Rittal 8001222 Gland Plate - Zinc-plated Sheet Steel
Part Number: 8001222
Quick Summary
Rittal 8001222 gland plate configures floor space and supports reliable earthing in VX enclosure installations. In busy panels, base openings can cause sealing challenges and inconsistent grounding; this accessory helps address those pain points. It is UL-listed per the EN-listed asset and supports CE-conformant assemblies for safer, compliant installations. By enabling flexible gland plate configurations and straightforward assembly, it reduces installation time and maintenance costs while improving reliability. Users benefit from predictable mounting patterns and safer earthing connections across VX, VX IT, and CX setups. The product's zinc-plated sheet steel construction resists corrosion in harsh industrial environments, extending service life and reducing replacement cycles.
Product Information
Extended Description
8001222 Rittal: VX Gland plate, WD: 600x275 mm
Article number
VX 8001.222
Product description
For individual configuration of the floor space. Potential equalisation is achieved via assembly components and earthing points.
Material
Sheet steel
Surface finish
Zinc-plated
Supply includes
Assembly parts
Note
At least one sliding plate is required to fully seal a base opening.
Dimensions
Width: 490 mm | Depth: 275 mm
To fit
Enclosure type: VX | VX IT | VX SE | CX one-piece console | CX pedestal | Width: = 600 mm
Packs of
1 pc(s).
Weight/pack
1.82 kg
Customs tariff number
73269098
EAN
4028177948778
ETIM 9
EC002620
ECLASS 8.0
27189261
Product description
VX Gland plate, WD: 600x275 mm
Feature: Sheet steel, zinc-plated surface finish. Business impact: Delivers durable, corrosion-resistant construction suitable for harsh industrial environments, reducing maintenance and replacement costs. Application: Ideal for factory floors and control cabinets where long service life and reliable grounding are critical. Feature: Dimensions and fitment (WD 600x275 mm; Width 490 mm; fits VX family; 600 mm enclosure width). Business impact: Provides a precise footprint for floor-space configuration, minimizing the need for custom adapters and accelerating installation. Application: VX, VX IT, VX SE enclosures and CX series with 600 mm width benefit from a ready-to-install gland plate. Feature: Supply includes assembly parts. Business impact: Speeds up installation and reduces procurement steps, lowering project lead times. Application: Quick deployment in new builds or upgrades, with reduced risk of missing hardware. Feature: Potential equalisation via assembly components and earthing points. Business impact: Improves electrical safety and grounding reliability across enclosures, supporting compliance and reducing troubleshooting time. Application: Essential for power and control cabinets where earth continuity is critical. Feature: Note on sealing (at least one sliding plate required). Business impact: Ensures a complete base opening seal to protect against dust and ingress, preserving enclosure integrity. Application: Important guideline for proper enclosure sealing during commissioning. Feature: Weight/pack and packaging details (1.82 kg per pack; 1 pc pack). Business impact: Simplifies logistics planning and cost estimation for assemblies and spares. Application: Useful for procurement and maintenance planning in automated manufacturing lines.
Get a Quick Quote for a Rittal 8001222
Chat with us on WhatsApp - fast responses guaranteed
Need to speak with someone? We'll call you back within 2 hours during business hours
Interested in Rittal 8001222?
Enquire Now
FAQs
The VX 8001222 gland plate is designed for VX family enclosures and is compatible with VX IT and VX SE variants, as well as CX one-piece consoles and CX pedestals when using a 600 mm width. It matches a 600 mm width enclosure footprint and requires assembly parts for proper installation, ensuring a clean and configurable floor-space setup.
The gland plate provides potential equalisation via included assembly components and earthing points, improving grounding reliability. It also supports sealing of base openings, provided a sliding plate is used as required, which reduces dust ingress and maintains enclosure integrity during operation in demanding environments.
Plan for a 600 mm wide VX family installation; use the supplied assembly parts to connect earthing points and ensure proper potential equalisation. Remember the note: at least one sliding plate is required to fully seal the base opening. The plate weighs 1.82 kg per pack, aiding handling and logistics on site.
This gland plate is UL-listed according to the provided asset, supporting safety compliance. While CE conformity is commonly pursued in electrical assemblies, verify local requirements and compatibility with CE-marked components for your specific installation. The product also carries ETIM and ECLASS classifications for procurement alignment.
By enabling quick configuration of floor space and reliable earth continuity, the gland plate reduces installation time and downstream troubleshooting. Its corrosion-resistant zinc-plated steel extends service life, lowering replacement frequency and maintenance costs, while compatible assembly components streamline procurement and reduce spares inventory for VX-based enclosures.
