclosure: Sheet steel 1.5 mm | Door and console cover: Sheet steel, 2.0 mm, all-round foamed-in PU seal | Mounting plate: Sheet steel
Surface finish
Enclosure, cover and door: Dipcoat-primed, powder-coated on the outside, textured paint | Mounting plate: Zinc-plated
Colour
RAL 7035
Supply includes
Enclosure open at top | Door or double door with locking rod (with depth 400 mm at the front, with depth 500 mm at the front and rear) | Mounting plate | Gland plates
Dimensions mounting plate (W x H)
499 mm x 571 mm
Number of doors
1
Dimensions
Width:Â 600 mm | Height:Â 675 mm | Depth:Â 500 mm
IP protection category to IEC 60 529
IP 55
Protection category NEMA
NEMA 12
Note
Mounting plate, depth-variable on a 25 mm pitch pattern
Packs of
1 pc(s).
Weight/pack
45 kg
Customs tariff number
94032080
EAN
4028177959880
ETIM 9
EC000784
ETIM 8
EC000784
ECLASS 8.0
27180504
Product description
TP TopConsole system, pedestal, WHD: 600x675x500 mm, Sheet steel
Feature → Business Impact → Application: The enclosure uses sheet steel walls with 1.5 mm thickness and a 2.0 mm door/console cover with a full PU seal, delivering robust protection against dust and moisture, extending equipment life and reducing maintenance intervals in manufacturing lines. In practice, this translates to lower downtime and improved reliability for machine controls and process automation. Feature → Business Impact → Application: IP 55 protection and NEMA 12 ratings protect sensitive electronics in dusty or humid environments, enabling compliant operation in production floors and outdoor enclosures without frequent seal maintenance. Feature → Business Impact → Application: Two-part gland plates and a supplied mounting plate simplify cable routing and installation, reducing wiring errors and shortening panel assembly times for electrical cabinets and control rooms. Feature → Business Impact → Application: Depth-variable mounting plate on a 25 mm pitch pattern supports flexible component placement, enabling quick reconfigurations as line layouts change or new devices are added. Feature → Business Impact → Application: The TopConsole pedestal dimensions (600 x 675 x 500 mm) and a 45 kg weight per pack balance cabinet capacity with manageable handling, improving logistics and on-site installation efficiency in industrial settings.
Get a Quick Quote for a Rittal 6704600
Chat with us on WhatsApp - fast responses guaranteed
Need to speak with someone? We'll call you back within 2 hours during business hours
Interested in Rittal 6704600?
Enquire Now
FAQs
The enclosure ships with a mounting plate sized 499 x 571 mm and a depth-variable mounting plate on a 25 mm pitch, plus gland plates. Installers should plan for the 600 x 675 x 500 mm footprint, open-top enclosure design, and door configuration for single or double doors with locking rod, ensuring clearance for the AX lock plate and cable routing paths.
IP 55 ensures protection against dust ingress and water jets, while NEMA 12 provides a sealing standard appropriate for indoor industrial use. Together they significantly reduce contamination risk, extend component life, and lower maintenance frequency in dusty, humid, or wash-down capable facilities.
This TopConsole pedestal is designed as a pedestal enclosure with a 600 mm width and a 499 x 571 mm mounting plate; while not a traditional 19-inch rack, the depth-variable mounting plate and gland plates support flexible mounting of 19-inch equipment and controllers within a compact, configurable cabinet system.
The enclosure uses sheet steel 1.5 mm walls with a 2.0 mm door and console cover, all-around PU foam seal, and a powder-coated exterior plus primed finish. The mounting plate is zinc-plated. This combination delivers corrosion resistance, surface durability, and long service life in demanding factory environments.
Integrated gland plates, the included mounting plate, and a uniform AX lock plate reduce field wiring time and ensure repeatable assembly. The robust IP/NEMA protection along with modular depth options lowers maintenance costs, minimizes downtime, and supports scalable configurations as automation needs evolve.
