Rittal 7641350 IT Wall-Mounted Enclosure - IP66
Part Number: 7641350
Manufacturer
Rittal
Part number
7641350
Alt Part Number
AX_IT 7641.350
Quick Summary
IT wall-mounted enclosure by Rittal delivers secure, compact IT distribution for harsh industrial environments. Installing IT hardware directly into production lines can cause downtime, misalignment, and space bottlenecks. This model offers IP66 protection (on request) and optional UL approval, ensuring compliant, reliable operation; it ships pre-assembled for fast deployment. With a 7U height, 482.6 mm (19") mounting angles, and depth-adjustable mounting options, it supports scalable automation architectures, reduces wiring complexity, and accelerates deployment across multiple lines.
Product Information
Extended Description
7641350 Rittal: AX IT wall-mounted IT distributor, 7 U, without mounting plate, with 482.6 mm (19") mounting angles, WHD: 600x380x350 mm (AX 1339), Pre-asembled IT enclosure with:, with hinged door, of all-round solid construction
Article number
AX_IT 7641.350
Design
Wall-mounted enclosures IT | with 482.6 mm (19") mounting angles, depth-variable
Product description
IT wall-mounted enclosure based on AX, with high protection category, for use in industrial environments. Secure, protected integration of IT directly into your production plant processes.
Benefits
Fully pre-assembled IT enclosure for immediate accommodation of 482.6 mm (19") IT components, with depth-variable mounting angles
Material
Sheet steel
Surface finish
Enclosure and door: Dipcoat primed, powder-coated on the outside, textured paint | Interior installation: Zinc-plated
Colour
RAL 7035
Supply includes
Pre-assembled IT enclosure with hinged door, of all-round solid construction | Cam lock with 3 mm double-bit insert | Gland plate with brush strip | 482.6 mm (19") mounting angle, front, mounted onto four interior installation rails with depth adjustment in 25 mm pitch pattern | Mounting bracket | C rail, fastened to the rear panel
Units
7 U
Dimensions
Width: 600 mm | Height: 380 mm | Depth: 350 mm
Installation depth
278 mm
Installation height for components
7 U
Door hinge position
right, may be swapped to the left
Number of locks
1
Installation options
Pre-configured mounting bracket including C rail for cable clamping
Note
Variant with UL approval available on request
Basic material
Sheet steel
Lock
Lock version: Cam lock with 3 mm double-bit lock insert | Number of locks: 1
Protection category to IEC 60 529
IP 10 (up to IP 66 on request)
Gland plate
Size: 7 | Qty.: 1
Number of locks
1
Packs of
1 pc(s).
Weight/pack
17.64 kg
PCF per pack (cradle-to-gate)
67.2 kg CO2 eq (Cat B)
Note on PCF category
Category B: PCF value (cradle-to-gate) based on the product weight, approximately calculated and self-declared
Customs tariff number
94032080
EAN
4028177942394
ETIM 9
EC002500
ECLASS 8.0
27180208
Product description
AX IT wall-mounted IT distributor, 7 U, without mounting plate, with 482.6 mm (19") mounting angles, WHD: 600x380x350 mm (AX 1339), Pre-asembled IT enclosure with:, with hinged door, of all-round solid construction
Fully pre-assembled IT enclosure with 482.6 mm (19") mounting angles and a pre-configured mounting bracket including a C rail for cable clamping. This reduces on-site assembly time and ensures precise alignment, enabling rapid deployment of 19-inch IT components in production lines. The depth-variable mounting angles and 278 mm installation depth (7 U) provide flexible internal layouts, allowing diverse IT hardware to be integrated without redesigning the cabinet. Made from sheet steel with a dipcoat-primer and powder-coated exterior (RAL 7035) and zinc-plated interior rails, the enclosure offers durability and corrosion resistance suitable for challenging factory floors, while maintaining a professional finish. The gland plate with brush strip supports clean cable entry and sealing, improving ingress protection and simplifying cabling management. A hinged door with a cam lock (one lock) delivers controlled security, with the option to swap the door hinge side to suit site requirements, helping maintain compliant access control. Pre-configured mounting brackets and C rails for cable clamping streamline compatibility with 482.6 mm (19") IT components and 7 U configurations, reducing project risk and installation time. These features collectively enable scalable, reliable IT integration in automated environments while reducing maintenance and lifecycle costs.
Get a Quick Quote for a Rittal 7641350
Chat with us on WhatsApp - fast responses guaranteed
Need to speak with someone? We'll call you back within 2 hours during business hours
Interested in Rittal 7641350?
Enquire Now
FAQs
Yes. The AX IT 7641.350 is designed as a 7U IT enclosure with 482.6 mm (19") mounting angles and four interior installation rails, plus a pre-configured mounting bracket and C rail for cable clamping, ensuring compatibility with standard 19-inch IT components and AX frames. Installation is straightforward and supports scalable configurations.
The enclosure offers IP protection up to IP66 on request, depending on the gland plate configuration. The gland plate, along with the brush strip, enhances cable ingress sealing and routing, reducing dust and moisture entry while maintaining accessibility for maintenance and upgrades.
Yes. The enclosure uses sheet steel with a dipcoat primer and powder-coated exterior (RAL 7035) and zinc-plated interior rails, delivering rugged durability for industrial environments. Optional IP66 protection (on request) further improves resistance to dust and water ingress in demanding factory settings.
UL approval variants are available on request, and IP66 protection can be specified with the appropriate gland plate. While CE certification is commonly supported for industrial enclosures, confirm current certification options directly with the supplier to match your regulatory requirements.
The enclosure ships pre-assembled with depth-adjustable mounting angles and a pre-configured mounting bracket, reducing field assembly time and risk of misalignment. This translates to faster project startups, lower on-site labor costs, and improved long-term reliability for IT-integration within automated production lines.
