Rittal VX 8001.223 Gland Plate - Zinc-Plated 800 mm
Part Number: 8001223
Quick Summary
Rittal VX 8001.223 gland plate configures VX enclosure floor space for modular assemblies. A common challenge is achieving reliable potential equalisation and clean base openings without obstructing access. The part is UL-listed and aligns with ETIM 9 EC002620 and ECLASS 8.0 27189261, supporting certified procurement. Its zinc-plated sheet steel construction delivers corrosion resistance in industrial environments while remaining lightweight for handling. For VX ecosystems, it complements assembly components and earthing points, easing installation and improving overall enclosure integrity—ideal for field service and retrofit projects. Each pack includes assembly parts to simplify mounting, and the note that at least one sliding plate is required to seal a base opening ensures a compliant setup.
Product Information
Extended Description
8001223 Rittal: VX Gland plate, WD: 800x275 mm
Article number
VX 8001.223
Product description
For individual configuration of the floor space. Potential equalisation is achieved via assembly components and earthing points.
Material
Sheet steel
Surface finish
Zinc-plated
Supply includes
Assembly parts
Note
At least one sliding plate is required to fully seal a base opening.
Dimensions
Width:Â 690 mm | Depth:Â 275 mm
To fit
Enclosure type:Â VX | VX IT | VX SE | CX one-piece console | CX pedestal | Width:Â = 800 mm
Packs of
1 pc(s).
Weight/pack
2.6 kg
Customs tariff number
73269098
EAN
4028177948785
ETIM 9
EC002620
ECLASS 8.0
27189261
Product description
VX Gland plate, WD: 800x275 mm
Feature: Broad compatibility with VX and CX enclosures, including VX IT and VX SE models. Business Impact: Reduces part variety and speeds up design and assembly. Application: Suitable for new installs and retrofits in factory automation. Feature: Zinc-plated sheet steel construction. Business Impact: Delivers corrosion resistance in harsh industrial environments, extending service life. Application: Ideal for manufacturing floors, control panels, and data centers where moisture and dust are concerns. Feature: Includes assembly parts in the supply. Business Impact: Cuts procurement time and on-site staging, accelerating installation. Application: Quick-fit during cabinet configuration and rework projects. Feature: Dimensions WD 800x275 mm; fits 800 mm wide enclosures. Business Impact: Ensures proper alignment and sealing with base openings, reducing retrofit risk. Application: Base opening sealing when used with corresponding sliding plates. Feature: Clear specifications and classifications (ETIM 9 EC002620, ECLASS 8.0 27189261). Business Impact: Facilitates compliant sourcing and seamless ERP/inventory matching. Application: Procurement workflows and supplier audits in industrial environments.
Get a Quick Quote for a Rittal 8001223
Chat with us on WhatsApp - fast responses guaranteed
Need to speak with someone? We'll call you back within 2 hours during business hours
Interested in Rittal 8001223?
Enquire Now
FAQs
Installation starts by aligning the gland plate to VX enclosure mounting points and securing it with the included assembly parts. Ensure correct orientation to align with access points and connect earthing points for potential equalisation. The note about at least one sliding plate to seal the base opening must be observed to achieve a complete enclosure seal and maintain enclosure integrity over time.
The gland plate is designed to fit VX family enclosures and related CX configurations with a width of 800 mm. It matches WD: 800x275 mm and is specified to fit VX, VX IT, VX SE, CX one-piece console, and CX pedestal variants, facilitating standardized retrofits and new builds within the VX ecosystem.
Key specs include material: sheet steel with a zinc-plated finish, dimensions WD 800x275 mm, and a weight of 2.6 kg per pack. The product is supplied as 1 piece per pack, with assembly parts included. The EAN is 4028177948785 and the product is listed under ETIM 9 EC002620 and ECLASS 8.0 27189261 for easy procurement.
The VX 8001.223 gland plate is UL-listed according to available EN documentation, supporting compliance and safe integration in many installations. It also aligns with ETIM 9 EC002620 and ECLASS 8.0 27189261 classifications, assisting standards-based procurement workflows.
Using this gland plate reduces installation time through included assembly parts and standard VX compatibility, improves grounding with built-in earthing points, and enhances enclosure integrity with a zinc-plated corrosion-resistant finish. The result is lower labor costs, fewer field changes, and improved reliability in harsh industrial environments.
