Rittal VX 8001.211 Gland Plate - Zinc-plated Sheet Steel
Part Number: 8001211
Quick Summary
Rittal VX 8001.211 gland plate is designed to tailor enclosure base layouts for VX systems, enabling precise floor-space configuration and orderly grounding points. Engineers often struggle with configuring large panels without compromising sealing or site-ground continuity, especially where base openings must be sealed quickly. This accessory aligns with UL-listed variants and is supported by standardized classifications such as ETIM 9 EC002620 and ECLASS 8.0 27189261 to simplify procurement and cross-referencing. With its zinc-plated sheet steel construction, it delivers durable performance in demanding environments, while the 690 mm width and 75 mm depth cover a broad range of VX and CX installations. By integrating assembly components and earthing points, it enhances grounding continuity and reduces on-site assembly time, delivering measurable value for panel builders and integrators.
Product Information
Extended Description
8001211 Rittal: VX Gland plate, WD: 800x75 mm
Article number
VX 8001.211
Product description
For individual configuration of the floor space. Potential equalisation is achieved via assembly components and earthing points.
Material
Sheet steel
Surface finish
Zinc-plated
Supply includes
Assembly parts
Note
At least one sliding plate is required to fully seal a base opening.
Dimensions
Width: 690 mm | Depth: 75 mm
To fit
Enclosure type: VX | VX IT | VX SE | CX one-piece console | CX pedestal | Width: = 800 mm
Packs of
1 pc(s).
Weight/pack
1 kg
Customs tariff number
73269098
EAN
4028177948662
ETIM 9
EC002620
ECLASS 8.0
27189261
Product description
VX Gland plate, WD: 800x75 mm
Feature: Tailored floor-space configuration for VX enclosures → Business Impact: Enables precise base layout planning, reducing wasted space and post-install adjustments → Application: VX, VX IT, VX SE, CX pedestal installations. Feature: Sheet steel with zinc-plated surface → Business Impact: Improves corrosion resistance and longevity in harsh industrial environments → Application: Factory floors, assembled control cabinets, outdoor or semi-exposed locations. Feature: Dimensions WD 800x75 mm; Width 690 mm → Business Impact: Standardized fit across multiple enclosure families, ensuring quick retrofits and scalable configurations → Application: VX family, CX consoles and bases. Feature: Supply includes assembly parts → Business Impact: Cuts on-site sourcing time and accelerates commissioning → Application: Fast installation in new builds or retrofit projects. Feature: Earthing points for potential equalisation → Business Impact: Improves grounding continuity and safety compliance → Application: Control cabinet grounding strategies and safety-critical panels. Feature: Note about sliding plate requirement → Business Impact: Clear guidance prevents incomplete sealing and dust ingress → Application: Base opening sealing workflows and quality assurance checks. Feature: 1 pc pack, 1 kg weight → Business Impact: Simplified logistics and procurement, predictable shipping costs → Application: BOMs and kappanized inventory management. Feature: To fit VX range including VX IT, VX SE, CX variants → Business Impact: Broad compatibility supports single-sourcing and reduces part proliferation → Application: Consolidated enclosure programs and maintenance planning.
Get a Quick Quote for a Rittal 8001211
Chat with us on WhatsApp - fast responses guaranteed
Need to speak with someone? We'll call you back within 2 hours during business hours
Interested in Rittal 8001211?
Enquire Now
FAQs
VX 8001.211 is designed to fit VX family enclosures including VX IT and VX SE, as well as CX one-piece consoles and CX pedestals. It is specified for enclosure widths around 800 mm and features a WD of 800x75 mm with a 690 mm wide gland plate opening to support flexible layout configurations.
The gland plate is manufactured from sheet steel with a zinc-plated finish for corrosion resistance. It measures Width 690 mm and Depth 75 mm, with a WD (working depth) of 800x75 mm. The product ships as 1 piece per pack and weighs 1 kg per pack.
By providing a controlled base opening and integrated earthing points, the gland plate simplifies potential equalisation and grounding continuity. The included assembly parts streamline mounting, reducing on-site labor time and helping meet standard grounding practices in VX and CX enclosure projects.
The product is documented with ETIM 9 EC002620 and ECLASS 8.0 27189261 classifications to support procurement and interoperability. A UL-listed variant is available in related documentation, and the packaging reflects standard compliance for enclosure accessories.
Yes, it is noted that at least one sliding plate is required to fully seal a base opening. Plan for this in the BOM and installation sequence to ensure dust protection and environmental sealing meet project specifications.
